ZK Technology iClock 2500 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

iClock multimedia v6.0

Important Notes

This fingerprint machine is designed to work with the newly issued
V3.X version Time & Attendance software only, which is completely
compatible with the original V2.X version that has been popularly
applied to all machines, the new one own stronger function, more
convenient, and more human nature for user than the V2.X version
I

Advertisement

Table of Contents
loading

Summary of Contents for ZK Technology iClock 2500

  • Page 1: Important Notes

    iClock multimedia v6.0 Important Notes This fingerprint machine is designed to work with the newly issued V3.X version Time & Attendance software only, which is completely compatible with the original V2.X version that has been popularly applied to all machines, the new one own stronger function, more convenient, and more human nature for user than the V2.X version...

  • Page 2: Acknowledgements

    iClock_ v6.1 Acknowledgements Thank you for purchasing our product. Before using this machine, please read this manual carefully. Notice Please Do not place the product in the place with strong light, because the strong light may significantly affect the fingerprint scanning, and thus cause the fingerprint verification fail.

  • Page 3: How To Place The Finger

    iClock_ v6.1 Installation Enrollment Identification Enrollment Installation Identification How to place the finger Make sure the fingerprint image captured is of a core of presented finger, a fingerprint is point to locate within innermost recurring ridge of any give finger. To obtain a higher success rate, enroll same finger 3 times in a slightly-adjusted angle, one to the center, one incline slightly to the left.
  • Page 4 iClock_ v6.1 Notice: Please adopt the correct way to place the finger. Our Company is not responsible for any damages and troubles whatsoever arising out of from improper pressing manner. About this Manual All functions in this document are subjected to the actual product , as a result of the product is unceasing renewal, all attempts have been made to make the information in this document complete and accurate.
  • Page 5 iClock_ v6.1 About 8〞TFT iClock...
  • Page 6 iClock_ v6.1 1 LED indicators: at normal working the green light blinking per one second, if the verification is positive, the LED will glow green for long -three seconds, If the authentication fails ,the LED glow red for long-three seconds. 2 Function keys: state key and functional shortcuts.
  • Page 7 iClock_ v6.1 14 Reset key : when the machine is in halt, push this key with samll tools 13 Key hole: Lock the whencover of the Cable Box Installation Steps 1) Mount the metal plate on walls in the appropriate place and fix 2）find the key along with the product.
  • Page 8 iClock_ v6.1 Recommendation step Step 1：Place the fingerprint machine properly and power up machine. Step 2: Enroll user, register fingerprint and password, and assign privilege to user. Step 3: verify user by the registered fingerprint and password. Step3: Configure the communication parameter; download the staff information to software using the U flash disk or one of three communications which is used to connect with the computer.
  • Page 9 iClock_ v6.1 Ready state is shown in photographs， users can upload images (see 7.4 upload custom photo), but also can shift the clock displayed on the screen intermediate (See 5.1 interface installed). When the equipment in ready working mode, users press OK button or touch keys on the screen after the player launched flash player, the middle of the screen broadcast flash animation After user verification completed by the fingerprint or the password...
  • Page 10 iClock_ v6.1 Ready work: The ready work equipment as shown below:...
  • Page 11 iClock_ v6.1 After playing the flash , the player interface will automatically shut down , in the process if press any button to stop players and return to the ready working mode. Touch Screen The devices support touch screen. That is, if we conduct an operation without keyboard by pressing option to choose , it is only need to use the touch pen or fingers, such as touch the icon or menu , according to the location or menu the system will locate and...
  • Page 12 iClock_ v6.1 Use fingers touch the display area on screen lower right of the key corresponding state information can be displayed once again. (See definition of state 5.5 keyboard definitions) Track Staff Attendance When staff punch –in or out, who will be more concerned about the current perform time, and so after staff in attendance the equipment will show the current time on the screen by clocks .
  • Page 13 iClock_ v6.1 sensor face and all fingerprints data in fingerprint machine Step1： Press the fingerprint sensor with finger in proper method. Step2 ： The equipment prompts "Thanks", the validation is successful. If the user’s photo has been registered, the photo will appear...
  • Page 14 iClock_ v6.1 The equipment prompt "please place finger again ", go back to repeat operation.
  • Page 15 iClock_ v6.1 （1） 1: 1 fingerprint validation (AC.NO +fingerprint) Match the fingerprint which place the fingerprint sensor face and entry the related number with keyboard, when user's fingerprint 1：1 quality is too poor to be recognized, this way will be available Step 1：Verify personnel's AC.NO that keyboard entry in the initial interface.
  • Page 16 iClock_ v6.1 Step 4：The equipment prompt "Thanks", the validation is successful. When the prompt “please try again?” appear.
  • Page 17 iClock_ v6.1 In the equipment there are default two times to allow the staff to try, Times range is setted in 5.1 interface. After failing to verify two times, the user must return the step to operate again. Track Time & Attendance by password Step 1：...
  • Page 18 iClock_ v6.1 Step 3: the password interface appears, please input the password Step 4：The equipment prompt "Thanks", the validation is successful.
  • Page 19 iClock_ v6.1 The equipment prompts "the password is wrong", the interface will return to the password operation interface.
  • Page 20 iClock_ v6.1 In the equipment there are default two times allowing the staffs to try, the number of times to be allowed to set in5.1 interface. After failing to verify two times, the user must return the step to operate again Track Time &...
  • Page 21 iClock_ v6.1 Note: the card induction area is 3cm -7cm above the small keyboard. Connect with PC This equipment will only track the attendance time record, but to get statistics result is unavailable till the software process the attendance record in the PC, therefore connecting machine with PC is necessary download attendance logs into Time &...
  • Page 22 iClock_ v6.1 set the following several items: IP address: default IP is 192.168.1.201, which has to be resetted. Subnet mask: default Subnet mask is 255.255.255.0, you may change it depending on actual application. Gateway: the default gateway is 0.0.0.0, you may change it depending on actual application Network speed: In network running speed, there are Automatic Adaptation, 10M and 100M, three options;...
  • Page 23 iClock_ v6.1 – 254. Baud rate: the computer communication speed, the low speed communication is stable, we recommend that the RS485 communication Baud rate as 9,600 and 38,400. If use RS485 to communicate, please set this item as “Yes”. ： RS485 Communication password: in Connection Setting.

  • Page 24: Table Of Contents

    iClock_ v6.1 Content Important Notes ..................I Acknowledgements ................. 1 How to place the finger ..............2 1 Main Windows ..................1 2 User Management................. 3 2.2 View User ................12 2.2.1 Search for users ............13 2.2.2 Inquiries Attendance ............. 14 2.2.3 Add New User ..............
  • Page 25 iClock_ v6.1 5.3 Screen Calibration ..............19 5.5 The Definitions of Keyboards ..........21 5.5.1 State Key Definition ............. 21 5.5.1 Using State Key ............23 6Inquiry Record..................24 7 USB Flash Disk Management ............27 7.1 Upload User data ..............28 7.2 Download User’s Data.............
  • Page 26 iClock_ v6.1 Appendix 5 battery specifications and Notice ........51...

  • Page 27: Main Windows

    iClock_ v6.1 1 Main Windows While device in readiness mode, Press key to open main window, shown as following figure Instruction On the Main menu interface you will find eight icons menu, namely: User Management, System Settings, Communications Settings, Customize Settings, Record Inquiries, U flash disk Management, Broadcast Information, Systems Information.
  • Page 28 iClock_ v6.1 B: Press to move on, and press OK key to enter interface for operation. 2) Submenu Status Press ▲ / ▼ key or press F1 ~ F8 submenu , the selected option will become in black grey colour, press OK key to enter interface for operation.

  • Page 29: User Management

    iClock_ v6.1 2 User Management For a fingerprint machine, user's basic information includes fingerprint, password and management privilege. When the company track staff Time & Attendance log, as a result of reassigning staff, the user information in the fingerprint machine also needs to correspondingly make the modification, therefore the fingerprint machine provide function to add, delete, search, change user and so on the operation.
  • Page 30 iClock_ v6.1 AC.NO: Staff' attendance number. Name: use T 9 input method to key in user’s name. Fingerprint: Registered staff's fingerprint, to register ten fingerprints is available the fingerprint may be used to check attendance by the staff whose fingerprint has been registered. Registration password: The registration user's password, the effective figure of password is 1 ~ 8.
  • Page 31 iClock_ v6.1 Enroll Photos: register user’s Photos. Registered user’s photographs will be displayed in attendance performance. Privilege: Users are people whose identity must be authenticated before enter a menu. The ordinary consumer can track attendance by the fingerprint or the password only; the manager already may equally carry on the daily checking attendance with the ordinary consumer, but may enter the menu to operate each option.
  • Page 32 iClock_ v6.1 with T9 input method input by the ESC from the completion of T9 input method. Directly press the "OK" button or scroll▲ / ▼ cursor keys will be located in the "Registration fingerprint" button, then "OK" button, enter the fingerprint registration. Enroll fingerprint Note: 1) the fingers is shown as yellow frame that present the current selected finger.
  • Page 33 iClock_ v6.1 ▲/▼/ / press key with the digital keyboard or scroll button, or touch the fingers which will be registered fingers. Follow the equipment prompt place the finger, you must continuously press the same finger 3 times in the correct method until the registration successful prompt appear After registering fingerprint successfully, if need to continually register another fingerprints to press finger, directly after the...
  • Page 34 iClock_ v6.1 After saving it, the icon will display on the screen, which mean the password has already set in the device. Enroll cards ★ Scroll ▲ / ▼keys to locate the cursor on “enroll card" button, and press "OK" to enter the registration card .
  • Page 35 iClock_ v6.1 Slight ware the card near the induction area, after the equipment found the card number, then remove the card from the equipment, after equipment prompt that the "Enroll successfully" the card number will be save up, or may press “Done” button to return to register interface.
  • Page 36 iClock_ v6.1 After entering a snapshot mode of the equipment interface , scroll ▲ / ▼ key to switch options input box with the small keyboard, and input appropriate number keys to adjust the value of the camera filming effect, after appropriate adjustment press (F7) or "OK"...
  • Page 37 iClock_ v6.1 Press any one button or touch the region of images on the screen, can exit from photo browser . Privilege setting ▲/▼ Scroll the key, and locate cursor on the "Privilege" option box, Scroll key to choose privilege. Save/exit user registration To confirm the registration information is correct, after getting confirmation, save it.

  • Page 38: View User

    iClock_ v6.1 2) press "ESC" to exit. If the prompt "the data has been changed, Are you sure to save it?” appear on equipment, want continuing to press "OK", if you abandon this operation, press "ESC" key to return the previous menu. 2.2 View User By means of the user view you can view all users' information in the current equipment is available, which include username, the...

  • Page 39: Search For Users

    iClock_ v6.1 2) The RF card No. will be displayed on the Card No. Rank Scroll ▲/▼ key , the blue cursor locate at the line that want to be operate, press the function key where around the screen both side to do operation, Example , press F1 key to search user.

  • Page 40: Inquiries Attendance

    iClock_ v6.1 search, after searching successfully, the blue cursor will automatically locate on this staff name, if this staff you search does not exist in the device, the prompt "the non- registration data" will appear. 2.2.2 Inquiries Attendance When the manager examine staff's registration information and fingerprint so on, meanwhile may track the staff’s attendance record in the same month.

  • Page 41: Add New User

    iClock_ v6.1 ▲/▼ Scroll key to browse the attendance log line by line. Press F6/F7key to browse the attendance log page by page. Press“ESC”/F8 return the user browser interface Press OK/ key to inquire the detailed situation. （F8） After the examination completed, press "ESC" key to return to the user management interface.

  • Page 42: Edit User

    iClock_ v6.1 2.2.4 Edit User Makes the revision for user's information which have been saved in the machine, for example, if the registered fingerprint is invalid , renew the fingerprint or register the password, just enter the " edition user" available. Press the "...

  • Page 43: Deletions Users

    iClock_ v6.1 1) Press " " the key to save editing result and return to the user management interface. 2) press the "ESC" key , prompt "the data have been changed, are you sure to save it" display on the equipment press OK, press “...
  • Page 44 iClock_ v6.1 If there is not user’s fingerprint or the password in the device, then his /her corresponding typeface is a blue color, be unable to operate ▲/▼ it, scroll the key to locate the cursor at the option which need to operate.

  • Page 45: System Setting

    iClock_ v6.1 3 System Setting To set up system parameter, make the equipment at the function, display with the perfect exhibition, pursue user's satisfactions. 3.1 Systems parameters 1: 1 matching threshold: When use ID+ fingerprint to recognize. Threshold a predefined number , often controlled by a biometric system administrator , which establishes the degree of correlation necessary for a comparison to be deemed a match .if the score resulting from template comparison exceed the threshold , the...
  • Page 46 iClock_ v6.1 Recommend matching threshold setting: e. (effect value is 1 ~ 60 minutes) Suggested Threshold Settings One-to-many One-to-one High Middle Middle High Time format: Set up the time format in the fingerprint initial interface. Scroll / key to choose form, the fingerprint machine supports 10 kinds of dates forms, YY-MM-DD, YY/MM/DD, YY.MM.DD, MM-DD-YY, MM/DD/YY,...
  • Page 47 iClock_ v6.1 favor Alarm attendance log( Alm Attlog), When the remainder log capacity reached set numerical value, it will automatically sound warning that logs will be full ( virtual value is 1-99). Recheck Minute: set it within the scope (unit: minute). Someone attendance has been recorded, then the second record will not display (virtual value is 66).
  • Page 48 iClock_ v6.1 Scroll the▲/▼key to shifts the cursor on the item which you need set. If the item is inputting box, configure the value with the numeric keyboard input; If the item is rolls the frame, Scroll the / key to choose the value you need, after the setting finished, please directly press OK or (F7) key to save this item and return to preceding interface, press the ESC (F8) key to give up...

  • Page 49: Time And Date Settings

    iClock_ v6.1 3.2 Time and Date settings It is necessary to set the accurate date and time for each of equipments. To obtain guarantee for tracking the accurate attendance result. ： Enter option to set the time and date Instruction ▲/▼...

  • Page 50: Data Managements

    iClock_ v6.1 3.3 Data managements Delete attendance record (Clear Attlog): Deletes all attendance record. Delete the complete datum (Clear All): Delete all registrations personnel information, the fingerprint and the attendance record. Clear Admin Privilege: Change the Administer privilege into ordinary users’ option: Caution：Unable to restore any file you delete, please careful Instruction ▲/▼...
  • Page 51 iClock_ v6.1 will operate. press OK to start operation, when the prompt “ Are you sure to continue the current this operation?” appear on the equipment, press OK key again , be sure that the data will be deleted, if after you delete the data, the data will be unable to restore.

  • Page 52: Upgrade Firmware

    iClock_ v6.1 automatically jumps to the next picture. If you want to delete all （F7） public picture in the equipment, Press button. Press the ESC (F8) key to return to the data management interface. 3.4 Upgrade firmware If want to upgrade the firmware of machine, may use USB flash disk to achieve.

  • Page 53: Automatically Test

    iClock_ v6.1 Note: to restores the setting cannot erase the personnel information and the attendance record in the equipment. 3.6 Automatically test The equipment provides with the automatic test function to test each module in the fingerprint machine. The function helps the operator firstly check the module, if the machine has some problem.

  • Page 54: Test Tft Screen

    iClock_ v6.1 press the "OK" key to start the testing 3.6.1 Test TFT screen Equipment provides auto-test to check the TFT screen demonstration effect. Through when the screen displays in color, entire white, entire black, you can inspect each place of the screen at this time, to check whether the TFT screen demonstrates normally.

  • Page 55: Test Fingerprint Sensor

    iClock_ v6.1 press accords with the display on the screen. The key you press display in garnet color, otherwise the key in gray black. Press “OK”、“ESC”（F8） key to exit from this test 3.6.4 Test fingerprint Sensor The auto-test fingerprint sensor tells user whether the sensor is in normal, through the test you can examine the picture resolution of the fingerprint, to whether the fingerprint picture is clear, and the screen will real-time show fingerprint picture that is captured from...

  • Page 56: Communication Setting

    iClock_ v6.1 4 Communication setting If when the data is transferred between the equipment and PC, it is necessary to set the equipment communication parameter according to the transmission cable. When the equipment and the machine are in the communication, the "in the work..” Message will be displayed on the equipment, Please Do not operate the equipment while the test is running.
  • Page 57 iClock_ v6.1 To find sitting on the fingerprint machine if you are using serial port (RS232/RS485) to communicate between the equipment and PC, configure the following parameter: Baud rate: the rate at which fingerprint machine communicate with the PC , there are five kinds of options 9600, 19,200, 38,400, 57,600, 1.15200 bit/sec, the high speed communication is quick, we recommend that high speed apply to the RS232communication ;...
  • Page 58 iClock_ v6.1 the password does not exist), it is allowed to set it as other values, after setting up, be sure to input this password before the software communicate with the equipment , otherwise you will fail to create connection between the fingerprint machine and PC software. The connection password length is 1 ~ 6.

  • Page 59: User Profile

    iClock_ v6.1 5 User profile User Profile settings can be set up according to their personal preferences show some style and operation method 5.1 User Customize According to their personal preferences, users can set up the initial interface style. the times of retrying 1:1 verification or password: users go on 1:1 verification or password, who may forget the right registered finger or improperly press fingers.
  • Page 60 iClock_ v6.1 Public Photo: according to the actual demand, users can upload some public photographs to be displayed on the screen. 1) Photo cyclical interval : how long the interval to shift Photo Display (Scope for 3 to 999 seconds) 2) Duration of the clock showed that after the user is verified how long the clock pictures show.
  • Page 61 iClock_ v6.1 Camera mode: When staff attendance, whether capture operation and display the current snapshot picture. Select "Yes" snapshot, selected as the "no" does not capture. Note: If the duration of the clock display is set to 0, in ready working state the machine plays full-screen flash;...

  • Page 62: Video Setting

    iClock_ v6.1 5.2 Video Setting The built-in camera equipment parameter settings, the camera will have the best performance. Brightness: Adjustment the brightness of camera capture photo. Contrast: Adjustment the contrast of camera capture photo. Picture quality: Setting up quality of the saved picture . Environment: Setting up the filming environment in which to take effect as the best.

  • Page 63: Screen Calibration

    iClock_ v6.1 keyboard and input appropriate number keys to adjust the value of the camera , or press the button will restore the default parameters and restore to the default state. After appropriate adjustments by (F7) or "OK" Save settings, press the "return" from set. Note: the setting is just available to the unit which has camera.
  • Page 64 iClock_ v6.1 ▲/▼ Scroll key to view the bell setting at line by line. Scroll F5/F7key to view the bell setting in page by page. Press " " key to begin/end the selected bell. Press "OK"/F5 to choose one of the bell setting, and enter the edition bell.

  • Page 65: The Definitions Of Keyboards

    iClock_ v6.1 ▲/▼ Scroll the key to shift the cursor to input box, set up the value with the numeric keyboard input. After the setting, directly press /“OK” （ F7） key to save the settings and return to OK or the preceding interface, press the ESC(F8) key to give up.
  • Page 66 iClock_ v6.1 this state key. When press any state key on initial interface, the attendance state corresponding to the state key will appear under the leftside of the screen, that is convenient for users to check. Instruction ▲/▼ Scroll the key to shift option box, Scroll key to change the setting.

  • Page 67: Using State Key

    iClock_ v6.1 5.5.1 Using State Key On main interface, press “F5”, the corresponding state key will appear at the left bottom of the screen. Then user can do the verification by fingerprint or password, the equipment will keep the attendance record at the corresponding state...

  • Page 68: 6Inquiry Record

    iClock_ v6.1 6Inquiry Record If the fingerprint machine successfully record the staff time & attendance, the record will be saved in. the inquiry record function has been designed in simple and manner to help user find his/her attendance logs he/she need quickly and easily. this machine offer the inquiry function.
  • Page 69 iClock_ v6.1 input condition will be displayed on the screen Scroll ▲ / ▼ key, move the cursor on the line you want, press /“OK”（F5） to enter attendance record Details view. For example, on August 28 on the 1st staff, Press Details to check.
  • Page 70 iClock_ v6.1 If the records fulfill the first page, press F6/F7 to turn on next page.. Press the "ESC" (F8) to return to the previous interface.

  • Page 71: Usb Flash Disk Management

    iClock_ v6.1 7 USB Flash Disk Management Using USB flash disk is able to download user’s information, fingerprint templates, attendance logs, and upload it into the tracking software for processing. Mearwhile, user’s information and fingerprint templates are able to upload into other fingerprint equipments.

  • Page 72: Upload User Data

    iClock_ v6.1 7.1 Upload User data Upload user’s information and fingerprint templates which have been saved in the USB flash disk into the equipment. Instruction Plug the USB flash disk into the USB slot of the fingerprint ▲/▼ machine, scroll " "...

  • Page 73: Upload The Customized Picture

    iClock_ v6.1 7.3 Upload the Customized Picture Upload the file with JPG picture format which front name as "ad_” in the USB flash disk into the equipment, after these pictures have been transfer to the equipment, it will display in the initial window. (Picture specification, please see appendix 4) Instruction Plug the USB flash disk in the USB slot of the fingerprint machine,...

  • Page 74: Download Attendance Datum

    iClock_ v6.1 7.4 Download Attendance Datum Save all attendance datum from the equipment into the USB flash disk. Instruction 1) Plug the USB flash disk into the USB slot of the fingerprint machine through the mini USB cable. 2) Scroll“▲/▼”to select the “ ”.

  • Page 75: Download User's Photos

    iClock_ v6.1 the equipment promt successful uploading, it will automatically turn to next picture. Complete uploading, press the "ESC" to exit. 7.6 Download User’s Photos To save staff photo which is taken by the equipment into U flash disk. Instructions Insert U flash disk into the USB slot of the fingerprint machine, scroll "▲...

  • Page 76: Upload Flash

    iClock_ v6.1 Insert the U flash disk into the USB slot of the fingerprint machine. Scroll "▲ / ▼" button to select users download data. Press "OK" button, the two file, udata.dat. and sms.dat in the machine will be downloaded to the disk. 7.9 Upload Flash Before you upload the Flash file into the equipment, please contact our technical support.

  • Page 77: Information Release

    iClock_ v6.1 8 Information Release The short message is similar to bulletin and notice. With the function, operator is able to schedule and edit the content of the short message that will be displayed on the screen. The short message is consisted of public short message and individual short message.

  • Page 78: Establish Short Message

    iClock_ v6.1 Scroll ▲ / ▼ keys to read his party Short Message. Press F6/F7 keys by reading a chapter in the short message. Press "OK" / F1 to view the selected Short Message Details. Press F2 to view new short message. Press F3 to edit short message.
  • Page 79 iClock_ v6.1 When the cursor locate in the text box, press “*”key to open the T9 ▲/ input method, input the content of the short message, scroll the ▼ key to switch the input box, scroll to change setting or keyboard and input the value with the small numeric keyboard.
  • Page 80 iClock_ v6.1 ▲/▼ Scroll key to search personnel line by line . Press "OK" key to choose the personnel, then short message will be released to this staff. Press key to save your choice and exit. /F7/F8 Note: Before finishing the steps, please do not exit, or the setting will not work and turn to the initialization.

  • Page 81: View Staff Short Message

    iClock_ v6.1 Press key to delete the short message. Device will prompt “Are you sure to delete this short message? : Press “OK” to confirm the delection, press “ESC” to give up the operation 8.2 View Staff Short Message 1) Check the public short message While the public short message is working, the main interface show the picture and the content of the message, the interval display time will turn around with advertising picture, if there are...
  • Page 82 iClock_ v6.1 content will be displayed. The duration of the message display is 30 seconds, after the message, the user verification begins working.

  • Page 83: Systems Information

    iClock_ v6.1 9. Systems Information From system information icon, you are able to know the information about the device, like Free volume and Engaged templates. 9.1 Equipment Information In the equipment information, there are the equipment name, serial number and firmware version. 9.2Logs Capacity Through the log capacity you can check the number of users, managers, registered password in this machine;...
  • Page 84 iClock_ v6.1...

  • Page 85: Getting Familiar With Keyboard

    iClock_ v6.1 Appendix 1 Getting Familiar with Keyboard The equipment keyboard has different usage in different interface, for details please see the next table Detailed solution numeric 1, 0 ~ 9, is used in to input the staff to number, numeral keyboard and password so on Function...
  • Page 86 iClock_ v6.1 menu key，confirms ESC key Confirm and save 1、 Cancel operation and return to the preceding of menus 2、 Press ESC key to close T9 input method 1.start the T9 input method 1.The backspaces key in T9 input method...

  • Page 87: T9 Input Method

    iClock_ v6.1 Appendix 2 T9 Input Method T9 input method is a intelligent input method; it is famous for highly effective inputting the character. The equipment fully supports T9 with Chinese, English and symbol input. There are three or four English letters on 0 ~ 9 numeric keyboards of the machine, for example the numeric keyboard 1 has the A, B, C three letters, only input key where this letter locate for the T9 Chinese, the program...
  • Page 88 iClock_ v6.1 ESC key Backspace Spacebar Start the input method ▲/▼/ / ：Turn page key OK：Choose letter Take an example for the T9 English input: Input “Arabia " press the * numeric key to enter the T9 input method.
  • Page 89 iClock_ v6.1...
  • Page 90 iClock_ v6.1 Press OK Scroll / key or input the letter you select. Press 4 If the operation must be carry on, please use the above method to do it again. After the input is completed, press the ESC key to exit...

  • Page 91: Quickly Inquire Staff Attendance Logs

    iClock_ v6.1 Appendix 3 Quickly Inquire Staff Attendance Logs In order to help ordinary user to view his/her Time & Attendance record at same time, whether forgetting clock-in or occurring error, should well inform the manager that the attendance record is in abnormal.
  • Page 92 iClock_ v6.1 ▲/▼ Scroll the key to browse the Time & Attendance record line by line F6/F7 Press key page by page to browse the Time &attendance record; Press “OK’ or key show detailed inquiry. Press ESC/F8 key to return the initial interface.

  • Page 93: The Rule About The Advertising Pictures

    iClock_ v6.1 Appendix 4 The Rule about the Advertising Pictures Custom Photo specifications: 1. Photo format is JPG format to the other formats Do not support the format of photographs must be "ad_" as its head. For example ad_12.jpg is legitimate. 3.After photo is uploaded , the file name is not changed, following the replacement of the second pictures.
  • Page 94 iClock_ v6.1 flash disk must be established, all users need upload photos within this folder. 4. while uploading, insert U flash disk into USB slot of the fingerprint machines, scroll the "▲ / ▼" key to preview qualified photographs in U flash disk, select the photos you need to upload.
  • Page 95 iClock_ v6.1 Appendix 5 battery specifications and Notice Maximum output voltage DC15.0V Output voltage DC12.0V Rechargeable power supply specifications DC12V - 1.5A Cycle life The number of charge-discharge cycle ≥ 500 Charging time (H) 3.5 ± 0.5 Discharge time (H) 3.5 ±...
  • Page 96 iClock_ v6.1 3, the battery has vent fluid, electrolysis also caused eye, skin or clothing, immediately wash with water flow, or seek immediate medical assistance; 4, please correct for battery installation and dismantling, otherwise it will affect the performance and battery life. Caution：...
