- Page 1 Anaren AIR for Wi-Fi A43364 Wi-Fi Module Series User’s Manual www.anaren.com/air 800-411-6596 AIR@anaren.com...
- Page 2 This page intentionally left blank.
-
Page 3: Table Of Contents
Table of Contents 1. Overview 1.1. A43364A 1.2. A43364C 1.3. A43364x Features and Benefits 1.4. Theory of Operation 1.5. Applications 2. Approvals and Usage 2.1. Product Approvals 2.1.1. U.S.: Federal Communications Commission (FCC) 2.1.1.1. FCC Labeling Requirements 2.1.1.2. End User Manual 2.1.1.3. -
Page 4: Overview
1. Overview Anaren AIR for Wi-Fi A43364x modules are based on the CYW43364 chipset from Cypress. They are surface- mounted 2.4GHz radio frequency (RF) transceivers incorporating Wi-Fi technology that conforms to the WLAN IEEE 802.11b/g/n. The CYW43364 chipset integrates an ARM... -
Page 5: Theory Of Operation
1. Overview Benefits: • 100% RF tested in production for repeatable performance • Minimal RF and protocol experience necessary • Only requires a two-layer host PCB implementation • FCC 15.247, IC RSS-210, and IC RSS-Gen certified • Compliant with ETSI EN 300 328 V1.9.1 •... -
Page 6: Applications
• Power Management: Power management ensures a stable supply for the internal functions, as well as providing means for a low-power sleep mode. Item Part Number Manufacturer Type Gain (dBi) Integral part of A43364A Anaren Integral antenna 66089-2406 Anaren Monopole whip, 6mm lead 66089-2430 Anaren Monopole whip, 30mm lead... -
Page 7: Approvals And Usage
2. Approvals and Usage A43364x modules meet many national regulations for worldwide Industrial Scientific and Medical (ISM) radio bands use. In particular, the modules have been certified to the following standards listed in this section. 2.1. Product Approvals 2.1.1. U.S.: Federal Communications Commission (FCC) A43364x modules have been tested to comply with the FCC CFR47 Part 15 subpart C “Intentional Radiators”... -
Page 8: Rf Exposure
To satisfy FCC requirements the antenna used with this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter except as permitted by FCC multi-transmitter procedures. The A43364 module is intended for use in mobile devices located at a distance greater than 20cm away from the body. -
Page 9: Ic Labeling Requirements
Manufacturer Type Gain (dBi) Numéro d’article Référence Fabricant Catégorie Gain Integral part of A43364A Integral antenna Anaren Partie intégrante de A43364A Antenne intégrée Monopole whip, 6mm lead 66089-2406 Anaren Antenne monopôle, longueur 6mm Monopole whip, 30mm lead 66089-2430 Anaren Antenne monopôle, longueur 30mm 2.1.2.1. -
Page 10: Rf Exposure
Notice: To satisfy Industry Canada requirements the antenna used with this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter except as permitted by Industry Canada’s multi-transmitter procedures. The A43364 module is intended for use in mobile devices located at a distance greater than 20cm away from the body. -
Page 11: Europe: Conformité Européenne (Ce)
2. Approvals and Usage 2.1.3. Europe: Conformité Européenne (CE) A43364x modules have been certified for use in European countries covered by ETSI regulations. The following tests have been performed and the module has been found to be compliant to the requirements: •... -
Page 12: Classic Bluetooth
2. Approvals and Usage 2.2.2. Classic Bluetooth ® Classic Bluetooth divides the 2.402-2.480 GHz band into 79 channels, each of which is 1MHz wide. However, since Bluetooth changes channels rapidly (up to 1600 times a second), it is unlikely to cause continuous interference in a specific channel and can be overcome by implementing a simple acknowledge/retransmit functionality. - Page 13 2. Approvals and Usage A43364A with internal antenna (2dBi gain): 802.11b CH10 CH11 Power Level Index (set in software) Measured Output 22.6 22.9 23.9 24.3 24.3 24.3 23.6 21.6 21.1 19.8 18.9 Power (dBm) 802.11g CH10 CH11 Power Level Index (set in software) Measured Output 20.0...
-
Page 14: Europe
54 Mbps MCS0 802.11n MCS7 Table 3: A43364 Module Peak TX Current Consumption Please note that the specified current consumption numbers are for radio operation only and do not include other MCU peripherals. 2.3.2. Europe For Europe, the maximum allowed output power is 20dBm with a spectral power density limit of 10dBm/MHz. - Page 15 2. Approvals and Usage A43364C with external antenna (3dBi gain): 802.11b CH10 CH11 Power Level Index (set in software) EIRP (dBm) 17.4 17.0 17.0 17.0 17.0 17.0 17.1 17.1 17.1 17.1 17.1 802.11g CH10 CH11 Power Level Index (set in software) EIRP(dBm) 17.2 17.1...
-
Page 16: Electrical Characteristics
3. Electrical Characteristics 3.1. Absolute Maximum Ratings Under no circumstances shall the absolute maximum ratings given in Table 5 be violated. Stress exceeding one or more of the limiting values or exposure to maximum rating conditions for extended periods may cause permanent damage to the device. -
Page 17: Digital I/O Characteristics
3. Electrical Characteristics 3.3. Digital I/O Characteristics Parameter Unit Comments (except GPIO_1, GPIO_2, GPIO_3, GPIO4) 0.35xVDDIO VDDIO=1.8V (GPIO_1, GPIO_2, GPIO_3, GPIO4) VDDIO=3.3V (except GPIO_1, GPIO_2, GPIO_3, GPIO4) 0.65xVDDIO VDDIO=1.8V (GPIO_1, GPIO_2, GPIO_3, GPIO4) VDDIO=3.3V (except GPIO_1, GPIO_2, GPIO_3, GPIO4) VDDIO=1.8V 0.45 (GPIO_1, GPIO_2, =+2mA... -
Page 18: Pin Description
3. Electrical Characteristics 3.5. Pin Description Function Name GPIO UART Timer Other SPI1_SCK I2S1_CK I2C2_SDA PB3/JTDO-SWO GPIO USART1_RX TIM2_CH2 JTDO/TRACESWO SPI3_SCK I2S3_CK I2C4_SDA SPI1_MISO PB4/JTRST GPIO I2S3ext_SD I2C3_SDA TIM3_CH1 JTRST SPI3_MISO SPI1_NSS I2S1_WS TIM2_CH1 PA16/JTDI GPIO USART1_TX JTDI SPI3_NSS I2S3_WS TIM2_ETR PA14/JTCK-SWCLK GPIO JTCK/SWCLK... -
Page 19: Internal Connections Between The Radio And The Microcontroller
3. Electrical Characteristics Function Name GPIO UART Timer Other TIM2_CH1 TIM2_ETR GPIO USART2_CTS ADC1_0 WKUP1 TIM5_CH1 TIM8_ETR PC15/OSC32_OUT GPIO OSC32_OUT PC14/OSC32_IN GPIO OSC32_IN I2C1_SCL TIM4_CH3 GPIO SPI5_MOSI I2S5_SD CAN1_RX I2C3_SDA TIM10_CH1 I2C1_SDA TIM4_CH4 GPIO SPI2_NSS I2S2_WS CAN1_TX I2C2_SDA TIM11_CH1 GPIO USART1_RX I2C1_SDA TIM4_CH2... -
Page 20: Recommended Layout
• If the design is using an external antenna via the U.FL connector, it is okay to overlap the antenna area with copper. However, the design with an external antenna needs to meet appropriate regulatory requirements depending on the target geography, such as FCC, IC, MIC/TELEC, etc. Contact Anaren for additional information. -
Page 21: Radio Module Details
3. Electrical Characteristics 3.7. Radio Module Details (dimensions in mm) 3.7.1. A43364A Figure 8: A43364A Dimensions 3.7.2. A43364C Figure 9: A43364C Dimensions... -
Page 22: Packaging Details
3. Electrical Characteristics 3.8. Packaging Details (dimensions in mm) A43364x modules are available in either matrix tray or tape-and-reel packaging for high-volume assembly. Details of packaging are provided below. 3.8.1. Matrix Tray Packaging Figure 10: A43364AxxGM and A43364CxxGM Matrix Tray Packaging Detail (27/Tray) 3.8.2. -
Page 23: Soldering
3. Electrical Characteristics 3.9. Soldering A43364x modules may be mounted either manually (for prototyping), or automatically for production. A no-clean tin/silver/copper (SAC) solder is recommended, however, lead-based no-clean pastes may also be used. CAUTION: A43364x modules are designed for no-clean fluxes only. DO NOT use water-based fluxes that require aqueous cleaning after solder. - Page 24 3. Electrical Characteristics Figure 12: Classification Reflow Profile Package Thickness Volume mm <350 Volume mm ≥350 <2.5mm 240+0/-5°C 225+0/-5°C ≥2.5mm 225+0/-5°C 225+0/-5°C Table 11: SnPB Eutectic Process - Package Peak Reflow Temperatures Package Thickness Volume mm <350 Volume mm 350-2000 Volume mm >2000 <2.5mm...
-
Page 25: Document History
Document History Date Author Change Note No./Notes 1/16/17 Chilbert Submitted final manual... - Page 26 Attach distributor contact information here If you have additional questions, would like samples, or would like a quote, please contact the Anaren AIR team at AIR@anaren.com For a complete list of our franchised distributors, please visit the Anaren website at: www.anaren.com/air...
