Summary of Contents for THERACYCLE THERACYCLE
- Page 1 Theracycle User’s Manual The Theracycle Company 31 Hayward Street, Franklin MA 02038 1-800-367-6712 www.theracycle.com...
-
Page 2: Table Of Contents
Quick Start Guide................13 Quick Start Guide................14 The Value of Exercise..............16 Basic Guidelines for Theracyclists ............16 For Beginning Theracyclists............17 For More Experienced Theracyclists..........17 Maintenance of your Theracycle............19 Limited Warranty for the Theracycle ...........20 Theracyclist User’s Log..............21 Theracyclist User’s Log..............22 1-800-367-6712 www.theracycle.com... - Page 3 Congratulations on your purchase of the Theracycle and your commitment to making it part of your exercise routine! Whether you have been exercising consistently over the years or are just getting started, the Theracycle is designed to help you get exercise the easy way.
-
Page 4: Important: For Your Safety
This unit is equipped with a special motor and no substitute should ever be used. 7. Never attempt to get off the Theracycle until it has come to a complete stop. 8. Use only genuine Theracycle parts when making repairs. - Page 5 13. Do not wear pants, which are loose at the bottom when riding the Theracycle. 14. Turn off the Theracycle with the switch located on the bottom front when not in use. 15. Do not keep the Theracycle at temperatures below 55 degrees Fahrenheit, as cold temperature will affect the performance of the Theracycle’s electronics.
-
Page 6: Theracycle Parts And Components
Theracycle Parts and Components Seat and Back Support Outrigger Handles Seat Adjustment Latch Seat Height Adjustment Knob Theracycle Shroud (gearbox cover) and Filler Cap Handlebar Assembly, Fork Computer Display Stand Computer Display Pedals, Pedal Crank and Link On/Off Switch Theracycle Motor 1-800-367-6712 www.theracycle.com... -
Page 7: Unpacking And Assembling Your Theracycle
• 3/8” wrench (provided) • Heavy-duty scissors or knife for cutting plastic straps and cardboard box Remove the cardboard cross support that is on the top of the Theracycle. Cut down the four corners of the box to expose the Theracycle. Inside the large box is the: •... - Page 8 DO NOT TIP the Theracycle on its side. Next, to add the gear oil to the gearbox: • Remove the 3/4” inch plastic cap on the top of the Theracycle shroud, exposing the oil filler plug. • Using a flat head screwdriver, loosen the filler plug.
- Page 9 • Tighten it. This is an important safety step as this safety screw will limit the distance the seat will travel forward and backward. Now that you have assembled the Theracycle, you will need to adjust it for a customized fit. In the section labeled, “Adjusting Your Theracycle,” you will find the directions, which allow you to do this.
-
Page 10: Adjusting Your Theracycle
If it is not adjusted to your satisfaction, follow these directions: 1. (Note: you must be off the Theracycle to raise or lower the seat.) Locate the seat height adjustment knob located below and behind the seat. - Page 11 2. Remove the entire seat by pulling up on the latch knob while pulling the seat away from the Theracycle. 3. Turn the seat over and remove the four bolts on the bottom of the seat with the Allen wrench, reposition in the desired holes, and replace the bolts.
-
Page 12: Handlebar Adjustment
3. IMPORTANT: Bolt must be firmly tightened clockwise so that it is safely secured. Pedal Strap and Pedal Crank Adjustment On the Theracycle, you can adjust the size of the arc you are pedaling by adjusting the angle of the pedal link. You can also adjust the size of the pedal strap. -
Page 13: Theracycle Computer Display
Theracycle Computer Display 1-800-367-6712 www.theracycle.com... -
Page 14: Quick Start Guide
Quick Start Guide 1. Plug the Theracycle power cord into a three prong, grounded outlet. 2. Turn on the power switch located underneath the front right bottom of the Theracycle, underneath the motor. 3. Get comfortably seated and make sure that both feet are placed securely on the pedals in the pedal straps. - Page 15 If you wish to keep track of your daily workout, you’ll need to write this information down in your Theracycle exercise log before the screen is terminated. Congratulations! 15. Shut off the Theracycle with the switch located on the bottom front of the control box, located below the motor. 1-800-367-6712...
-
Page 16: The Value Of Exercise
The Value of Exercise If you are like many of our Theracycle owners, exercise is important to you, but it has been a while since you were able to get the kind of exercise you want. The key to success is to make exercise a regular and enjoyable part of your everyday life. -
Page 17: For Beginning Theracyclists
• Experiment with the three variables: time, speed, and effort level, as you gain experience with the Theracycle. Remember, you can program the Theracycle for rides lasting up to 99 minutes and at speeds up to 15 miles per hour, and you can vary your effort level, depending on how hard you work. - Page 18 Theracycle do the work. Even if you can’t push/pull, or pedal, you will still benefit from a Theracycle workout.
-
Page 19: Maintenance Of Your Theracycle
Maintenance of your Theracycle The Theracycle is designed to be nearly maintenance free for years of normal use. All of the bearings in the machine have been sealed and permanently lubricated. • Every five years, with normal home use, it is advisable to replace the oil in the gearbox. -
Page 20: Limited Warranty For The Theracycle
• Electronic components (computer display and control box), and the motor are covered for one year from the date of original purchase. • All other parts of the Theracycle are covered for three years from the date of original purchase.
