Z90 SPECIFICATIONS
MECHANICAL
SIZE:
5.3" x 3.0" x 2.0" [135mm x 76mm x 51mm]
WEIGHT:
16oz. [454g]
MOUNTING:
Two: 1/4"-20 Socket
ELECTRICAL
INPUT:
7-24V DC
DC PLUG:
Positive Locking Type
OD: 5.5mm, ID: 2.1mm
AC ADAPTER:
100-240V, 50-60Hz
POWER:
30W max. [2.5A max. @ 12V]
WIRELESS FREQ:
2.45GHz
CHANNELS:
10
OUTPUT
BEAM ANGLE:
60° 2Ө ½-intensity, 130° total
DIMMING:
1% - 100%
PRESETS:
White Mode - Two: Daylight, Tungsten
Gel Mode - 2500°K
Color Mode - Two: User defined
LED LIFE:
50,000 Hrs. min. before factory re-calibration
THE ZYLIGHT Z90 IS PROTECTED BY THE FOLLOWING U.S. AND FOREIGN PATENTS
WITH OTHER U.S. AND FOREIGN PATENTS PENDING:
US 6,608,453
US 6,777,891
US 6,016,038
US 6,150,774
US 6,211,626
US 6,788,011
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modifications not expressly approved
by the party responsible for compliance could void the user's authority to operate the equipment.
Per FCC 15.105(a), Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accor-
dance with the instruction manual, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Zylight LLC
PO Box 54
Chelmsford, MA 01824
+1-978-244-0011
www.zylight.com
© Copyright 2003-2007 Zylight LLC. All rights reserved. 24-07002 Rev. 1
↔
±
9000°K in 50°K steps,
GREEN
US 6,340,868
US 6,806,659
CA 2,302,227
EP 1 016 062 B1
AU 757000 B2
HK 1025416
DE 698 07 092 C0
Z90
Intelligent LED Light
USER GUIDE
