Summary of Contents for LH Technologies LH 500
- Page 1 OPERATORS MANUAL FOR THE LH ”INTELLITRAM” 500 LH No. 020-505-UK Version 1.00 LH Technologies Denmark ApS Mølhavevej 2 9440 Aabybro Denmark Tlf. +45 9696 2500 Fax. +45 9696 2501 Internet: http://www.lh-agro.com/...
- Page 2 LH ”I ” 500 O NTELLITRAM PERATORS MANUAL LH A...
-
Page 3: Table Of Contents
NTELLITRAM PERATORS MANUAL ONTENTS Contents INTRODUCTION .........................5 OVERVIEW .........................7 OPERATING THE LH 500 ....................8 HOLD KEY (POS. 1) ....................8 FUNCTION SELECTION KEY (POS. 2)..............8 MENU KEY (POS. 3)....................8 ARROW KEYS (POS. 4) .....................8 ENTER KEY (POS. 5) ....................9 ESCAPE KEY (POS. 6)....................9 CLEAR KEY (POS. - Page 4 LH ”I ” 500 O ONTENTS NTELLITRAM PERATORS MANUAL EMPTY HOPPER....................15 KG LEFT .......................15 FAN SPEED......................15 MACHINE SETTINGS ....................15 WORKING WIDTH....................15 FORWARD SPEED SENSOR ................16 AUTOMATIC FORWARD SPEED CALIBRATION..........16 IMPLEMENT SENOR ...................16 RPM SENSOR ......................17 NUMBER OF ROWS ....................17 ROWS IN TRACK ....................17 RETURNS......................18 STOPWATCH .......................18 INFO ..........................19...
-
Page 5: Introduction
LH ”I ” 500 O NTELLITRAM PERATORS MANUAL NTRODUCTION INTRODUCTION Thank you for choosing a LH product. Whilst developing the LH ”Intellitram” 500 we have tried to create an advanced product that, at the same time, is easy to operate. The LH ”Intellitram”... - Page 6 This manual may not be altered, copied or manipulated in any way. Unoriginal manuals can lead to operational faults damaging machines or crops as a consequence thereof. LH Technologies Denmark ApS can therefore not be held responsible for damages incurred, which can be traced to the use of unoriginal or manipulated manuals.
-
Page 7: Overview
LH ”I ” 500 O NTELLITRAM PERATORS MANUAL ENERAL OPERATION OVERVIEW Menu Pos. Description Hold key Function selection key Menu key Arrow keys Enter key Escape key Clear key Program keys Cursor LH A... -
Page 8: Operating The Lh 500
LH ”I ” 500 O ENERAL OPERATION NTELLITRAM PERATORS MANUAL OPERATING THE LH 500 HOLD KEY (POS. 1) Description Pressing this key stops the bout number from being counted. The implement can be lifted without the bout number changing. This function is typically used if the seed drill must be raised for an obstruction. -
Page 9: Enter Key (Pos. 5)
LH ”I ” 500 O NTELLITRAM PERATORS MANUAL ENERAL OPERATION ENTER KEY (POS. 5) Description The enter key is used to accept encodements and to return to the previous screen. ESCAPE KEY (POS. 6) Description Use this key to return to the previous menu without saving the value. -
Page 10: Operation
LH ”I ” 500 O PERATION NTELLITRAM PERATORS MANUAL OPERATION Pressing the MENU key, regardless of where you are in the program, shows the operating screen. The operating screen is always displayed when the computer is switched on. Correct operation presupposes that all encodements/calibrations have taken place (see page 13). -
Page 11: User Selectable Operation Functions
LH ”I ” 500 O NTELLITRAM PERATORS MANUAL PERATION USER SELECTABLE OPERATION FUNCTIONS Repeatedly pressing the FUNCTION SELECTION key pages through the available operation functions. Each individual function is described in the following: FORWARD SPEED Description The present forward speed shown in kilometres per hour. AREA Description The worked area since the last reset (see page 19), displayed in ha. -
Page 12: Kg Left
LH ”I ” 500 O PERATION NTELLITRAM PERATORS MANUAL KG LEFT Description The amount remaining in the seed hopper (presupposes that the amount filled into the hopper has been encoded, see page 13). KG/HA Description The present seed rate shown as kg/ha. DISTANCE Description The driven distance since the last reset (see page 19). -
Page 13: Encode
LH ”I ” 500 O NTELLITRAM PERATORS MANUAL ENCODE The encodement menu is selected from the main menu (press the menu key). Use hereafter the ARROW UP and ARROW DOWN keys to mark “Encode”. Press thereafter the ENTER key. The same principle is used to select the individual encodement menus. -
Page 14: Calibration
LH ”I ” 500 O NCODE NTELLITRAM PERATORS MANUAL CALIBRATION GRAM/PULSE The weight, in gram, per pulse can be encoded directly if known. NEW CALIBRATION The procedure for calibration is thus: 1. Move the cursor to “New calibration” and press the ENTER key. 2. -
Page 15: Drill Shaft
LH ”I ” 500 O NTELLITRAM PERATORS MANUAL NCODE DRILL SHAFT The drill shaft warning is given if the drill shaft stops rotating. Encode whether the warning is active (on) or not active (off). Use the program keys 1 & 2 to switch the warning on or off. On most seed drills the drill shaft can be adjusted to rotate very slowly (1 rev. -
Page 16: Forward Speed Sensor
LH ”I ” 500 O NCODE NTELLITRAM PERATORS MANUAL FORWARD SPEED SENSOR Selection of the forward speed sensor plus the speed calibration figure can be encoded here. It is also possible to automatically calibrate the forward speed sensor. Description Pressing this key (program key 1) selects Radar as the speed sensor (via the 7-pin DIN/ISO socket). -
Page 17: Rpm Sensor
LH ”I ” 500 O NTELLITRAM PERATORS MANUAL NCODE RPM SENSOR The number of pulses per revolution for the following rpm sensors is encoded her: Clutch left, clutch right, drill shaft and fan. NUMBER OF ROWS Encode the total number of rows on the seed drill. ROWS IN TRACK Encode the number of rows closed, per track, when tramlines are made. -
Page 18: Returns
LH ”I ” 500 O NCODE NTELLITRAM PERATORS MANUAL RETURNS Only on pneumatic seed drills. Description If the seed to the closed rows (when making tramlines) is returned to the hopper then select on. If the seed to the closed rows (when making tramlines) is distributed to the other rows then select off. -
Page 19: Info
LH ”I ” 500 O & D NTELLITRAM PERATORS MANUAL DELETE INFO The information menu gives an overview of different encodements and is selected from the man menu (press the MENU key). Use the ARROW UP and ARROW DOWN keys to mark “Info”. Press thereafter the ENTER key. Pressing the ARROW UP and ARROW DOWN keys pages through the following two screens: Info... -
Page 20: The Counters In A Task
& D LH ”I ” 500 O DELETE NTELLITRAM PERATORS MANUAL THE COUNTERS IN A TASK The screen to the left is displayed Trip counter when the “Data/delete” menu is 1/10 selected. A description of each individual counter follows: New counter Delete counter Time 0:00:00... -
Page 21: Resetting A Task
LH ”I ” 500 O & D NTELLITRAM PERATORS MANUAL DELETE RESETTING A TASK If the counters in a task are to be reset, select the task as described above and highlight “Delete counter”, press thereafter the ENTER key. LH A... -
Page 22: System
LH ”I ” 500 O YSTEM NTELLITRAM PERATORS MANUAL SYSTEM The system menu is selected from the main menu (press the MENU key). Use the ARROW UP and ARROW DOWN keys to highlight “System” and press the ENTER key. CONTRAST/LIGHT Description Pressing this program key will make the screen lighter. -
Page 23: Test
LH ”I ” 500 O NTELLITRAM PERATORS MANUAL YSTEM TEST TEST INPUT Test input can be used if Directly under each input description, to the right, is a counter that registers the number of time the input has been activated (the counter is reset automatically each time “Test input”... -
Page 24: Tramlining Rhythms
LH ”I ” 500 O NTELLITRAM PERATORS MANUAL RAMLINING RHYTHMS TRAMLINING RHYTHMS There are many different possible combinations of different drill widths and cultivating equipment. To meet these needs the following tramlining rhythms are available. SYMMETRIC TRAMLINING RHYTHMS Common for all symmetric tramlining rhythms is that the shut off mechanisms are fitted symmetrically on the middle of the machine. - Page 25 LH ”I ” 500 O NTELLITRAM PERATORS MANUAL RAMLINING RHYTHMS Rhythm 8S: Rhythm 9S: Rhythm 10S: Rhythm 11S: Rhythm 12S: Rhythm 13S: Rhythm 14S: LH A...
-
Page 26: Right/Left Tramlining Rhythms
LH ”I ” 500 O RAMLINING RHYTHMS NTELLITRAM PERATORS MANUAL Rhythm 15S: Rhythm 16S: Rhythm 17S: RIGHT/LEFT TRAMLINING RHYTHMS Common for the following tramlining rhythms is that the shut off mechanisms are fitted on either the left- or the right-hand side of the machine. The width of the equipment divided by the seed drill width must be an equal number. - Page 27 LH ”I ” 500 O NTELLITRAM PERATORS MANUAL RAMLINING RHYTHMS Rhythm 4 left/right: Shut off = right side, start the field on the right-hand side. Shut off = left side, start the field on the left-hand side. Rhythm 6 left/right: Shut off = left side, start the field on the right-hand side.
- Page 28 LH ”I ” 500 O RAMLINING RHYTHMS NTELLITRAM PERATORS MANUAL Shut off = right side, start the field on the left-hand side. Rhythm 12 left/right: Shut off = left side, start the field on the left-hand side. Shut off = right side, start the field on the right-hand side. Rhythm 14 left/right: Shut off = right side, start the field on the left-hand side.
-
Page 29: Special Tramlining Rhythms
LH ”I ” 500 O NTELLITRAM PERATORS MANUAL RAMLINING RHYTHMS Rhythm 18 left/right: Shut off = right side, start the field on the left-hand side. Shut off = left side, start the field on the right-hand side. SPECIAL TRAMLINING RHYTHMS Rhythm 28 Left: 3 metre seed drill/28 metre cultivating equipment. - Page 30 LH ”I ” 500 O RAMLINING RHYTHMS NTELLITRAM PERATORS MANUAL Rhythm 50 Left: 6 m seed drill/15 m equipment or 8 m seed drill/20 m equipment. Shut off = 2 x right & 2 x left side, start the field on the left-hand side. Rhythm 51 Right: 6 m seed drill/15 m equipment or 8 m seed drill/20 m equipment.
- Page 31 LH ”I ” 500 O NTELLITRAM PERATORS MANUAL RAMLINING RHYTHMS Rhythm 54 Left: 6 m seed drill/20 m equipment. Shut off = 1 x right & 2 x left side, start the field on the left side. Rhythm 55 Right: 6 m seed drill/20 m equipment.
- Page 32 LH ”I ” 500 O RAMLINING RHYTHMS NTELLITRAM PERATORS MANUAL Rhythm 61/63 Right: 6 m seed drill/28 m equipment. Shut off = 2 x right & 1 x left side, start the field on the right-hand side. LH A...
