    Liquid Crystal Display LCD2-80 Instruction Manual Document 53242 10/25/2012 Rev: P/N 53242:B1 ECN 12-0233...
  • Page 2 Adequate written records of all inspections ing with matches (especially in bedrooms), smoking in should be kept. LCD2-80 Instruction Manual — P/N 53242:B1 10/25/2012...
  • Page 3: Installation Precautions

    HARSH™, NIS™, and NOTI•FIRE•NET™ are all trademarks; and Acclimate® Plus, FlashScan®, NION®, NOTIFIER®, ONYX®, ONYXWorks®, UniNet®, VeriFire®, and VIEW® are all registered trademarks of Honeywell International Inc. Echelon® is a registered trademark and LonWorks™ is a trademark of Echelon Corporation.
  • Page 4 • Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. LCD2-80 Instruction Manual — P/N 53242:B1 10/25/2012...
  • Page 5: Table Of Contents

    3.3.2: Point Labels Tab .................18 Section 4: Operating the LCD2-80........19 4.1: Displays .....................19 4.1.1: Terminal Mode................19 4.1.2: ACS Mode ..................19 4.1.3: Communications Failure Reporting ..........20 4.2: Buttons....................21 Appendix 5: EIA-485 Shield Terminations......22 LCD2-80 Instruction Manual — P/N 53242:B1 10/25/2012...
  • Page 6: Section 1: Product Overview

    864 9th Edition. The following products have not received UL 864 9th Edition certification and may only be used in retrofit applications. Operation of the LCD2-80 with products not tested for UL864 9th Edition has not been evaluated and may not comply with NFPA 72 and/or the latest edition of UL 864. These applications will require the approval of the local Authority Having Jurisdiction (AHJ).
  • Page 7: 2: Programming Features Subject To Ahj Approval

    • EIA-485 connects to control panel terminal port. • No programming necessary — mimics the host control panel. • In ACS Mode: • The LCD2-80 supplies a means to display a subset of the panel message text, or to display custom messages programmed using VeriFire Tools.
  • Page 8: Board Layout

    • AC Fail (Piezo ON): 45 mA • AC Fail (Piezo OFF): 28 mA • Alarm (Piezo ON): 98 mA • Alarm (Piezo OFF): 85 mA Include these currents in your power supply loading and battery calculations. LCD2-80 Instruction Manual — P/N 53242:B1 10/25/2012...
  • Page 9: Connections

    16 for TB2 connection illustrations. Power Connections (TB1) The LCD2-80 can be powered by a +24 VDC power supply listed for fire protective signalling use that is power limited and regulated with a voltage range of +17 VDC to +28 VDC. Power can also be provided by an FACP with an integral power supply as long as the LCD2-80 is listed for use with the FACP.
  • Page 10: 2: Nup Connection - J3

    Product Overview Switches and Indicators From Main Power Supply (-) Common (+) 24 VDC Power LCD2-80 (+) (-) To next LCD2-80 Figure 1.3 Supplying Power to the LCD2-80 24 VDC (+) Common (-) FCPS-24S6/8 TB4-9 TB4-10 TB10 Nonresettable 24VDC+ TB10 Nonresettable 24VDC-...
  • Page 11: 2: Piezo

    Set OFF when not connected to PC for updating LCD2-80 firmware. ACS Mode: When the LCD2-80 is set for ACS Mode (switch 3-6 is set to ON), and it will be used in receive-only mode, switch 3-5 must be set to ON. Otherwise, set to OFF.
  • Page 12: Section 2: Terminal Mode Configuration

    For 3-3, 3-5, 3-6, 3-7 and 3-8, set as follows for Terminal Mode: 3-3 - Set ON if this LCD2-80 is being used with an ONYX panel. Set OFF if it will be used with a legacy panel.
  • Page 13: Terminal Mode Eia-485 Connections

    • Maximum of 32 LCD2-80s may be connected to this circuit. • 6000 feet maximum distance (@ 16 AWG) between the control panel and the first or last LCD2-80 and between each LCD2-80. • Use overall foil/braided-shield twisted pair cable suitable for EIA-485 applications, terminated to earth at one end.
  • Page 14 Figure 2.2 Terminal Mode EIA-485 Connections EIA-485 Connections on OUT(-) RET(-) OUT(+) RET(+) LCD2-80 NFS-320, NFS2-640 TB11-2 TB11-4 TB11-1 TB11-3 NFS2-3030, NCA-2 TB9-2 TB9-4 TB9-1 TB9-3 Table 2.1 EIA-485 Control Panel Connections (Terminal Mode) LCD2-80 Instruction Manual — P/N 53242:B1 10/25/2012...
  • Page 15: Section 3: Acs Mode Configuration

    The power-limited EIA-485 interface provided by the control panels will support the installation of devices at up to 32 addresses. Devices other than the LCD2-80 that can be installed at one of the 32 addresses include the ACS, LDM, and SCS modules.
  • Page 16: Acs Mode Eia-485 Connections

    Cabinet Observe the following requirements when connecting the EIA-485 circuit: • The LCD2-80 requires operating power. Connect 24 VDC power to TB1 terminal 3(+) and TB1 terminal 4 (-). Power connections are supervised and power-limited. • The EIA-485 loop can support up to 32 devices on the...
  • Page 17: 1: General Tab

    Starting ACS Circuit Type - SYS: The first eight points will be system points and are not programmable. ACS: The full range of points are available for point programming. LCD2-80 Instruction Manual — P/N 53242:B1 10/25/2012...
  • Page 18: 2: Point Labels Tab

    System Messages - Description: Fixed message titles. The message associated with the description will display on the LCD2-80 when called for by a panel command. Message: These fields are populated with default messages that may be changed by the programmer.
  • Page 19: Section 4: Operating The Lcd2-80

    Terminal mode. *Note: If Acknowledge, Silence, and Reset switches are enabled for system control, access security must be provided by mounting the LCD2-80 in a locked fire alarm cabinet, or annunciator backbox model ABF-1B or ABS- 1TB with AKS-1B key switch option.
  • Page 20: 3: Communications Failure Reporting

    Pressing “Step/Display” will turn on the backlight for 60 seconds. 4.1.3 Communications Failure Reporting If the LCD2-80 fails to receive communications from the panel for a period of over one minute, it will activate its local sounder and display the following message: COMMUNICATIONS FAIL...
  • Page 21: Buttons

    LCD2-80 software version number will briefly be displayed and then the LCD2-80 will return to normal operation. When the LCD2-80 is set for ACS mode, this button may be used to step the display through multiple events. Events types are displayed in the following order;...
  • Page 22: Appendix 5: Eia-485 Shield Terminations

    Never use the shield for grounding purposes. Note on remote power supplies: When the LCD2-80 is powered from a separate power supply, use a separate conductor to connect the main power supply common terminal to the remote power supply common terminal. Disable earth fault detection on the remote power supply.
  • Page 23 Distributor has completed Manufacturer's Return Material Authorization form. The replacement part shall come from Manufacturer's stock and refurbished. FOREGOING DISTRIBUTOR'S SOLE AND EXCLUSIVE REMEDY IN THE EVENT OF A WARRANTY CLAIM. Warn-HL-08-2009.fm LCD2-80 Instruction Manual — P/N 53242:B1 10/25/2012...
