razor slider duo 1200
ceramic top vanity
1200W x 460D x 520H mm
top view of ceramic top
front view
drawer 1
drawer 2
Important!
Use acetic cured silicone sealant. Do not use epoxy type adhesives.
seima.com.au
wall mount or recessed kicker
1200
1200
drawer 3
drawer 4
1185
SCV-SD1200-1
White high gloss vanity with ceramic top
sleek one-piece ceramic benchtop
O
smooth clean lines, no handles
O
non-porous painted white high gloss cabinet
O
durable finishes — easy to clean
O
wall mount or recessed kicker options
O
premium soft-close drawer runners
O
generous storage space
O
allows flexible plumbing
O
Cabinet with one drawer, one-piece ceramic top
configuration
SCV-SD1200-1
product code
O
Kickers that fit:
SCV-SLKICK-43-31
O
SCV-SLKICK-60-31
O
SCV-SLKICK-75-31
O
SCV-SLKICK-90-31
O
Kicker requires assembly.
kicker option
Suits standard 40 mm waste with overflow
waste/overflow
(not supplied)
Refer to installation instructions provided.
installation
Use acetic cured silicone sealant. Do not use epoxy
type adhesives.
All dimensions are nominal and subject to normal
dimensions
ceramic manufacturing variations of ±5mm.
Specifications may vary without notice as part of our
continuous improvement practices.
top cross-section view of cabinet
drawer
1 and 2
1 taphole
430W x 310H x 250D mm
565W x 310H x 250D mm
715W x 310H x 250D mm
865W x 310H x 250D mm
131
drawer
3 and 4
1185
DS-SCV-SD1200-1 | v1.0 | 06-13
Advertisement
Summary of Contents for Seima SCV-SD1200-1
- Page 1 1 and 2 3 and 4 1200 1185 front view 1200 drawer 1 drawer 3 drawer 2 drawer 4 1185 Important! Use acetic cured silicone sealant. Do not use epoxy type adhesives. seima.com.au DS-SCV-SD1200-1 | v1.0 | 06-13...
- Page 2 slider | slider duo vanity cabinet slider .com.au +slider installation guide Important — read this first ! Note: These instructions show a Slider Duo 900 vanity cabinet which has two drawers. However, the instructions apply to all Slider and Slider Duo vanity cabinets and all sizes — the characteristics and drawer mechanisms are the same for all units. 1.1 All Slider and Slider Duo vanity cabinets come assembled with drawers installed.
- Page 3 slider | slider duo vanity cabinet .com.au removing + adjusting drawers remove cover plate #2 (on outside of drawer) To remove the drawer/s Push lever on both sides 5.1 Extend the drawer. of the drawer at the same time. 5.2 Each drawer has a plastic cover plate on each side of the drawer (#1 and #2).
- Page 4 kicker — recessed slider | slider duo | designyo kicker .com.au assembly instructions slider+ slider duo Package contents 1 x long front panel (holes are on panel inner) 4 x locknut screws 4 x locknuts 4 x angle brackets 2 x short side panels (holes are on panel inner) 16 x self-drilling screws Insert locknuts and use a screwdriver to turn the Insert locknut screws into holes of front panel.
