Installation and Operations Manual
March 2000
© Copyright 1999, EXI Wireless Systems Inc. All rights reserved.
Revision 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HALO and is the answer not in the manual?

Questions and answers

Related Manuals for Exi HALO

Summary of Contents for Exi HALO

  • Page 1 Installation and Operations Manual March 2000 © Copyright 1999, EXI Wireless Systems Inc. All rights reserved. Revision 2.0...

  • Page 2: Table Of Contents

    EXI HALO Installation & Operation Manual 981-000003-000 Table of Contents LIMITED WARRANTY..........................4 RECORD OF CHANGES ..........................6 REGULATIONS..........................7 INTRODUCTION ............................8 4.1....................8 BOUT NFANT ROTECTION YSTEM 4.2..........................9 YSTEM OMPONENTS 4.2.1. Door Control Package (Networked) – SR2C01N ................
  • Page 3 EXI HALO Installation & Operation Manual 981-000003-000 HALO CONSOLE (SINGLE STATION) ....................37 8.1......................39 OMPUTER ISPLAY ONVENTIONS 8.2....................40 ONNECTING TO THE OMPUTER 8.2.1. Navigating the Dealer Screens....................... 40 8.2.2. Adding a Floor Plan........................42 8.2.3. Adding System Devices ........................

  • Page 4: Limited Warranty

    Product or Transponder, as the case may be, within 30 days after the date of the original purchase from EXI of the same, or the Product or Transponder, as the case may be, or any part thereof: (a) is damaged by misuse, accident, negligence, lightning, power surge, brown-out, or leaking, damaged or inoperative batteries, or failure to maintain the Product or Transponder as specified or required by EXI;...
  • Page 5 §(i), and (b) understands fully the foregoing limitations concerning the Products and Transponders, including EXI’s limitation on liability described in §5, and agrees to warn, and obtain acknowledgements from, all users thereof of the same.

  • Page 6: Record Of Changes

    EXI HALO Installation & Operation Manual 981-000003-000 Record of Changes October 1999 Combined HALO Installation & Operating Manual and Elevator Manual. March 2000 Added Cabling types and Threshold / RX Sensitivity Switch Adjust. EXI Wireless Systems March 2000 Revision 2.0...

  • Page 7: Fcc Regulations

    EXI HALO Installation & Operation Manual 981-000003-000 FCC Regulations This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 8: Introduction

    The function of the HALO system is to monitor areas within a building for the presence of HALO Tags. A Tag is sensed when it either enters an RF Field that is set up using the EXI HALO Controller (referred to as a Tag in Field or TIF), or when the Tag initiates an alarm signal (referred to as Tag Initiated Communications, or TIC).

  • Page 9: System Components

    EXI HALO Installation & Operation Manual 981-000003-000 4.2. System Components This section describes the various system components required to complete the installation of the HALO system. 4.2.1. Door Control Package (Networked) – SR2C01N Figure 1 - Halo Controller Package 4.2.2. Elevator Package (Networked) – SR2L01N...

  • Page 10: Halo Receiver Package (Networked) - Sr2R01N

    EXI HALO Installation & Operation Manual 981-000003-000 4.2.3. HALO Receiver Package (Networked) - SR2R01N Figure 3 - HALO Receiver Package 4.2.4. Power Supply Individual power supply adapters Model # AR2PS01-024 may be used for each of the Door Control Packages and the Receivers. Alternatively, a Central Power Supply Model # AGECP01-624 has 6 independent inputs, each of which can power one Controller or two Receivers.

  • Page 11: Halo Console

    EXI HALO Installation & Operation Manual 981-000003-000 4.2.5. HALO Console Figure 5 - HALO Computer Package EXI Wireless Systems March 2000 Revision 2.0...

  • Page 12: Installation

    The EXI HALO elements are designed such that many more than the RS-485 limit of 32 Drivers and 32 Receivers can be co-exist on the same network. The baud rate used in the HALO system is 57,600 bps, and therefore in order to avoid data corruption it is important to ensure that a clean signal is always present.

  • Page 13: Cabling Type

    4,000 ft, a RS-485 Repeater will be required to ensure that the system works reliably, or works at all. It is also recommended that a Repeater be used to isolate HALO Elevator Controllers from the main system to minimize noise pick-up and loading of the system.

  • Page 14: System Connection

    981-000003-000 5.3. SYSTEM CONNECTION The figure below shows the details of connecting the various system components together for the HALO system. H a l o C o n t r o l l e r C o n n e c t o r P i n - O u t...

  • Page 15: Door Control

    EXI HALO Installation & Operation Manual 981-000003-000 5.4. DOOR CONTROL The controller chassis may be horizontally or vertically mounted, on a wall, ceiling or shelf and should be mounted so that the front face panel is easily accessible. Since it is preferable to leave the RX antenna attached directly to the controller, the exact location of the controller will affect the reception of the tags and should only be finalized after setting up the field.
  • Page 16 EXI HALO Installation & Operation Manual 981-000003-000 Detection Areas Figure 12 - SRA Antenna Exciter Field A ) G O O D C O V E R A G E B ) P O O R C O V E R A G E...

  • Page 17: Locating The Receiver Antenna

    EXI HALO Installation & Operation Manual 981-000003-000 Take note of the following: • Ensure that no tag can reach the protected area without passing through a field. • The field should not extend into other rooms or areas that are regularly occupied by tags. These tags could keep a controller in a pre-alarm state preventing the door from opening if magnetic door locks are being used.

  • Page 18: Finalize Controller Installation

    RS-485 side of the RIM to the RS-485 network. This may be done by using crimp type connectors, or by means of an EXI TAP box. The Keypad is designed for flush wall mounting in a standard single-gang electrical box. Should surface mounting be necessary, an optional SMB box may be used.
  • Page 19 EXI HALO Installation & Operation Manual 981-000003-000 5.7.1.1. CONTROLLER CONFIGURATION SWITCHES SRA Antenna Adjust “Mode” Switch Transponder Ranges (Not used) J2: Relay function “Option” Switch Both Relays Relay 1 = TIF Relay 2 = TIC active on TIF Threshold / RX...

  • Page 20: Installing Receivers

    EXI HALO Installation & Operation Manual 981-000003-000 5.7.1.3. OPTION SWITCH SETTING Option Function Patient Monitoring Authorized Entry Switch Don’t act on any Tags No Tags are stopped No Tags authorized Act on all Tags All Tags will be All Tags authorized stopped 5.7.1.4.

  • Page 21: Threshold Switch

    EXI HALO Installation & Operation Manual 981-000003-000 Set the threshold such that the Receiver can detect a Tag from about a 25’ radius within the protected perimeter. This detection area is highly dependent on the layout of the floor which in turn influences the placement of the Receivers on that floor.

  • Page 22: Rs-485 Interface Module (Rim)

    Each HALO Controller, Receiver and Elevator Controller needs a RIM to interface to the RS-485 network that terminates at the HALO Computer. The RIMs have a unique serial number that is associated to the locations on the floor plans of the building, so that the computer can correctly show the location of an event occurring on the system.

  • Page 23: Installing Elevator Controllers

    INSTALLING ELEVATOR CONTROLLERS Only one elevator system should be installed per elevator car. When installing an elevator system it is best to coordinate with the local Elevator Company to ensure that the elevator controls are not affected by the HALO installation.

  • Page 24: Controller Cabinet Installation

    981-000003-000 5.10.1. CONTROLLER CABINET INSTALLATION Mount the HALO Elevator Controller Cabinet inside the elevator car. A suitable location for mounting the cabinet would be bolted securely with locking hardware above the ceiling tile of the elevator car, or on top of the elevator car roof.

  • Page 25: Location For Sra-E Exciter Antennas

    EXI HALO Installation & Operation Manual 981-000003-000 should be routed back to the HALO RS-485 Network. It is highly recommended that you employ an RS- 485 Repeater, available from EXI, in the Elevator Control Room to separate the Elevator connections from the main HALO network.

  • Page 26: Elevator Receive (Rx) Antenna

    RX Antenna and mount the antenna to this surface. • Thread the coax cable through the grommet and connect it to the Controller within the HALO Elevator Cabinet. 5.10.4. Audible Alarm Module The Audible Alarm module can be mounted on the elevator “COP”...

  • Page 27: Door Not Closed" Contact

    In order for the system to operate correctly, the contacts supplied with the elevator controls that indicate when the elevator door is open or closed, have to be monitored by the HALO Elevator Controller. These contacts have to be normally open when the doors are open, and closed when the doors are closed. If such a pair of contacts is not available, a suitable set of contacts will need to be installed, as without these the HALO Elevator Controller will not shut off when the elevator doors are closed.

  • Page 28: System Adjustment And Testing

    • In the event that the field appears to be too strong, indicated by the fact that a Transponder is sensed well outside the elevator cab, adjust the “Range Adjust” setting within the HALO Controller located inside the Cabinet to optimize the exciter field (see Threshold setting instructions for HALO Controller in Section 5.7.1.5)

  • Page 29: Pc Networked Installation

    EXI HALO Installation & Operation Manual 981-000003-000 PC Networked Installation (Must have a dedicated Ethernet) 10BASE-T CABLING: • Maximum allowable distance per segment is 100 meters. • Supports 10Mb/s transmission rate. • Uses a Star Topology. • Unshielded Twisted Pair Category 5 cable recommended.
  • Page 30 EXI HALO Installation & Operation Manual 981-000003-000 RJ-45 Connector The 10Base-T media system uses two pairs of wires, which are terminated in an eight-position (RJ-45 style) connector. This means four pins of the eight-position connector are used. The following table shows the RJ-45 connector pin assignments.

  • Page 31: Theory Of Operation

    All Halo tags will transmit their serial number whenever they first enter a field created by a HALO controller. We refer to this type of communication as a TIF (tag in field) for the purpose of brevity. The HALO controller is able to communicate directly with one Tag even if there are multiple Tags in the field since the communication is bi-directional.

  • Page 32: Halo Controller

    See Appendices for details. The HALO controller uses the Door Switch input to disable alarm reporting, when the door is closed. This is known as the Nurse Saver Feature. Although Tags are still detected and reported to a central system, no alarms are annunciated until the door opens.

  • Page 33: Keypad

    EXI HALO Installation & Operation Manual 981-000003-000 Controller Input Switch State Result Unlock In Closed Open Closed Force Door Lock Open Normal Operation Override In Controller Disabled Normal Operation 7.4. KEYPAD The Keypad provides the user with four separate functions.
  • Page 34 Loiter Alarm If the Tag remains in this field for 70 seconds, a “Loiter” alarm is reported at the HALO PC Console and the associated floor button, and device icon, turn red.

  • Page 35: Halo Receiver

    Figure 26 - HALO Receiver Front Panel The HALO Receiver is used for detecting “off body” or Tag Initiated Communication (TIC) conditions, within a building. The Receiver does not have the capability of generating an Exciter Field, as does the HALO Controller.

  • Page 36: Full-Alarm

    EXI HALO Installation & Operation Manual 981-000003-000 are reread. If there are any non-bypassed Tags detected, Full-Alarm will start and the HOST computer will report a Tag Alarm. 7.6.2. Full-Alarm Full-Alarm is indicated locally by a steady Alarm light on the Keypad and the Full-Alarm siren. This alarm will continue until all the Tags leave the detection field or the user requests a Bypass.

  • Page 37: Halo Console (Single Station)

    Console. The EXI HALO Console application is the primary interface for the user, annunciating Alarm information at the same time as logging all activity on the network. The Halo system has three separate security access levels, namely “USER”, “SUPERVISOR” and “DEALER”.
  • Page 38 Figure 28 - Buttons for Dealer and Supervisor modes Both Dealer and Supervisor modes require a User Name and Password for access. Upon entering the correct information in the panel as shown below, the HALO Console enters the appropriate mode. Figure 29 - Dealer Mode User/Password Prompt The User mode only has access to the Floor Plan screen, while the Supervisor mode has access to system Activity, Tag management and Users management screens.

  • Page 39: Computer Display Conventions

    Yellow: Indicated Pre-alarm condition on floor Active Alarm field. Red: Alarm condition on this floor “Accept Alarm” button is active after valid Username and Password are entered. Figure 31 - HALO Console User Screen EXI Wireless Systems March 2000 Revision 2.0...

  • Page 40: Connecting To The Host Computer

    Figure 32 - Host Computer Connections Turn the UPS power switch to ‘ON”, and then power up the computer. After some self-tests, the Microsoft Windows 98 splash-screen will be seen followed by the HALO Console default User screen. 8.2.1. Navigating the Dealer Screens Press on the computer keyboard simultaneously.
  • Page 41 EXI HALO Installation & Operation Manual 981-000003-000 Figure 33 - Dealer Floor Plan Screen Clicking on the “Activity” tab accesses the Activity screen, which lists all events that have been logged in the system. The maximum number of events stored is 14,000 activities, after which any additional events will displace the very first event logged on a First-in-First-out basis.

  • Page 42: Adding A Floor Plan

    Figure 36 - Dealer "User" Screen The “Dealer Only” screen contains a list of all devices present on the HALO network, and allows the addition and deletion of devices as well as the setting up of the communications parameters of the network.

  • Page 43: Adding System Devices

    “C:\Program Files\eXI\Halo\floor plans\” which is the default directory for floor plans set up at the factory. Once a bitmap has been stored in the above location, click on the “Add” button in the Dealer Toolbar. A panel appears as shown below.

  • Page 44: Adding Tags And Users

    Highlight the appropriate node and click “OK” to complete the placement. Figure 42 - Adding Icons for Nodes 8.2.4. Adding Tags and Users Refer to the “HALO Users Guide” for detailed instructions on how new Tags and Users may be added to the system. EXI Wireless Systems March 2000 Revision 2.0...

  • Page 45: Dkx Keypad Programming

    EXI HALO Installation & Operation Manual 981-000003-000 DKX KEYPAD PROGRAMMING The Keypad is pre-programmed for the following: • BYPASS FUNCTION: 1938 • RESET FUNCTION: 1939 To re-Program Keypad: 1) BEGIN programming mode enter: * 382436# 3 beeps indicate a valid program code was entered.

  • Page 46: Appendix A - Weigand Output Specification

    EXI HALO Installation & Operation Manual 981-000003-000 Appendix A - Weigand Output Specification Fields # of bits Even Parity bit (first)1 Parity bit + next 16 bits = 0 Control code used to distinguish message types Door bit 1 = Door open, 0 = Door closed...

  • Page 47: Appendix B - Accessories

    EXI HALO Installation & Operation Manual 981-000003-000 APPENDIX B - ACCESSORIES 11.1. SELECT SOUND MODULE (SSM) The SSM is an audible annunciator that creates two distinct alarms – a general alarm and an urgent alarm. The two active tones are programmed from a selection of 8 tones in each group using DIP switches inside the unit.

  • Page 48: Ann-6L Six Zone Annunciator

    11.2. ANN-6L SIX ZONE ANNUNCIATOR For situations that warrant using the HALO Controller in a stand-alone configuration, without the Computer Console, the ANN-6L may be used as the annunciator panel. The ANN6L is a six-zone central alarm panel, usually mounted at the nursing station, reception or a guard station to monitor the status of up to 6 alarm zones.

  • Page 49: Appendix C - Application Notes

    Controller if it is sensed to be closed when a transponder enters the field. Data is sent to the HALO Computer, but Relays #1 and #2 are not activated (Pins 15 to 20). The outboard relay...

  • Page 50: Ann-6L Switch Configurations

    EXI HALO Installation & Operation Manual 981-000003-000 12.2. ANN-6L Switch Configurations EXI Wireless Systems March 2000 Revision 2.0...
