  • Page 1 User Manual V1.01 Date: 2012/09/03 User Manual UM12090301 Item Contents CANScope, safety on usage, hardware description, Terms PC software, parameters This document is an overview on how to use the Abstract CANScope analyzer. www.zlg.cn Guangzhou ZHIYUAN Electronics Stock Co., Ltd.
  • Page 2 CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual Version Rev. Date Modifications V1.00 2011-09-01 Original Chinese version V1.01 2012/08/31 Revised Chinese version V1.01 2012/09/03 Translated to English User Manual V1.01 Date: 2012/09/03 ©2012 Guangzhou ZHIYUAN Electronics...

  • Page 3: Table Of Contents

    2.1.3 M12 Communication cable ..................4 2.2 Device connections ....................5 Chapter 3: Software Installation ..............6 3.1 Install CANScope software .................. 6 3.1.1 System requirements ....................6 3.1.2 Steps to install the software ..................6 3.2 Software Operations ..................11 3.2.1 Main window ......................

  • Page 4: Chapter 1: Notices On Safety Usages

    Do not use product in any manner other than those specified in the user manual. Do not install substitute parts or perform any unauthorized modification to the product. Please contact Guangzhou ZHIYUAN Electronics Stock Co., Ltd. and return the product to its technical support office for repair and maintenance.

  • Page 5: Power Supply Connection

    Do not use a damaged or broken test lead probe for measurement, it may result in damage to instrument or personnel injury. 1.1.2 Power supply connection The rated values and limits of the CANScope power adapter:  (Input) I/P: 100~240V / 50-60Hz, 0.55A ...

  • Page 6: Chapter 2: Hardware Description

    Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual This chapter introduces the basic functions and operations of the CANScope Analyzer. Reading this chapter can help you quickly understand how to use CANScope Analyzer to perform basic measurement works. 2.1 Hardware interfaces 2.1.1 Front side interfaces...

  • Page 7: Backside Interfaces

    CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual 2.1.2 Backside interfaces Figure 2-2: CANScope backside view  ○ Power switch: turn on/off power supply.  ○ Power supply: 12V DC power adaptor connector.  ○ USB port: High speed port; connect to PC through the provided A-B USB cable.

  • Page 8: Device Connections

    1. Power cable: Plug the power cable to a 220V power outlet, and connect the other side of cable to the power port on the back of the CANScope. 2. USB Cable: Connect the A side of the cable to PC, and the B side to the USB port of the CANScope on its back.

  • Page 9: Chapter 3: Software Installation

    CANScope Analyzer User Manual This chapter demonstrates how to install CANScope software to your computer, the basic function of the PC software for CANScope analyzer, and how to use it to perform basic measurement works. The CANScope software is the PC software for CANScope Analyzer; it can communicate with the analyzer hardware through USB connection, and controls the analyzer to perform operations and measurements.
  • Page 10 Click next to proceed, then the install path window will appear, as Figure 3-3 shows. 2. Set installation path Default path is: “C:\Program Files (x86)\zhiyuan\CANScope”, user can specify a new path for installation. After path setting, click next to proceed.
  • Page 11 3. Start menu settings This window can configure the location of the software icon in “Start menu” the default location is “zhiyuan\CANScope”, user can redefine this location. After this, click next to proceed; as Figure 3-4 shows. Figure 3-4: CANScope setup program: start menu options 4.
  • Page 12 Figure 3-6: CANScope setup program: get ready to install files 6. Start the file installations As Figure 3-7 shows, wait till the installation of software files is complete, an installation complete window will then pop up, click the finish button to finish the installation.
  • Page 13 7. Installation completed Now the installation is completed, as Figure 3-8 shows, If user checked the run CANScope option within the finish window, then the software will be run immediately after the installation of the software. Figure 3-8: CANScope setup program: Installation complete User Manual V1.01...

  • Page 14: Software Operations

    3.2.1 Main window Figure 3-9 shows the main window of the software. Figure 3-9: Main window of the CANScope software Notice: if there is an “offline” quoted after the top middle title of the main software window, it means that the software is not connected with the device, after connection, the quoted content will be “online”.

  • Page 15: Can Messages

    Open CAN message analysis window and configure the data collection settings. Single click on the “ ” button within the “Control” field, then CANScope Step 2: will enter data listening state. Step 3: Configure the frame contents to send within the “Send Frames” field; after this, single click on the “...

  • Page 16: Network And Sharing

    3.2.3 Network and sharing Network and sharing function allows user to share data to the server, allowing other users to access them through server connection. To use CANScope itself as a server, simply configure the corresponding server parameters within the “Server settings” area.
  • Page 17 Step 3: Connect to server settings: including Server IP (default IP is the local IP of CANScope itself), connection port, and connection password (this password should be matched with the server setting). Then click the “Connect” button to establish connect.

  • Page 18: Can Waveform

    CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual 3.2.3.2 Connection List Figure 3-12 shows the connection list, details of a connection can be found in this place. Figure 3-12: Network and sharing: connection list 3.2.4 CAN Waveform This function can display a CAN message in waveform mode.
  • Page 19 CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual ○ Navigation bar: Drag to control the waveform display, allow user to observe the complete waveform. The CAN waveform menu area contains 5 options, which are mode, zooming, position, view, and settings;...

  • Page 20: Can Oscilloscope

    CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual Step 8: Within the display area, right click to bring up the dropdown menu; in its options, user can select “zoom in/zoom out/whole view” to change waveform display. Step 9: Move the cursor to the display area, hold down the [ctrl] key, the cursor will change to “...
  • Page 21 CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual Within Figure 3-16, number 1~2 marks areas with different functions: ○ Menu area: contains basic operations of the CAN oscilloscope function. ○ Display area: display CAN oscilloscope waveforms. 3.2.5.1 Operations Open “Port board”...

  • Page 22: Can Eye Diagram

    CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual Step 11: Within the oscilloscope, right click to bring up the dropdown menu, then select “save as…” option to save the current waveform to BMP, JPEG, GIF, TIFF, and PNG format image files.

  • Page 23: Protocol Analysis

    CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual Single click on the “load pattern” to load eye pattern for comparison. Single Step 4: click on the “match” option to match the eye diagram to loaded pattern. Check the “display pattern”...
  • Page 24 CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual Figure 3-19: Protocol list Within Figure 3-19, there are 4 protocols:  CANopen: CANopen protocol defines the application standard and CAN application layer communication protocol for distributed industrial automation system.
  • Page 25 CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual 3.2.7.2 Operations Run the “protocol analysis” software. Step 1: Open the “Configure parameters” window. By default this window will be Step 2: opened when the protocol software is run. User can open it from the menu “View=>Configure parameters”, or click the “configure parameter”...

  • Page 26: Chapter 4: Parameters

    CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual 4.1 Instrument Table 4-1: CANScope instrument parameters Power supply voltage +12V Power consumption 6W (Max) Current consumption (Max) 500mA@12V Working Temperatures 0~55º C Dimensions (Port connector not included) 18.9cm×4.7cm×17.7cm (W×L×H)

  • Page 27: Oscilloscope

    CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual 4.2.1 Oscilloscope Table 4-3: Oscilloscope parameters Number of Channels Real-time Sampling Rate(Max) 100MSa/s (each channel) Collect 512Mpts Storage Depth Vertical Resolution 8-bit Analogue Bandwidth (-3dB) DC to 60MHz AC Coupling 3.5Hz~60MHz...

  • Page 28: Port Parameters

    CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual 4.3 Port Parameters Table 4-4: Port parameters Transceiver (standard component) P8251T, P1040T Terminal Isolation Transient Communication port Supported Protocol resistor voltage Voltage Supports M12 Connector, compliant CAN2.0A/CAN2.0B 120Ω 2500V...

  • Page 29: Chapter 5: General Features

    CANScope Guangzhou ZHIYUAN Electronics Stock Co., Ltd. CANScope Analyzer User Manual  Power supply: 220V, 50Hz.  Power consumptions: 6W (Max).  Storage temperature: 0º C~55º C.  Working environment: Full precision 0º C~55º C, 80%R.H. no condensing.  Communication Ports: USB2.0 High Speed.

  • Page 30: Rights & Statements

    The defects or bugs of the CANScope Analyzer will be collected to an errata list once they are found by any one. This may cause version difference between products. Latest errata list can be acquire from us if customer requires.
  • Page 31 Company name： Guangzhou ZHIYUAN Electronics Stock Co., Ltd. Address: Floor 2, No.3 Building, Huangzhou Industrial Estate, Guangzhou, CHINA Post code: 510660 Website: http://www.zlg.cn Contact +86-20-22644375 Email: support@zlg.cn...
