- Page 1 Disassembly and Assembly System Dismantle Warning! ▶ - Make sure the system & peripherals power are off. - Disconnect cables for peripherals & DC power input jack from the system. www.hanasis.com...
- Page 2 3. Pull in the direction of the arrow to remove the HDD. 4. Remove the screws(3ea). ※ Please be careful not to damage the cable. 5. Assemble it in the opposite way of dismantling and connect peripheral cables & DC power input jack. www.hanasis.com...
-
Page 3: Memory Module Replacement
Raise the stand at a right angle as shown. stand. 3. Pull in the direction of the arrow to remove the HDD. 4. Remove the HDD-Support after undoing screws (3ea) which ※ Please be careful not to damage the cable. hold the HDD-Support. HDD-Support www.hanasis.com... - Page 4 Disassembly and Assembly MEMORY BOARD T/P,LCD Memory Module Replacement 6. Install new memory as shown in the figure and tighten them with levers at both ends. Memory www.hanasis.com...
- Page 5 2. Remove the Stand after undoing screws (4ea) which hold the Raise the stand at a right angle as shown. stand. 3. Remove the screws(3ea). 4. With reference to the order of the pictures to remove the back cover. www.hanasis.com...
- Page 6 6. Remove the HDD after undoing screws (3ea) which hold the HDD. Disconnect MSR cable. 7. Remove the HDD-Support after undoing screws (3ea) which 8. Refer to the table to remove the board. hold the HDD-Support. ■ Parts List ■ Part Name Main-board Inverter Module MSR-board Power-board Touch-board(4w) Touch-board(5w) www.hanasis.com...
- Page 7 2. Remove the Stand after undoing screws (4ea) which hold the Raise the stand at a right angle as shown. stand. 3. Remove the screws(3ea). 4. With reference to the order of the pictures to remove the back cover. www.hanasis.com...
- Page 8 Remove adhesive tape Ⓒ LVDS cable Ⓓ LED cable and OSD-board cable Ⓔ Internal Speaker cable Ⓚ cable tie 8. Undo screws(4ea) on the side of display bracket. 7. Remove the front cover, and put down a clean place. www.hanasis.com...
- Page 9 2. Carefully cut the middle of cushion tape between LCD and Touch panel where you can see the gap. 3. Remove cushion tape completely on the corners of Touch panel. 4. Also remove cushion tape on the corners of LCD. 5. LCD(End of steel bezel) and Touch panel(inside the yellow line) are attached to match. www.hanasis.com...
- Page 10 Disassembly and Assembly MEMORY BOARD T/P,LCD MSR Removal Remove the screws(2ea). 2. Remove the MSR and Disconnect the MSR cable. www.hanasis.com...
