Summary of Contents for Metropolis 10HP
- Page 1 Installation and User Manual METROPOLIS 10HP MODEL: METROPOLIS 12HP BEFORE INSTALLING AND USING THIS AIR CONDITIONER PLEASE READ ALL INSTRUCTIONS CAREFULLY ...
-
Page 2: Table Of Contents
3.2 REMOTE CONTROL FUNCTIONS…………………...………………..11 3.3 HEATING MODE……………………………………………….………..…..12 3.4 COOLING MODE………………………..…………………………..….…...12 3.5 DRY MODE……………………………………………………………..….……13 3.6 FAN MODE……………………………………………………………..…..….13 3.7 SLEEPING MODE……………………………………………………….…….14 3.8 AUTO MODE……………………………………………………………….….14 3.9 TIMER OFF FUNCTION…………………………………………………….15 3.10 TIMER ON FUNCTION……………………………………………………15 4. METROPOLIS ACCESSORY 4.1 CLEAN CONTACT FUNCTION……………………………..…………….16 4.2 FRESH AIR SYSTEM…………………………………………………..….….17 4.3 WALL PAD FUNCTION……………………………………………………..17 4.4 WALL PAD INSTALLATION……………………………………………….18 4.5 HOT WATER EXCHANGER INSTALLATION………………………..18 4.6 ELECTRICAL HEAT INSTALLATION………………………………..….19 4.7 MULTIDIRECTIONAL AIR SYSTEM…………………...………………19 4.8 SOFT GRATINGS INSTALLATION………………………………………20 4.9 OUTSIDE GRILLE INSTALLTION………...………………………..…...20 4.10 INSTALL AND CHANGE THE BATTERY…….………………..….…21 4.11 MAINTENANCE …………………….……….……..…………………..….21 ... -
Page 3: General Information
1. GENERAL INFORMATION 1.1 INTRODUCTION PLEASE NOTE: Do not dispose of any packaging until the installation of the air conditioner is completed. After having removed the packing, check that all the content is intact and complete. (See list of accessories). In the event of missing parts, contact your retailer. This air conditioner has been designed to cool or heat the air of a room and should only be used for this purpose. The manufacture cannot be held liable for damage caused to property or injury to persons or animals due to incorrect installation, regulation and maintenance or improper use. ... -
Page 4: Receiving The Goods
Repair or maintenance work must be carried out by a service engineer or by qualified technicians in compliance with the instructions given in this booklet. Do not alter the appliance, since hazardous situations could be created while the manufacture of the appliance will not be liable for any damage or injury caused. This instruction booklet is an integral part of the appliance and should therefore be carefully preserved and always accompany the appliance in the event of transfer to another owner or user or another installation engineer. Should the booklet be damaged or lost, please request an additional. ... -
Page 5: Technical Features
METROPOLIS 10HP AND 12 HP is conform to the European directives : • Low voltage 2006/95/EC and with amendments 92/31/EEC and 93/68/EEC. • Electro‐magnetic compatibility 2004/108/EC • Use restrictions of hazardous substances in electrical and electronic equipment 2011/65/EC (RoHS2) • Waste electrical and electronic equipment 2002/96/ EC (WEEE). • Energy consumption indication on the labels of energy related products 2010/30/EU Waste electrical products should be disposed of with household waste. Please recycle where ... -
Page 6: Installation
*The above data could be change without notice in order to improve the performances. STANDARD TEST CONDITIONS –EN 14511‐ OPERATING CONDITIONS IN COOLING AND DEHUMIDIFICATION MODE: ‐Inside 27℃ DB, 19℃ WB ‐Outside 35℃ DB, 24℃ WB OPERATING CONDITIONS IN HEATING MODE: ‐Inside 20℃ DB ‐Outside 7℃ DB, 6℃ WB INSTALLATION 2.1 POSITIONING THE AIR CONDITIONER(P3) To maintain the best performance from your air conditioner, prevent breakdowns or hazards, you must position it correctly. Please follow the guidelines and instruction below in full, as failure to do so could cause potential installation problems. ‐The air conditioner must be installed on an exterior wall that has access to the outside with a minimum of a meters clearance to ... - Page 7 ...
-
Page 8: Drilling The Wall
2.3 DRILLING THE WALL (P5) Please note: If you are drilling the hole above ground floor level, please ensure that an area has been secured and while the holes are drilled the outside area is supervised, until drilling has been completed. INTAKE AND OUTLET HOLES: ‐This operation should be carried out using the proper tools (diamond tip or core borers drills with high twisting torque and adjustable rotation speed). ‐Fasten the template to the wall taking care to check the distance from the floor or ceiling and keep it horizontal by using a spirit level. ‐Use a pilot drill to mark the centre of each core hole to be drilled. Use a core boring head having a diameter of 162mm to drill the two holes for intake and outlet the air. It is recommended that the holes must have a slightly downward inclination of 3‐5 ... -
Page 9: Fastening The Bracket
System “B”: (P9.P10) In case of impossibility to install the drainage pipe as showed on “A” system, please use system “B” to drain the condensate moisture to a suitable place. If use system “B”, please block the black rubber cup from system “A”. ... -
Page 10: Fitting The Air Conditioner On Bracket
2.6 FITTLING THE AIR CONDITIONER ON BRACKET(P13，P14) After checking again that the fastening bracket is securely fastened to the wall, and that any necessary preparations for electric connection and condensate drainage (if it needs) have been made, fasten the air conditioner to its supporting bracket. Lift it up by holding the sides at the bottom. Tilt the air conditioner slightly toward you to ... -
Page 11: Use Remote Control
USE REMOTE CONTROL 3.1 INTRODUCTION OF LCD ICONS Icons Means Icons Means Auto Fan speed Air flow Cooling direction Timer off Timer on ... -
Page 12: Heating Mode
3.3 HEATING MODE Sequence of the operation Press the ON/OFF button “①”, switch on the air conditioner, it will run by memory mode. Press the MODE button “M”, set up the mode to heat “ ”, the air conditioner will run in heating. Press UP “∧” or DOWN “∨” button, to adjust the setting temperature. Press the FAN SPEED button” ”, set up the ... -
Page 13: Dry Mode
3.5 DRY MODE Sequence of the operation Press the ON/OFF button “①”, switch on the air conditioner, it will run by memory mode. Press the MODE button “M”, set up the mode to dry “ ”, the unit will run in dehumidifying. Press UP “∧” or DOWN “∨” button, to adjust the setting temperature. FAN SPEED button is ” ” disable, indoor fan speed always is low in dry mode. ... -
Page 14: Sleeping Mode
3.7 SLEEP MODE Sequence of the operation Press the ON/OFF button “①”, switch on the air conditioner, it will run by memory mode. Press the MODE button “M”, set up the mode to cool” ”, heat” ”, auto “ ”, the air conditioner will run in setting mode. Press UP “∧” or DOWN “∨” button, to adjust ... -
Page 15: Timer Off Function
3.9 TIMER OFF FUNCTION Sequence of the operation Press the ON/OFF button “①”, switch on the air conditioner, it will run by memory mode. Press the MODE button “M”, set up the mode to which you want. Press UP “∧” or DOWN “∨” button, to adjust the setting temperature. Press the FAN SPEED button” ”, set up the fan speed, is ... -
Page 16: Metropolis Accessory
4 METROPOLIS ACCESSORY Metropolis 10 HP and 12 HP , is equipped with some standard accessories and some optional accessories . STANDARD ACCESSORIES : To have access inside the machine please proceed in this way: Proceed to open the plastic cover like below: ‐Move the both sides filter gratings(P15) ‐Take out the 2pcs screws by screw driver. (P16) ... -
Page 17: Fresh Air System
4.2 FRESH AIR SYSTEM Fresh air system is studied to reduce CO2 inside room . This function is necessary for Hotel guest room but also to reduce CO2 inside room where there are many peoples inside . When the fresh air system is open, the air conditioner will change the room air automatically. In this way new clean and fresh air will intake to the room. There is two air fresh level 25 m/3 and 50 m3/h . See 4.1 to take out the plastic cover, cut the ... -
Page 18: Wall Pad Installation
4.4 WALL PAD INSTALLATION ‐The main PCB is on the top of the unit. ‐ It’s possible to connect one wall pad for one machine like below scheme or is possible to connect the a small net system ( 20‐30 machines ) ‐ When you connect a net, and turn on the air conditioner by wall pad, unit 1 would start immediately, and unit 2 would delay 5 seconds, unit 3 would delay 5 seconds from unit 2...The 5 seconds delay is important for the electrical system to avoid over pick current . ‐ Put DIP2 with ON position, PCB is selected with wall pad function. Unit would work only with wall pad, remote control is invalid, and Auto‐restart function is available with wall pad mode. P20 ... -
Page 19: Electrical Heat Installation
4.6 ELECTRICAL HEAT INSTALLATION When it is very cold in winter, and need good heating performance with temperature lower than zero°C. So, electrical heat is suggested to use inside the air conditioner to improve in automatic way the performance . ‐Remove the insulation sponge and EPP ... -
Page 20: Soft Gratings Installation
4.8 SOFT GRATINGS INSTALLATION To fix the external two soft gratings, please proceed as following: Familiarize yourself with the fitting of the grating to the tube before installation. Insert the cords through the centre hole of grating. ... -
Page 21: Install And Change The Battery
4.10 INSTALL AND CHANGE THE BATTERY ‐Open the cover of battery, hold the hook and lightly pull up. ‐Insert the battery (AAA,2pcs), the positive must be same with the mark on the plastic surface. ‐Reinstall the cover of battery. ‐Inspection: if press ON/OFF button “”, no ... -
Page 22: Problem Solving
4.12 PROBLEM SOLVING ‐If the supply cord damaged, it must be replaced by manufacture or its service agent or a similar qualified person in order to avoid a hazard. ‐ The unit has Auto‐restart function. When electrical current is switched off during working mode, the unit would stop working. When electrical current is switched on, unit would work with former working mode automatically, no need to Turn ON the unit by remote control. ‐The max operation temperature for the air conditioner (max cooling: outdoor DB43℃/WB26℃, indoor DB32℃/WB23℃; min heating: outdoor DB‐5℃/WB‐6℃, indoor DB20℃). ‐This appliance is not intended for use by person(including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. ‐Children should be supervised to ensure that they do not play with the appliance. ... - Page 23 ...
