Summary of Contents for XITONG GT06
-
Page 1: User Guide
GPS Vehicle Tracker （GPS+GSM+SMS/GPRS） User Guide ( Version V1.0) GT06 Tracking system: http://en.gpsxitong.com/index.aspx Username: IMEN(ID) Password:123456 1 / 12... - Page 2 Preface This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. The introduction in this book is just for your reference, if product appearance and colors different from the real products, please follow the products. Contents 1．Accessories 2．...
- Page 3 2.8 SOS switch button for emergency calls for help ; 2.9 Internal / external microphone and speakers , remote audio monitoring and voice intercom function ( optional ) ; 2.10 Built-in backup battery ,to achieve illegal cutting line alarm ( optional ) ; .3 .
- Page 4 3.2.4.3 below under car windshield after decorative plates ; 3.2.4.4 car door or inside the column ; 3.2.4.5 inside the electric car / motorcycle shelter beneath the dashboard or rear seat. NOTE : If the metal layer or heat insulating layeris attached below the windshield , it will lower the received GPS signal , resulting in GPS work’s Malfunction , please change equipment installation location.
- Page 5 power installation, choose a separate grounding or grounding , not connected with other common ground . If ACC auto- theft feature is required, being sure to connect the ACC line , the device state to decide whether to enter the ACC fortified state ; Without access ACC line, the vehicle will enter the fortified state , vibration occurs at the maximum security state of the vehicle is running , it will trigger vibration alarm .
- Page 6 Modify the owner password command : password123456 666888 (666888 is the new password ) 4.2 SOS set a specific number Specific number is the alarm number , you can send text messages to increase the terminal commands specific numbers to add numbers , you can add three , 101 is the first , 102 is the second , 103 is the third , in the alarm state , the terminal will send thePositioning information or help to a specific number ( information is based on the needs to be set ) , and the cycle call until the dial up .
- Page 7 4.3.4 shut off phone alarm : pwrcall123456, 0 ( default ) Reply : pwr call alarm set ok 4.4 ACC alarm settings ( lines need to be properly connected to the ACC ) 4.4.1 ACC ( open start switch by car keys ) in the open state , if it is the auto-arming state , ACC can open to Anti- automatic solution .
- Page 8 Reply : no sossms ok 4.6.3 SOS alarm call open instruction , soscall123456 ( default ) Reply : soscall ok 4.6.4 SOS alarm call close instruction , no soscall123456 Reply : no soscall ok 4.7 Remote monitoring SMS Format: 88 When the owner’s number or a specific number to send this command to the terminal SIM card , call back to achieve the monitoring function.
- Page 9 Displacement alarm settings command : move123456 300 ( default ) Unit : meter Re : move ok 4.12 fortification disarm SMS setting SMS fortification : SF Re : SF OK SMS disarm : CF Re : CF OK 4.13 off the oil and power-offmessage( optional ) When the vehicle was stealed , unsolicited set the off the oil and power-offinstruction by monitoring background, to ensure the safety of the vehicle move, cutting of the stolen vehicle’s oil-way, to achieve that the vehicle can’t be started .
- Page 10 Reply : apnuser ok Set APN corresponding password command format : apnpasswd123456 password Reply : apnpasswd ok 4.19 set the server IP and port : SMS : IP + space + IP address + space + port number Example : IP 219.143.106.193 8500 Re : set IP OK 4.20 -platform applications ( the dealer’s platforms are different, consult your dealer platforms URL ) 4.20.1 Real-time monitoring, network / phone search vehicles GPS + LBS Bi-mode positioning , GPS positioning accuracy of 2 meters , when there is GPS signals...
- Page 11 5.1.2 Whether the SIM card is properly installed , please refer to the installation instructions. 5.1.3 Whether power switch is turned on, the switch in the open edge of the back cover . 5.1.4 Check the LED state , please refer to indicators . 5.1.5 check whether the GPS has located, if not to go outside to the open space for initial positioning.
- Page 12 12 / 12...
