- Page 1 RE866 Interface User Guide 1VV0301387 Rev.0 – 6/16/2017 Mod. 0809 2016-08 Rev.7...
-
Page 2: Notice
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE NOTICE While reasonable efforts have been made to assure the accuracy of this document, Telit assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein. The information in this document has been carefully checked and is believed to be reliable. -
Page 3: Usage And Disclosure Restrictions
USAGE AND DISCLOSURE RESTRICTIONS License Agreements The software described in this document is the property of Telit and its licensors. It is furnished by express license agreement only and may be used only in accordance with the terms of such an agreement. Copyrighted Materials Software and documentation are copyrighted materials. -
Page 4: Applicability Table
APPLICABILITY TABLE PRODUCTS RE866-A1 Page 4 of 17 6/16/2017... -
Page 5: Table Of Contents
Scope ................... 6 Audience..................6 Contact Information, Support ............6 Text Conventions ................7 Related Documents ..............7 BUNDLE OVERVIEW..............8 Setup .................... 8 RE866 Interface without EVK2 ............ 10 Software ..................11 SCHEMATICS ................14 Page 5 of 17 6/16/2017... -
Page 6: Introduction
Scope This document gives an overview of the RE866 interface for EVK2 Audience This document is intended only for Telit customers that wants to integrate the RE866 modules on their application. Contact Information, Support For general contact, technical support services, technical questions and report documentation errors contact Telit Technical Support at: •... -
Page 7: Text Conventions
Tip or Information – Provides advice and suggestions that may be useful when integrating the module. All dates are in ISO 8601 format, i.e. YYYY-MM-DD. Related Documents • 1VV0301365_RE866_AT_Command_Reference • Telit EVK2 User Guide, 1VV0300704 Rev. 19 • RE866 Hardware user guide Page 7 of 17 6/16/2017... -
Page 8: Bundle Overview
) and Telit EVK2 interface board 3990251568 (cod. 3990150474 On the picture below you find a picture of the RE866 interface with the indication of the main component interface Below you can find the Telit EVK2 interface Page 8 of 17... - Page 9 After you plug the interface on top of the EVK and you connect the power cable and USB you will have the system below. Before connecting the power please check that the Power Selector on the interface (J100) has the jumper that close the PINs 1 and 2 of the power selector J100 as in the picture below, leave the others open.
-
Page 10: Re866 Interface Without Evk2
Finally be sure that the USB Jumpers on the EVK2 are selected on USB as in the picture below: RE866 Interface without EVK2 The interface can be used also standalone without mount it on top of the EVK2 but in this case you need and FTDI for the serial connection that is at 3.3Volt and set the power... -
Page 11: Software
The jumper should close the PINs 5 and 6 of the J100 connector and the others open. After that you can power the board externally providing 3.3Volt by the pin 24 (positive) and 23 (negative) on the connector J103 (GPIOs connector) On the pin 15,16,17,18 can be find the RXD, TXD, RTS, CTS PINs at 3.3Volt level. - Page 12 Open a terminal software (TeraTerm in the picture) with 115000 bps, 8, N, 1 and HW flow control enable setting like below: Press Ok and after connect and after that send AT followed by carriage return, you should get OK response as below: You can ask also the SW version with ATi98 and ATi99.
- Page 13 To proceed now you can read the SW AT command user guide where you can find all the instruction to start using LoRa® Note: the numbering of the USB ports can be different, if it in not the last in the numbering try the others with the same serial configuration.
-
Page 14: Schematics
SCHEMATICS Page 14 of 17 6/16/2017... - Page 15 Page 15 of 17 6/16/2017...
- Page 16 Revision Date Changes 6/16/2017 First issue Page 16 of 17 6/16/2017...
- Page 17 Mod. 0809 2016-08 Rev.7...
