Owner's Manual
Take the time to read through this owner's manual.
Familiarity with installation and operation procedures will help you obtain the best
Performance from your new DVD-receiver.

Advertisement

Table of Contents
loading

Related Manuals for Soundstream VRN-65HB

Summary of Contents for Soundstream VRN-65HB

  • Page 1 VRN-65HB 2 DIN 6.2' Monitor DVD/CD/MP3/MP4 Player AM/FM Radio Support Bluetooth Support Mobile Phone link Build in GPS Owner’s Manual Take the time to read through this owner’s manual. Familiarity with installation and operation procedures will help you obtain the best...

  • Page 2: Warning

    WARNING! To promote safety, certain functions are disabled unless the parking brake is on. The Unit is designed to detect parked status and must be connected to the power supply side of the parking brake switch. Improper connection or use of his connection may violate applicable law and may result in serious injury or damage.

  • Page 3: Table Of Contents

    CONTENTS WARNING! ......................... 2 OPERATION PRECAUTIONS ..................2 CONTENTS ........................ 3 ACCESSORIES ......................3 UNIT INSTALLATION AND REMOVAL…………………………………………………...5 WIRING CONNECTIONS ................... 6 PANEL ........................8 REMOTE CONTROL ....................9 REMOVE BATTERY ....................11 MAIN MENU ......................12 RADIO ........................12 DVD PLAYER ......................

  • Page 4: Accessories

    ACCESSORIES Package contains the following accessories for installation and operation of the unit. (1) Washer, Spring 1 each Washer, M5 Nut (2) Mounting Strap (3) Bolt (4) Screw (5) Mounting Collar (6) Release Key (7) Screw (8) Rubber Cushion User Manual GPS cable Warranty card Remote Control...

  • Page 5: Unit Installation And Removal

    INSTALLATION / UN-INSTALLATION Note Before starting installation of the unit, make sure the wiring is connected properly. Use only the parts provided with the unit to ensure proper installation. The use of unauthorized parts may cause malfunction. Install the unit where it does not get in the driver’s way and will not injure the passenger in case there is a sudden stop, like an emergency stop.

  • Page 6: Wiring Connections

    WIRING CONNECTIONS Make sure you have good chassis ground. A good ground connection will eliminate most electrical noise problems. A good chassis ground requires a tight connection to the vehicle’s metal chassis. The area around the ground connection should be clean, bare metal without rust, paint, plastic, dust, or dirt for a good electrical connection.
  • Page 7 Connecting the reversing line to taillight on the car After connecting, when you start up the reverse gear, the unit will receive the picture from car rear view camera. Note: Only use groundless loudspeakers. Use only loudspeakers of minimal 40Watt, using fewer watts may result in damaging your loudspeakers at higher volumes.

  • Page 8: Panel

    FRONT PANEL IR Sensor IR Remote control signal receiving window. Max distance is 6-8 meters, 45 angels. 2. EJECT Button Press to eject a disc. If the disc is not removed for about 10 seconds after eject, the disc is reinserted automatically.

  • Page 9: Remote Control

    REMOTE CONTROL 1. POWER Power on or off. 2. MODE button Press it to select the mode: Radio, DISC (if there is a disc in unit), USB (if there is a USB device in the unit), CARD (if there is a SD/MMC card in the unit) and AV IN. 3.
  • Page 10 11. Cursor buttons Use the buttons to select the menu item, the title track or to show next frame. 12. SETUP button In DVD mode press it to enter the setup menu. 13. EJECT button Press it to eject the disc. 14.

  • Page 11: Remove Battery

    26. OSD button In DVD mode press it to enter the OSD menu, press and hold for 2 seconds to set video setup. (RED /GREEN /BLUE /BRIGHT / CONTRAST /SHARP /COLOR RESET /BACK) 27. VOL- button Press to decrease volume level. 28.

  • Page 12: Main Menu

    MAIN MENU The best way to discover the program is to explore each screen in detail, and to find out how to move from one to another. Read this chapter for a guided tour. Unit starts by displaying the Main menu. This is the root of the screen hierarchy, and you can simply access all features by tapping on the touch screen buttons.

  • Page 13: Dvd Player

    DVD PLAYER To start DVD Player, tap DVD icon from main menu screen. TOUCH SCREEN MENU In DVD mode touch it return to DVD menu. In VCD mode touch it can choose PBC ON or OFF. Touch it to skip to the previous track. Touch it to pause/play.

  • Page 14: Setting Control

    Press it to select songs. Press it to select move or video file. Press it to select pictures. Press it to search USB files. Press it to search song, move, and video or picture files. Press it to turn on / turn off track randomly playback.

  • Page 15: Date Time Setting

    Date Time 24-Hour Time :Turn on or of the 24 hour time. Set Automatically :Turn on or off automaticlly set dateand time. Time Zone:Press it can choose time zone. Navigation Navi Gain: Adjust Navi volume. Dissble media play when navigating: Turn on or off dissble media play when navigating.

  • Page 16: Radio Setting

    Radio Area Radio Area: Can choose radio area Asia, Japanese, Russian, North America and Middle East. GPS Information Radio Area: Can choose radio area Asia, Japanese, Russian, North America and Middle East. GPS SCETION To start GPS mode, please insert SD card in GPS slot on the front panel. Firstly tap SETUP icon on main menu and enter to Navigation setting;...

  • Page 17: Mobile Phone Link Scetion

    MOBILE PHONE LINK SCETION Note: Mobile phone link function can only be available: *Used for Android system phone. Do not support iphone till now. *Set your phone to debug mode. When start to operate phone link function, firstly set the phone to USB debug mode; connect the USB cable with mobile phone;...
  • Page 18 When the unit have connect with phone, the BT icon will turn on and the Mobile phone name (if available) will be display on the panel. According to mobile pairing device manual,after searching new device(SoundStream), select it, input password "0000" and confirm ok, device paring is finished.

  • Page 19: Av-In Mode

    AV IN MODE To start AV-IN Mode, tap on AV-IN button from main menu screen.Connect the external audio/video signal source to this unit. Select AV-IN mode in the main menu. Note: If there is no external video input, the TFT displays “Warning”. OTHER FUNCTIONS Subwoofer Connect the subwoofer to the unit using sub output (see electrical diagram).

  • Page 20: Notes On Disc

    NOTES ON DISC — Only use groundless loudspeakers. — Use only loudspeakers of minimal 40Watt, using fewer watts may result in damaging your loud speakers at higher volumes. — Use 4~8 (Ohm impedance) loudspeakers only; using higher or lesser impedance may damage the unit.

  • Page 21: Troubleshooting

    TROUBLESHOOTING Symptom Cause Remedy Power does not turn Replace with fuse of the same amperage. Fuse is blown If the fuse blows again, consult your store (No sound is of purchase produced.) In correct wiring Consult your local retailer. 1. Turn off the unit. 2.

  • Page 22: Troubleshooting

    TROUBLESHOOTING SYMPTOM CAUSE SOLUTION IF THE POWER SUPPLY IS PROPERLY THE CAR IGNITION IS CONNECTED TO THE CAR NOT ON. ACCESSORY SWITCH THE IGNITION KEY NO POWER TO “ACC”. THE FUSE IS BLOWN. REPLACE THE FUSE. DISC CANNOT BE PRESENCE OF DISC REMOVE THE DISC IN THE PLAYER INSIDE THE PLAYER THEN PUT A NEW UPWARD.

  • Page 23: Technical Specifications

    TECHNICAL SPECIFICATIONS General Power supply: 11~16V DC Current consumption: max. 10 A Maximum power output: 4 x 50W channels (max) DVD/VCD//MP3/MP4/VIDEO/CDDA/PIC Compatible formats: TURE CDCD-R/-RW/DVD±R/±RW PLAYBACK Dimensions (W x D x H) / weight: 178*165*100 mm/2 kg Working temperature range: - +60 ESP function: 10 sec.
  • Page 27 FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
