RS-9710 Operating Instructions
Radio design :
1. Speaker
2. D.C. Jack
3. Band Switch
4. Antenna
5. Hand Strap
6. LCD Display
7. Power
8. Reset
9. Volume Control
10. Sleep/Timer On
11. Mode
12. Night Light
13. Memory/Time Set
14. Earphone Jack
15. Hour/Up Search
16. Key Lock
17. Min/Down Search
18. Frequency Input
19. Battery Compartment
20. 0-9 numeric pad
21. AL. Set/Meter Band Switch
Advertisement
Summary of Contents for ECB RS-9710
- Page 1 RS-9710 Operating Instructions Radio design : 1. Speaker 12. Night Light 2. D.C. Jack 13. Memory/Time Set 3. Band Switch 14. Earphone Jack 4. Antenna 15. Hour/Up Search 5. Hand Strap 16. Key Lock 6. LCD Display 17. Min/Down Search 7.
- Page 2 Battery Installation : Please install 3AA batteries. Please replace batteries when you see the low battery indicator. Band switch : Press the Band Switch button (3) to select different band in the following order : FM – MW – SW1 – SW2 .
- Page 3 Time setting : Under the “off” mode, press the Memo/Time Set (13) button , the number on LCD will blink. Press the HOUR (15) button to set the hour and MIN (17) button to set the minute. Meter Band Switch/ Alarm Set Under the radio mode, you can press the Meter Band Switch (21) to select SW1 or SW2.
- Page 4 Noise Limit Sensitivity FM <= 10uV AM < = 1mV/m SW <= 30uV Single Signal Selectivity >=16dB Power : DC 4.5V or 3 x AA batteries (not included) Speaker : 57mm/16ohm/0.5W Earphone jack : 3.5mm Measurement : 128 x 78 x 28 mm Weight : 200g (excluding batteries)
