- Page 1 Revision 1.1 July 17, 2017 TPM Operation Manual Parameter setting, monitoring and auto data memory for MDC & ADC www.mountztorque.com - 1080 N 11th St - San Jose CA 95112 - 408.292.2214...
-
Page 2: Table Of Contents
Index 1. Main feature 2. Specification 3. Operation 3.1 Connection 3.2 Menu 3.2.1 Standard menu 3.2.2 Setting menu 1) Extended 99 pesets 2) Extended 99 models 3) Communication 4) Barcode 5) I/O 4. Layout drawing 5. Data memory in SD card 6. -
Page 3: Main Feature
- Data auto saving in file system. One file a day / monthly folder, yearly folder - Barcode scanner available to call preset or model - Available for MDC or ADC ( two models ) - 8” TFT LCD with touch screen 2. -
Page 4: Operation
3. Operation 3.1 Connection ParaMon Touch is connected to MDC or ADC controller as below. MDC controller : Serial RS232C ADC drive : Serial RS422 The COM port connection requires the information about COM port, Baud rate and the device ID... -
Page 5: Menu
2 x RS422 There are two RS232C ports on the back side of ParaMon Touch. # RS232C-1 : Labeled as SENSOR. It is connected to the MDC controller To activate RS232C-1 port, select RS232 on Communication1 menu # RS232C-2 : Labeled as RS232. It is connected to the barcode scanner To activate RS232C-2 port, select RS232 on Communication2 menu There are two RS422 ports on the side of ParaMon Touch. -
Page 6: Standard Menu
4. Auto data saving on SD card 5. ParaMon Touch I/O 3.2.1 Standard menu – Parameter, Monitoring & Remote Use the operation manual of MDC or ADC www.mountztorque.com - 1080 N 11th St - San Jose CA 95112 - 408.292.2214... -
Page 7: Setting Menu
There are total 99 presets with 15 standard parameter settings. These presets are saved in ParaMon Touch itself, not in the MDC controller. Whenever the preset is selected from 99 presets, it replaces parameters on the Preset #1 of the MDC controller via RS232C. -
Page 8: Extended 99 Models
There are total 99 models with 10 standard steps. These models are saved in ParaMon Touch itself, not in the MDC controller. Whenever the Model is selected from 99 models, it replaces settings on the Model #1 of the MDC controller via RS232C. -
Page 9: Communication
3) Communication The communication menu manages two RS232C & RS422 ports. One works for connecting to MDC or ADC controller (DR1 & SESNOR). The other works for Barcode scanner or any other device ( DR2 & RS232 ) 2 X RS422 2 X RS232 Communication 1 >... - Page 10 2 X RS422 2 X RS232 Communication 2 > Enable : YES / Type : RS232 or RS422 To connect the RS232 Barcode scanner, select type RS232. And select the same baudrate with the barcode scanner. To connect the RS422 barcode scanner, select type RS422 and ID number.
-
Page 11: Barcode
4) Barcode Once Communication 2 was done with proper setting for the connected barcode scanner, Barcode menu is available to be programed. Click to select the number of preset 1) Key in the Preset or Model number to be selected 2) Key in the barcode data address 3) Click “... - Page 12 5) I/O setting There are 8 inputs and 6 outputs. Pin No Description Factory setting IN 1 Preset / Model #1 IN 2 Preset / Model #2 IN 3 Preset / Model #3 IN 4 Preset / Model #4 IN 5 Preset / Model #5 IN 6 Preset / Model #6...
- Page 13 ◆ 25P I/O schematic 25P D-Sub connector Input #1 Pin 1 Input #2 Pin 2 Input #3 Pin 3 Input #4 Pin 4 Input #5 Pin 5 Input #6 Pin 6 Input #7 Pin 7 Input #8 Pin 8 Input com Pin 22 24V 100mA max.
- Page 14 www.mountztorque.com - 1080 N 11th St - San Jose CA 95112 - 408.292.2214...
-
Page 15: Layout Drawing
4. Layout drawing 6 - M3, 6mm depth hole for mounting www.mountztorque.com - 1080 N 11th St - San Jose CA 95112 - 408.292.2214... -
Page 16: Data Memory In Sd Card
Then the system will detect the update folder and start updating the firmware automatically SD card > update > MD_ParaMonTouch.bin ( firmware file for MDC ) AD_ParaMonTouch.bin ( firmware file for ADC ) www.mountztorque.com - 1080 N 11th St - San Jose CA 95112 - 408.292.2214... - Page 17 [ UI graphic file upgrade ] Save all the graphic files into the following folder name in SD card. Folder name : DWIN_SET Open the top frame of the ParaMon Touch by loosening 3 screws on top And two screws on both top side. Power ON the ParaMon Touch after inserting of SD card.
- Page 18 www.mountztorque.com - 1080 N 11th St - San Jose CA 95112 - 408.292.2214...
