Summary of Contents for Cramer Mower 90
- Page 1 Installation Manual Machine no. Mower Front device for TOURNO pick-up carrier Models Mower 90 TOURNO pick-up mower Original Operation Manual English 3-2014...
-
Page 2: Table Of Contents
List of contents Important general information ........................3 General ........................... 3 Symbols ..........................3 Limitation of liability ........................ 3 Copyright ..........................3 Warranty ..........................3 Safety ................................4 Use in compliance with intended purpose ................4 Possible misuse ........................4 General sources of risks ...................... -
Page 3: Important General Information
Important general information We are pleased that you have selected a mounting device Symbols from Cramer GmbH in Germany. Please read this Manual before you use the device for DANGER ! the first time and observe the notes and safety This symbol cautions against an immediate instructions. -
Page 4: Safety
• The device is only approved for floorings as indicated in the Manual. • Do not remove any covers during operation. • Cramer products may only be operated by staff who was • Immediately remedy any damage to safety devices. instructed in its use or who provided evidence of their... -
Page 5: Design And Function
Design and function Brief description The mower front device may be used as mulcher in combination with the carrier vehicle TOURNO pick-up. The mower is mounted on the TOURNO pick-up and operated through the operating panel. For cleaning purposes, the mower may be tilted upward in a few simple steps. -
Page 6: Overview Bottom
Overview bottom Blade Bolted connection Mulching kit TOURNO pick-up mower Original Operation Manual English... -
Page 7: Operating Elements
Operating elements Lever for V-belt tensioning The V-belt may be removed from the V- belt disk by using the lever. Always secure the lever by a pin inserted in the bore holes. Note! The pin is included in the supply. (Please also refer to 3.5.1) Adjustment lever for setting the mowing height Push lever slightly to the outside and let it engage at the requested... - Page 8 Remove mulching kit For discharging grass, the mulching kit below the mower may be removed. Please proceed as follows: Stop the carrier and remove the ignition key Tilt the mower upward (cf. item 3.5.1) Loosen the three hexagon bolts and remove the washers Now remove the mulching kit You may now tilt the mower back again.
-
Page 9: Functions
Functions Tilt mower upward For better access to the bottom of the mower, the entire mower may be tilted upward. For tilting the mower upward, please proceed as follows: Attention! Stop the carrier and remove the ignition key. Activate parking brake. Set the mowing height to the lowest level (1) using the adjustment lever. - Page 10 Slowly pull the mower towards you as far as possible. Only now tilt the mower upward (inclination approx. 80°) and hold it. Insert the second pin into the bore so that the mower is kept at the top. Important! The bolted connection has to bear in the angle as shown on the right picture. You may now let go the mower.
- Page 11 Tilt mower downward For tilting the mower downward, please follow the procedure below: 1. Hold the mower at the rod and remove the second pin from the bore (picture in 3.5 Functions, no. 1.12). 2. You may now tilt the mower downward and push it back towards the carrier. 3.
-
Page 12: Working Position And Areas Of Risk
Lower the mower. • Move machine across the area to be mown/mulched. • Stop the mower and lift it. 3. Stop the carrier. Please observe the relevant Operation Manual for handling the Cramer carrier. TOURNO pick-up mower Original Operation Manual English... -
Page 13: Maintenance
Maintenance Safety 6.1.2 Check safety precautions Safety precautions comprise: DANGER ! Covers of V-belts. Risk of injury by inappropriately performed maintenance work! The mounting devices must not be operated if the covers show any signs of damage or are removed. They are to be Defective work may result in serious bodily injuries and replaced in case of damage or loss. -
Page 14: Troubleshooting
1 Initiate emergency stop (leave working position). product serial no. in inquiries. (Please refer to nameplate on 2 Stop the carrier. the Cramer product or on the Operation Manual cover). 3 Determine the failure cause. 4 Remedy failure or contact authorized dealer. -
Page 15: Declaration Of Conformity
Declaration of conformity EU Declaration of conformity pursuant to machine directive 2006/42/EC Annex II 1-A The authorized party with residence in the EU, Cramer GmbH Reimersstr. 36 26789 Leer herewith declares, that the following product Manufacturer: Cramer GmbH Reimersstr. 36... -
Page 16: Mount Adjustment Lever For Mowing Height Setting
Mount adjustment lever for mowing height setting Mount mower on TOURNO pick-up carrier Dismantle mower from TOURNO pick-up carrier Safety Delivery, packaging, assembly Risk of high dead weight • Remove machine parts separately from packaging. ATTENTION! Transport inspection • Check the machine for completeness and potential damage upon delivery. Squeezing hazard during •... - Page 17 Mount mower on TOURNO pick-up carrier Step 1 Place the mower in front of the carrier. 1 Receiver bar Step 2 Pull the lever for tensioning the V-belt and fix it with a pin (see 2 Guide rail 3.4.1). Step 3 Lift the mower at the back and place the guide rail on the receiver bar.
- Page 18 Step 7 Now lower the mower with the pedal and the pedal unlocking. Step 8 Only then place the V-belt on the V-belt disk. Important! The V-belt must be in the guide of the two lateral V-belt disks. Step 9 Slightly pull the lever for tensioning the V-belt, remove the pin and slowly release the...
- Page 19 Dismantle mower from TOURNO pick-up carrier Step 1 Now lower the mower with the pedal and the pedal unlocking. Step 2 Pull the lever for tensioning the V-belt and fix it with a pin (see 3.5.1). Step 3 Remove the V-belt from the V- belt disk.
