Summary of Contents for PowerMax PM91001
- Page 1 Multi-Function Automobile Emergency JUMP START Multi-Function Automobile Emergency JUMP START Versatile Mobile power Emergency Compact Carstart supply lighting Product Instruction For PM91001 Series 12V...
- Page 2 WARNING Before using the JUMPSTART, read and follow the instructions carefully. Also pay close attention to the cautionary statements on the vehicle battery and any other equipment. NOTE: MUST READ: As a safety measure, there is NO VOLTAGE present at the clamp ends. The product automatically detects Please read this instruction carefully before you when it is hooked up correctly to a battery, LCD make any operation on your vehicle.
-
Page 3: Product Functions And Features
2. PRODUCT FUNCTIONS AND FEATURES 3.SPECIFICATIONS HYD-SERIES Battery Type Li-Polymer Charging 110-220VAC Charger OR 12VDC IN CAR Charger Peak Amps: 700A 12VDC 6A Output (with 8A overload protection) Outputs 19VDC 3.5A Output (with 4A overload protection) USB - 5VDC, 2.1A High Intensity LED 1W Weight 0.8Kg (1.76LB) - Page 4 USING THE “BOOSTER” FUNCTION WARNING 4.USING THE “BOOSTER” FUNCTION WARNING Ensure that you are using this on a 12 VOLT SYSTEM ONLY, Step 5 Step 6 otherwise the battery could explode. Please strictly follow Once car started successfully Remove the clamps the following steps, otherwise, it could cause damage to the jumpstart, the vehicle or personal injury and death! USING JUMP START OPERATION STEPS...
-
Page 5: Using The Led Work Light
6.USING THE 5V 12V 19V DC OUTPUT POWER SOURCES 5. CHARGING USING AC OR DC CHARGER CAUTION 1. Charge via AC battery charger 2. Charge via DC Adaptor Turn on power button, all output sources 5/12/19V are ready to go. Note: (if not connected or didn’t function, please call 888-8323557) ①The maximum power of the 12V and 19V are 75W. - Page 6 10. PERFORMANCE AT -17.5˚C TO 15˚C 11. ACCESSORIES(if equipped) ①Table 1: Gasoline CAR Gasoline SERIES 3 CYL(≤1.2L) 4 CYL(≤2.7L) 6 CYL(≤3.5L) 8 CYL(≤5.0L) Model Dead 50% Full Dead 50% Full Dead 50% Full Dead 50% Full Battery Battery Battery Battery Battery Battery Battery...
- Page 7 12. ANSWERS FOR COMMON PROBLEMS 13. STATEMENT OF LIMITED WARRANTY Q: How much time will it takes to charge the JUMP START? Our company warrants that each device 1) is free from defects in A: First initial charge is suggested to be 8 hours. After that in a normal materials and workmanship and 2) conforms to our company's official situation, 3-5 hours should charge up completely.
- Page 8 14. WARRANTY CERTIFICATE Record the following information for safe keeping. Product model Purchase date Dealer name Dealer address Dealer phone no. Dealer email Cause of failure User name User phone no. User address User email This material is printed on recycled paper. M001E-B...
