- Page 1 MULTICOM STATIONARY 2.4G USER'S MANUAL...
-
Page 2: General Information
1. General Information 1.1 Introduction The "Multicom Stationary 2.4G" is designed by using the most advanced Multiplex communication technology. It serves user-friendly features and extremely convenient to operate including a crystal clear sound quality and also long distance communication coverage. -
Page 3: Controls And Indicators
2. Controls and Indicators Power S.W Upward : Power Turn ON / Downward : Power Turn OFF Mode Button Selection of Group Number, Device ID, Side Tone On/O , Mute Mode, Microphone Sensitivity level and Audio Output Loud Up Button Control to be Up the level in the selected mode Down Button Control to be Down the level in the selected mode... -
Page 4: How To Use
3. How to use 3.1 Power On/O Press the "Power S.W" switch to the upward to turn the stationary power on. The LCD display is on and shows the default volume level with "VOL 03". If you pressed the "Power S.W" to the downward, the stationary power is turned o . - Page 5 3.4 ID selection In a group, every Stationary needs to have each di erent ID per Stationary from "00" to "99". The ID "00" becomes a master device in a group and every group needs to have a master device with ID "00" per group without alternative.
- Page 6 Normal Audio Output mode Loud Audio Output mode Note; 1) Its default setting is "UL". 2) There might be a kind of white noise creation when you set the audio output at "UH". Hence, it is recommendable to set the audio output at "UL"...
-
Page 7: Specifications
4. Specifications ITEM SPECIFICATION Radio Frequency Type ISM 2405MHz ~ 2477MHz Type Wireless Microphone/Receiver Unit Radio Interface ISM 2.4GHz: FSK Modulation with Frequency Hopping Voice Codec 16bit/8KHz Tx Max. Output Power 10dBm RX Sensitivity -95dBm Voice Latency <35ms Num. of Frequency Channel 145CH Operation Hopping 16CH... - Page 8 5. How to install 5.1 General Publishing Speaking only or Speaking and Listening 100~ 400m distance Unlimited Listeners with MTT-R Notice) It is required to tune the same group number only between Stationary and MTT-R Listening device regardless its ID number. 5.2 Full duplex communication with up to two other MTT-T devices Stationary...
- Page 9 5.3 Full duplex communication and general publishing Stationary MTT-T 1 MTT-T 2 Full Duplex communications between Stationary, MTT-T1 and MTT-T2 Listening all the talking between Stationary, MTT-T1 and MTT-T2 Unlimited number of Listeners with MTT-R 5.4 Line repeat communication between Stationary and Stationary It is available to repeat the communication in one Stationary to the other Stationary by cable connection between two stationeries.
-
Page 10: Important Note
FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 11 European CE notice to users and product statements This product is CE marked according to the provisions of the R&TTE Directive(1999/5/EC). Hereby, Maytel Co., Ltd declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
-
Page 12: Contact Information
Manufacturer Address #417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea To locate in-country MAYTEL CO., LTD., distributors of the Multicom Stationary 2.4G (MTT Stationary T-1) please refer to the MAYTEL CO., LTD. Website http:// www.maytel.com These distributor(s) represent local contacts for this product. -
Page 13: Declaration Of Conformity
#417 Doosan Venture Digm 126-1, Pyeongchon-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Republic of Korea declare under our sole responsibility that the product(s) Multicom Stationary 2.4G (MTT Stationary T-1) – MS-11 2.4G to which this declaration relate(s) is in conformance with the following standards: EN 301 489-1 V1.9.2:2011...
