Part # 35804000 - Instinct Shock Controller
Instinct Shock Controller
Table of contents
Page 2......... Included components
Page 3......... ECU Installation
Page 5......... Sensors Installation
Pages 7-9..... Drive By Wire TPS Calibration
Installation
Instructions
www.ridetech.com
812-482-2932

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 35804000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Instinct 35804000

  • Page 1 Installation Installation Instructions Instructions Part # 35804000 - Instinct Shock Controller Instinct Shock Controller Installation Instructions Table of contents Page 2..Included components Page 3..ECU Installation Page 4..GSensor Installation Page 5..Sensors Installation Page 6..Mode Switch Operation & Launch Control Pages 7-9..
  • Page 2: Installation Instructions

    Installation Installation Instructions Instructions Major Components ..In the box Item Part # Description 35800001 35800002 Main Harness 35800003 GSensor Mode Select Harness - Included in Main Harness GSensor Extension Harness - Included in Main Harness 35900011 Brake Pressure Sensor Harness 35900012 Speed Sensor Harness www.ridetech.com...
  • Page 3 Installation Installation Instructions Instructions Instinct ECU Installation ECU Connector Mode Selector Switch (brown, female, 4 wires) Communication to GSensor (brown, male, 4 wires) use supplied extension harness Green/Yellow Twisted = CAN Shock Connectors Brown and Black = Ground Red = +12V at Battery...
  • Page 4: Gsensor Installation

    Installation Installation Instructions Instructions GSensor Installation location with easy access to the wiring. The sensor should be mounted as level with the ground as possible, with the mounting fl anges on the bottom (like it was sitting on a table), with the wires protruding pointing to the rear of the vehicle.
  • Page 5 Installation Instructions Instructions Instinct Sensor Installation 7. Install the Sensors: 7a. Brake Pressure Sensor (Black Male Plug - 4 wire - yellow wire - short pigtail) 7b. Throttle Position Sensor (Black Female Plug - 3 wire - blue wire - short pigtail) adapter harness.
  • Page 6: Mode Switch Operation & Launch Control

    -2nd Press - LED Flashing - Track Mode -Press again and the system turns off, returns to Street Mode Launch Control: The Instinct system is equipped with and automated Launch Control feature. Launch Control is activated when: -mph less than or equal to zero When Launch Control is active the Mode Selector button will fl...
  • Page 7 Installation Installation Instructions Instructions Drive By Wire Throttle Position Sensor Calibration from the top of the screen. 3. Hit the “Start” button. 4. With the throttle pedal in the idle po- sition, type AB in the “Write Out” box. ***Must be capital letters*** www.ridetech.com 812-482-2932...
  • Page 8 Installation Installation Instructions Instructions TPS Calibration 5. Hit “Send” or press the “Enter” but- ton on your keyboard right. ***Must be capital letters*** right with the value that has been saved. 7. Depress the throttle pedal to Wide 8. While holding the pedal to the fl oor, type AC in the “Write Out”...
  • Page 9 Installation Installation Instructions Instructions TPS Calibration 9. Hit “Send” or press the “Enter” but- ton on your keyboard. right. ***Must be capital letters*** with the value that has been saved. back to the idle position. 12. Hit the “Clear” button to clear the 13.
