Summary of Contents for Oakley Radar Pace
- Page 1 INSERT LOGO HERE User Manual RADAR PACE i | P a g e...
- Page 2 Safety Information ii | P a g e...
-
Page 3: Table Of Contents
SENSORS ................................... 8 RESETTING RADAR PACE ..................................8 MAINTENANCE .................................... 9 STORING RADAR PACE ..................................9 CHARGING ......................................9 SUPPORT ...................................... 9 CLEANING MAINTENANCE ................................9 OAKLEY LIMITED WARRANTY ................................9 BATTERY DISPOSAL INFORMATION ..............................12 TECHNICAL SPECIFICATIONS ................................13 COMPLIANCE INFORMATION ................................. 1 4 iii | P a g e... -
Page 4: Welcome
RADAR PACE your training goals. Let it know about an upcoming event and it will develop a training plan that assesses your level of preparation and dynamically adapts your ongoing training. An indicator light tells you the status of remaining battery power and helps you with wireless pairing, and a touch pad on the frame lets you control even more functions with simple taps and swipes. You can adjust volume, control music and answer calls from your paired phone, and do more. The water-resistant design is a showcase of Oakley’s best performance eyewear technologies including comfortably lightweight O Matter™ frame material, and pure Plutonite® for the lens. RADAR PACE is an interchangeable lens design so you can adapt quickly and easily to the environment. The unrivaled optics take advantage of Polaric Ellipsoid® lens technology for razor-sharp clarity at all angles of view — even at the sides of sweeping contours that extend peripheral vision while maximizing side protection against sun, wind and impact. -
Page 5: In The Box
The power of technology meets the power of possibility. We put the best of everything into the world’s first voice activated real-time coaching system. With your new personal trainer for running and cycling, it’s time to reach for the next level and beyond. Possibility is waiting. IN THE BOX The following items are included in the box: NEEDS UPDATE BASED ON FINAL BOX CONTENTS 4. Remote Goggle Strap 5. USB Cable 6. AC Adapter 7. UK Adapter 8. EU Adapter 1. Radar Pace 9. US Adapter 2. Remote 3. Remote Wrist Strap OVERVIEW INSERT GRAPHICS SHOWING LABELED CONTROLS, AND LABELED LENS MOUNT LOCK/UNLOCK IF IT HAS A MECHANISM FOR THAT. KEEP IT SIMPLE -- NO NEED TO CALL OUT SENSORS, WATERPROOFING, ETC. HERE -- THOSE ASPECTS ARE DISCUSSED ELSEWHERE. SOME WOULD ARGUE THAT CALLING OUT EVERYTHING WOULD HELP RELIEVE COGNITIVE DISSONANCE OVER THE PURCHASE DECISION, BUT AT THIS POINT, EXCITEMENT OVER THE NEW PURCHASE OUTWEIGHS THAT EFFECT, AND WE DON’T WANT TO OVERWHELM THEM AT THE START OF A USER GUIDE. SYSTEM REQUIREMENTS To use RADAR PACE, you need an Android Smartphone (version 5.0 or later) or an Apple iPhone 5S or later (running iOS 9 or later). 5 | P a g e... -
Page 6: Status Indicator
STATUS INDICATOR RADAR PACE has an indicator light that lets you check the status of remaining battery power, and tells you when it is pairing with a Bluetooth enabled device. GREEN: Remaining power is greater than 50% YELLOW: Remaining power is between 20% and 50% RED: Remaining power is less than 20% LIGHT BLUE FLASHING: Booting up or shutting down LIGHT BLUE SOLID: Device is ready DARK BLUE FLASHING: Bluetooth Pairing mode RED FLASHING: Factory Reset mode RADAR PACE APP Download the RADAR PACE app from the App Store or Google Play. Launch the app and follow the onscreen instructions. Let the app help you pair RADAR PACE with your phone and external sensors. Use the app to give RADAR PACE the information it needs to build your personal training program. PAIRING WITH PHONE AND EXTERNAL SENSORS Pair RADAR PACE with your smartphone by pressing the power button twice quickly. The indicator light will flash blue. If pairing is successful, it will turn solid white. If unsuccessful, it will turn solid blue; see the Troubleshooting section. After pairing with your smartphone is complete, the app will assist you with pairing external sensors such as your heartrate monitor and speed sensor. Be sure the devices are powered on and ready for pairing. POWER BUTTON Located on the inner facing of the temple, the power button has multiple functions: For Your Session... -
Page 7: Touch Pad
TOUCH PAD The touch pad on the temple lets you control functions with simple taps and swipes. You can adjust the volume, control music and calls from your paired phone, and more. Control Volume Increase volume: SWIPE FORWARD Decrease volume: SWIPE BACKWARD Control Music Pause or play song: SINGLE TAP Jump to next song: DOUBLE TAP Return to previous song: TRIPLE TAP Fast forward: DOUBLE TAP and HOLD Rewind: TRIPLE TAP and HOLD Control Calls Answer call: SINGLE TAP End call: SINGLE TAP Decline call: HOLD then RELEASE (Use this function when you are not on a current call, and the phone is ringing.) End current call and switch to incoming or on-hold call: HOLD then RELEASE Switch back and forth between incoming call and current call: SINGLE TAP (A single tap puts the current call on hold and answers the incoming call. Each single tap after that switches between the two calls, placing one on hold.) Control Siri / Google Now Activate Siri or Google Now: HOLD then RELEASE CHARGING THE INTERNAL BATTERY Remove either earpiece by pulling it straight down. Plug the micro USB cable into the exposed port. Plug the other end of the cable into the provided AC adapter. The indicator light on RADAR PACE will glow green when charging is complete. A full charge requires approximately 3 hours. CHANGING THE LENS ??? Interact With Radar Pace RADAR PACE is your personal, real-time coach. At any time, just say, “Okay Radar...” to get its attention, then ask your question. Try it now by saying, “Okay Radar. What can I ask you?” 7 | P a g e... -
Page 8: Troubleshooting
Current Metrics Ask RADAR PACE about current metrics during your workout. Ask “What’s my pace?” or just say “pace.” Connect it wirelessly to your external heartrate monitor then ask “What’s my heartrate?” or just say “heartrate.” If you want RADAR PACE to stop responding to you, say “stop listening.” Coaching Philosophy You can ask RADAR PACE about its coaching philosophy, or about creating a training program. For example, “What’s a marathon program?” or “How do I improve my endurance?”... -
Page 9: Maintenance
Oakley lens cleaning solutions are specially formulated and approved for use on Oakley lenses. Otherwise, use only mild soap and water to clean your product. After rinsing, dry by gently blotting with the provided microfiber cloth bag. For eyewear that includes Iridium® lenses: Oakley Iridium is a thin-film reflective coating engineered to help reduce glare and balance light transmission. The coating should be treated with special care to avoid scratching. For Iridium lenses, use only Oakley cleaning kits/solutions. For eyewear that includes anti-fog lenses: Special care should be taken to avoid scratching when cleaning lenses enhanced with anti-fog treatment. Touch the clean microfiber bag lightly to the inside surface of the lens to absorb excess moisture. Rubbing the anti-fog surface may scratch the lens and reduce the effectiveness of the coating. OAKLEY LIMITED WARRANTY This Oakley eyewear product is warranted for one year (two years in the European Union) from the date of purchase against manufacturer’s defects. This warranty is valid only to the original purchaser with a proof of purchase from an Authorized Oakley Dealer that clearly shows the purchase date. Oakley does not warrant any lens scratches. Alteration, misuse, abuse or installation of non-Oakley lenses will void this warranty. The customer’s exclusive remedy for a breach of warranty will be the repair or replacement of the item as determined by Oakley. This warranty does not affect the legal rights of customers under applicable state and national law governing the sale of consumer goods. Hardware Technical Support During the Limited Warranty Period, Oakley will provide Product technical support. Please note that when contacting Oakley via telephone, long distance and other charges may apply, depending on your calling area. The scope of technical support consists of helping to diagnose and resolve problems with defects in Products covered by this limited warranty. 9 | P a g e... - Page 10 Software Support for Operating System Software Oakley is not the manufacturer of any software or operating system and does not guarantee that software or operating systems will be free from errors, either in isolation or in combination with the Product. Limitations and Exclusions THIS LIMITED WARRANTY DOES NOT COVER AND OAKLEY IS NOT RESPONSIBLE FOR: • DELIVERY OR INSTALLATION, OR LABOR CHARGES FOR SETUP OF THE PRODUCT AND/OR ADJUSTMENT OF CUSTOMER CONTROLS ON THE PRODUCT. DAMAGES CAUSED BY MISUSE, ABUSE, ACCIDENTS, FIRE, THEFT, DISAPPEARANCE, MISPLACEMENT, • FLUCTUATIONS AND POWER SURGES, CONNECTIONS TO IMPROPER VOLTAGE OR INCORRECT ELECTRICAL LINE VOLTAGE, VIRUSES, MALWARE, RECKLESS, WILLFUL OR INTENTIONAL CONDUCT. • DAMAGES CAUSED BY SERVICING NOT AUTHORIZED BY OAKLEY. • DAMAGES CAUSED BY USAGE THAT IS NOT IN ACCORDANCE WITH PRODUCT INSTRUCTIONS. • DAMAGES CAUSED BY FAILURE TO FOLLOW THE PRODUCT INSTRUCTIONS OR FAILURE TO PERFORM CLEANING OR PREVENTIVE MAINTENANCE. DAMAGES CAUSED BY THE COMBINATION OF THE PRODUCT WITH OTHER NON-OAKLEY BRANDED PRODUCTS, • ACCESSORIES, PARTS OR COMPONENTS OR USE OF PRODUCTS, EQUIPMENT, SYSTEMS, UTILITIES, SERVICES, PARTS SUPPLIES, ACCESSORIES, APPLICATIONS, INSTALLATIONS, REPAIRS, EXTERNAL WIRING OR CONNECTORS NOT SUPPLIED OR AUTHORIZED BY OAKLEY THAT DAMAGE THE PRODUCT. SIGNAL ISSUES, RECEPTION PROBLEMS AND DISTORTION RELATED TO NOISE, ECHO, INTERFERENCE OR OTHER • SIGNAL TRANSMISSION AND DELIVERY PROBLEMS. RESULTS OF NORMAL USAGE, SUCH AS GRADUAL IMAGE DEGRADATION, UNEVEN SCREEN AGING, BURNED-IN • IMAGES AND PIXEL FAILURE WITHIN DESIGNED SPECIFICATIONS OR THAT DO NOT MATERIALLY ALTER THE PRODUCTS FUNCTIONALITY. • UNINTERRUPTED OR ERROR-FREE OPERATION OF THE PRODUCT. • SOFTWARE, INCLUDING THE OPERATING SYSTEM AND SOFTWARE ADDED TO THE PRODUCT. • ANY EQUIPMENT OR COMPONENTS THAT WERE NOT INCLUDED IN YOUR PRODUCT AS ORIGINALLY SOLD. • NORMAL WEAR AND TEAR, INCLUDING LENS SCRATCHES.
- Page 11 CONSEQUENTIAL, PUNITIVE OR SPECIAL DAMAGES, HOWSOEVER CAUSED, WHETHER FOR BREACH OF WARRANTY, CONTRACT, TORT (INCLUDING NEGLIGENCE), STRICT LIABILITY OR OTHERWISE. For original purchasers who are covered by consumer protection laws or regulations in the jurisdiction of purchase or, if different, their country of residence, the benefits conferred by this warranty are in addition to all rights and remedies conveyed by such consumer protection laws and regulations. This warranty does not exclude, limit or suspend any rights of original purchasers arising out of non-conformity with a sales contract. Some countries, states and provinces do not allow the exclusion or limitation of incidental or consequential damages or allow limitations on how long an implied warranty or condition may last, so the limitations or exclusions described herein may not apply. This warranty provides specific legal rights, and the original purchaser may also have other rights that vary by country, state or province. Instructions for Obtaining Warranty Service Within the United States, the original purchaser should contact Oakley. Original purchasers outside of the United States and Australia should contact their local Authorized Oakley Dealer or visit our website at www.oakley.com to obtain the contact information for the nearest Authorized Oakley Dealer. IT IS THE RESPONSIBILITY OF THE ORIGINAL PURCHASER TO REMOVE ANY DATA FROM THE PRODUCT RETURNED TO OAKLEY OR AN OAKLEY AUTHORIZED DEALER. OAKLEY IS NOT RESPONSIBLE FOR ANY LOSS OF DATA WHATSOEVER. HOW TO MAKE A WARRANTY CLAIM Within the United States, the customer should telephone our Global Headquarters at 1 (800) 403-7449 with their purchase information. Customers outside the United States and Australia should contact their local Authorized Oakley Dealer or visit our website at www.oakley.com for the phone number of the nearest Oakley Distributor. FOR PURCHASERS IN AUSTRALIA Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. The benefits given to you under our express warranty are in addition to other rights and remedies you have under the Australian Consumer Law and other laws. Our express warranty in Australia is provided by: Oakley South Pacific Pty Ltd (ABN 47 090 585 149) 24 The Esplanade St Kilda, VIC, 3182 Australia 1-800-637-001 infoaustralia@oakley.com Unless specifically stated elsewhere in this warranty policy, to make a warranty claim, return your product to the Authorized Oakley Dealer from which the product was purchased together with your proof of purchase. If your warranty claim is deemed to be valid, we will replace or repair the product. Any expenses incurred in returning product for warranty assessment will be done so at the expense of the purchaser. If the returned product is deemed to be a valid warranty claim then Oakley will incur the cost of any further freight 11 | P a g e...
-
Page 12: Battery Disposal Information
MANUFACTURER Oakley, Inc. One Icon Foothill Ranch, CA 92610 USA AUTHORIZED REPRESENTATIVE FOR EUROPEAN UNION Luxottica Group S.p.A., Piazzale Luigi Cadorna 3, 20123 Milano. WARNINGS This eyewear is not designed to protect the wearer from all injury in the event of impact with hard objects. To perform properly, the lens must be fitted securely in the frame. Oakley eyewear should not be used for direct viewing of the sun or strong artificial light sources, nor should tinted lenses be used for driving at night or with poor visibility. If the eyewear impairs your peripheral vision, do not wear while driving. Certain lens tints are specifically designed for performance applications and may be unsuitable for traffic signal recognition. TR22 and TR45 (with or without Iridium Coating) are not suitable for driving and road use and must not be used for driving. DEFINITION OF MARKINGS A Filter Category (Protection Index) number, preceded by “FC:”, indicates the category of the filter (see Table 1) and is imprinted on each lens. The choice of filter depends on the anticipated ambient light level and the user’s sensitivity to glare. An “AF” marking on the lens indicates that it is treated with an anti-fog coating and features enhanced resistance to fogging. SUNGLASS FILTER CATEGORIES TABLE BATTERY DISPOSAL INFORMATION NEED INFO 12 | P a g e... -
Page 13: Technical Specifications
TECHNICAL SPECIFICATIONS Mechanical Specifications Weight: Approx. 65Grams (2.3oz) Storage Temperature Range: -20°C to 60°C (-4°F to 140°F) Operating Temperature Range: -10°C to 30°C (-4°F to 86°F) Vibration Resistance: 4.4g rms 5 Hz to 2000 Hz Shock / Drop Resistance: 40 g, 15-23 ms, ½ Sine (1m vertical drop) Enclosure: Water resistant enclosure, IPX5 Sensor Technology 9-Axis Sensors: 3D Accelerometer | 3D Gyroscope | 3D Magnetometer Pressure Sensor: Altimeter application Networking Subsystem Bluetooth 4.0 (Bluetooth Smart) ANT+ Apple MFi Bluetooth support USB / Micro-USB 2.0 (5-pin) - Device charging Power requirements Primary Supply Voltage: 3.7 lithium polymer rechargeable battery Charge Time: Approx. 3 hours for full charge Battery Size & Life: 1200 mAh; 6 hours or more per charge Environmental Considerations RoHS compliant Brominated flame-retardant-free Mercury-free 13 | P a g e... -
Page 14: Compliance Information
Compliance Information FCC Statement (USA) frequency exposure limits. This equipment has been tested and found to This device must not be co-located or comply with the limits for a Class B digital operating in conjunction with any other device, pursuant to Part 15 of the FCC Rules. antenna or transmitter. These limits are designed to provide FCC requires the user to be notified that any reasonable protection against harmful changes or modifications made to this device interference in a residential installation. This that are not expressly approved by equipment generates, uses, and can radiate manufacture, may void the user’s authority to radio frequency energy and, if not installed use the device and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no ICES-003 (Canada) guarantee that interference will not occur in a This digital apparatus does not exceed the particular installation. Class B limits for radio noise emissions from If this equipment does cause harmful digital apparatus set out in the interference- interference to radio or television reception, causing equipment standard entitled: “Digital which can be determined by turning the Apparatus,” ICES-003 of the Canadian equipment off and on, the user is encouraged Department of Communications. to try to correct the interference by one or Cet appareil numérique respecte les limites more of the following measures: bruits radioélectriques applicables aux appareils numériques de Classe Bprescrites ● Reorient or relocate the receiving antenna. - Page 15 Europe (CE Declaration of Conformity) tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en This product complies with the Low Voltage compromettre le fonctionnement. Directive 2006/95/EC; EMC Directive 2004/108/EC, EU Directive R&TTE Directive Industry Canada ICES- 1999/5/EC, and RoHS Directive 2011/65/EU. 003 Compliance Label: CAN ICES-3 Point of contact: (please add your company (B)/NMB-3(B) name), Attn: (Please add your corporate address) "In the EU, this symbol means that this product must not be disposed of with household waste. It is your responsibility to bring it to a designated collection point for the recycling of waste electrical and electronic equipment. For more information, please contact your local waste collection center or your point of purchase of this product." BRAZIL Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.
