Summary of Contents for Stone Stonebook Mini

  • Page 1 V16.1.00...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Erp Off Mode Power Consumption Statement

    Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
  • Page 5 Preface CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has at- tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation.

  • Page 6: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Fcc Rf Radiation Exposure Statement

    Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

  • Page 8: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 9: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 10 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 11: Servicing

    Preface Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and may expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the following conditions: •...

  • Page 12: Power Safety

    Preface Power Safety The computer has specific power requirements:  • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety Warning steady, uninterrupted power supply.

  • Page 13: Polymer Battery Precautions

    Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.

  • Page 14: General Battery Precautions

    Preface General Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 15: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 16: Travel Considerations

    Preface Travel Considerations As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 17 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 18 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.

  • Page 19: Lcd Screen Care

    Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
  • Page 20 Preface XVIII...

  • Page 21: Table Of Contents

    Preface Contents Notice ................................I ErP Off Mode Power Consumption Statement: ................... II FCC Statement ............................IV FCC RF Radiation Exposure Statement: ..................... V Instructions for Care and Operation ......................VII Servicing ..............................IX Power Safety ..............................X Polymer Battery Precautions ........................XI General Battery Precautions ........................XII Cleaning ..............................
  • Page 22 Preface System Map: LCD Panel Open ........................1-6 LED Indicators ............................1-7 Keyboard ..............................1-8 Keyboard Shortcuts ...........................1-9 Function/Hot Key Indicators ........................1-10 Control Center ............................1-11 System Map: Front & Left Views ......................1-12 System Map: Right & Rear Views ......................1-13 System Map: Bottom View ........................1-14 Removing the Battery ..........................1-15 Inserting the Battery ..........................1-16 Windows 8.1 Control Panel ........................1-17...
  • Page 23 Preface Features & Components Overview ..............................2-1 Hard Disk Drive/Solid State Drive ......................2-2 Multi-In-1 Card Reader ..........................2-3 Touchpad and Buttons/Mouse ........................2-4 Touchpad Sensitivity ..........................2-4 Gestures and Device Settings ........................2-6 Audio Features ............................2-11 Setup for Audio Recording ........................2-12 Power Management Overview ..............................3-1 The Power Sources ............................3-2 AC/DC Adapter ............................3-2 Battery ................................3-2...
  • Page 24 Preface Configuring the Power Buttons .........................3-9 Resuming Operation ..........................3-11 Power Conservation Modes ........................3-12 Battery Information ..........................3-14 Battery Power ............................3-14 Conserving Battery Power ........................3-15 Battery Life ..............................3-16 New Battery .............................3-16 Recharging the Battery with the AC/DC Adapter ...................3-16 Proper handling of the Battery Pack ......................3-17 Battery FAQ .............................3-18 Removing the Battery ..........................3-22 Inserting the Battery ..........................3-23...
  • Page 25 Preface User Account Control ..........................4-6 Windows Security Message ........................4-6 New Hardware Found ..........................4-6 Driver Installation Procedure ........................4-7 Chipset ...............................4-7 Video (VGA) .............................4-7 LAN ................................4-7 CardReader ..............................4-7 TouchPad ..............................4-7 Airplane Mode ............................4-8 USB 3.0 ..............................4-8 Intel TXE ..............................4-8 Hot Key ..............................4-8 Intel®...
  • Page 26 Preface Non-Fatal Errors ............................5-3 Setup Screens .............................5-4 Booting From a Windows 8.1 DVD ......................5-5 Main Menu ..............................5-6 Advanced Menu ............................5-8 Security Menu ............................5-11 Boot Menu ...............................5-15 Exit Menu ..............................5-17 Modules & Options Overview ..............................6-1 PC Camera Module ............................6-2 PC Camera Audio Setup ..........................6-3 Camera App ...............................6-4 Camera Options ............................6-5 Taking Pictures/Capturing Video ......................6-6...
  • Page 27 Preface 3rd Party Bluetooth Combo Driver Installation (Version 1) ..............6-17 Intel Bluetooth Combo Driver Installation ....................6-17 Bluetooth Configuration in Windows ......................6-18 3G/4G Module ............................6-21 3G Configuration in Windows .........................6-23 Trusted Platform Module .........................6-26 Enabling & Activating TPM ........................6-27 TPM Management in Windows .......................6-28 TPM Actions ............................6-30 Wireless Display ............................6-32 Wireless Display Configuration ......................6-33...
  • Page 28 Preface Interface (Ports & Jacks) Overview ..............................A-1 Notebook Ports and Jacks .........................A-2 Control Center Overview ..............................B-1 Video Driver Controls Intel Video Driver Installation ........................C-1 Dynamic Video Memory Technology ......................C-1 Intel® HD Graphics Control Panel ......................C-2 Display Devices & Options ........................C-16 Attaching Other Displays ........................C-17 Attaching Other Displays - Devices (Charms Bar) ................C-19 Configuring an External Display In Windows ..................C-20...
  • Page 29 Preface Storage ..............................D-2 Audio ................................D-2 Keyboard & Pointing Device ........................D-2 Interface ..............................D-2 Card Reader ..............................D-2 Slots ................................D-3 Communication ............................D-3 Power Management ..........................D-3 Power ................................D-3 Indicators ..............................D-3 BIOS .................................D-3 Security ..............................D-3 Features ..............................D-3 Operating System ............................D-3 Environmental Spec ..........................D-3 Dimensions & Weight ..........................D-4 Windows 10 Overview ..............................
  • Page 30 Preface Pining/Unpinning Apps & Programs to/from the Start Menu ..............E-5 Windows 10 Control Panel ........................E-6 Settings ..............................E-7 Windows 10 Taskbar ..........................E-8 Video Features ............................E-9 To Configure Displays using Projectt ....................... E-9 Power Options ............................E-12 Using the Power Button ..........................
  • Page 31 Preface Optional Drivers ............................. E-19 Wireless LAN Module ..........................E-20 3rd Party WLAN Driver Installation ...................... E-21 Intel® WLAN Driver Installation ......................E-21 Bluetooth & WLAN Combo Module ..................... E-22 3rd Party Bluetooth Combo Driver Installation ..................E-23 Intel Bluetooth Combo Driver Installation ..................... E-23 Bluetooth Configuration .........................
  • Page 32 Preface...

  • Page 33: Quick Start Guide Overview

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 34: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - 1 “BIOS Utilities” on page 5 - 1 in the remainder of the User’s Manual.

  • Page 35: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows 8.1) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...

  • Page 36: System Startup

    Quick Start Guide System Startup Remove all packing materials, and place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the right of the computer, connect the AC power cord to the AC/ DC adapter and then plug the AC power cord into an outlet (make sure you use the adapter when first setting up the computer).

  • Page 37: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 8.1 operating system is sup- ported.

  • Page 38: System Map: Lcd Panel Open

    Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open  Built-in PC Camera PC Camera LED Wireless Device Operation Aboard Built-In Microphone Aircraft Power Button The use of any porta- Keyboard ble electronic trans- Touchpad &...

  • Page 39: Led Indicators

    Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Orange DC Power is Plugged In Green The Computer is On Blinking Green The Computer is in Sleep Mode Orange The Battery is Charging Green...

  • Page 40: Keyboard

    Quick Start Guide Keyboard  The keyboard features function keys to allow you to change operational features in- Other Keyboards stantly. If your keyboard is dam- aged or you just want to make a change, you can NumLk Scr Lk Function Keys use any standard USB keyboard.

  • Page 41: Keyboard Shortcuts

    Quick Start Guide Keyboard Shortcuts  The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navi- gation/operation in Windows 8.1. Windows Logo Keyboard Shortcut Windows Logo Use the Windows logo Description Key + + D key com- bination switch Toggle between the Start screen and the foremost running app or the from the Start screen...

  • Page 42: Function/Hot Key Indicators

    Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; some visual indicators are available when the hot key utility is installed. Keys Function Keys...

  • Page 43: Control Center

    Quick Start Guide Control Center When in the Windows Desktop application (not in the Start screen) press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Con- trol Center gives quick access to frequently used controls and enables you to quickly turn the camera/touch pad on/off (see Appendix B...

  • Page 44: System Map: Front & Left Views

    Quick Start Guide System Map: Front & Left Views Figure 1 - 5 Front & Left Views LED Indicators Security Lock Slot External Monitor Port Vent/Fan Intake/ Outlet HDMI-Out Port USB 3.0 Port Microphone-In  Jack Headphone-Out USB 3.0 Port OR USB 2.0 Port Jack This model includes 1 * USB 3.0 port and 2 * USB 2.0 ports.

  • Page 45: System Map: Right & Rear Views

    Quick Start Guide System Map: Right & Rear Views Figure 1 - 6 Right & Rear Views DC-In Jack RJ-45 LAN Jack Multi-in-1 Card Reader USB 2.0 Ports Battery  Battery Information Always completely discharge, then fully charge, a new battery before using it. Completely ...

  • Page 46: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 7 Bottom View Battery Location Vent/Fan Intake/ Outlet Speakers   Overheating Bottom Cover Removal Warning To prevent your comput- Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may from overheating violate the terms of your warranty.

  • Page 47: Removing The Battery

    Quick Start Guide Removing the Battery  We recommend that you do not remove the battery yourself. If you do need to re- Bottom Cover move the battery for any reason (e.g. long term storage) see below. Removal Warning Turn the computer off, and turn it over. Do not remove any cov- Slide the latch in the direction of the arrow.

  • Page 48: Inserting The Battery

    Quick Start Guide Inserting the Battery 1. Slide the battery straight into the compartment (note that there are grooves on the side of the battery which should align up with the battery compartment). 2. Lock should lock automatically into place upon insertion. 3.

  • Page 49: Windows 8.1 Control Panel

    Quick Start Guide Windows 8.1 Control Panel  Throughout this manual you will see an instruction to open the Control Panel. Windows Versions R ight-click the lower left hot corner to bring up the context menu (or use the Win- + X key combination) and select Control Panel in both the dows Logo Key Note that the informa-...
  • Page 50 Quick Start Guide The Control Panel can be accessed in a number of ways in Windows 8.1. • Click Search in the Windows Charms Bar (see previous page) and the search pane will pop out. Type Control Panel and select it from the results to the left. •...
  • Page 51 Quick Start Guide Right-click the Start button in the Desktop app (or use the Windows Logo Key  + X key combination) to bring up an advanced context menu of useful features such as Control Panel, Programs and Features, Power Options, Task Manager, Display Most Search, File Explorer, Command Prompt, Device Manager and Network Connec- Recently Used...

  • Page 52: Windows 8.1 Start Screen & Desktop

    Quick Start Guide Windows 8.1 Start Screen & Desktop The Apps, control panels, utilities and programs within Windows are accessed from the Start screen and/or Windows Desktop app. The Desktop (which runs as an app within the Start screen) can be accessed by clicking the Desktop item in the Start screen (or by using the Windows Logo Key + D key combination).

  • Page 53: Apps & Tiles

    Quick Start Guide Apps & Tiles The Start screen will contain a number of apps, and many more will be installed as you add more applications etc. Not all of these apps can fit on one screen so you will often need use the slider at the bottom of the screen in order to view all the necessary Apps.

  • Page 54: Desktop Application

    Quick Start Guide Desktop Application When the Desktop app is running (click the app in the Start screen or use the Windows Logo Key + D key combination) you can use lower left hot corner to switch between the Start screen and the Windows Desktop app.

  • Page 55: The Charms Bar

    Quick Start Guide The Charms Bar The right side of the screen (Start or Desktop) displays the Charms Bar. The Charms Bar contains the Search, Share, Start, Devices and Settings menus. To access up the Charms Bar move the cursor to the upper or lower right corners of the screen, and then hover over one of the items in the Charms Bar to activate it (the bar will be black when it is active), or use the Windows Logo Key + C key combination.
  • Page 56 Quick Start Guide Charms Bar Items • Search : You can search for any file, application, Apps and control panel settings with instantaneous results. • Share : This button is used to share information with people via mail or social networks. •...

  • Page 57: Windows 8.1 Taskbar

    Quick Start Guide Windows 8.1 Taskbar In many instances throughout this manual you will see an instruction to access the notification area of the task- bar (system tray). In Windows 8.1 the taskbar can be directly accessed from the Desktop application; if you are in the Start screen you will need to move the cursor to the bottom of the screen to display the taskbar.

  • Page 58: Video Features

    Quick Start Guide Video Features You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows when running the Desktop app (see “Desktop Application” on page 1 - 22). It is possible to quickly configure external displays from the Devices menu item in the Charms Bar (see “The Charms Bar”...
  • Page 59 Quick Start Guide To access Display (Control Panel) and Screen Resolution in Windows: Go to the Control Panel. Click Display (icon) - In the Appearance and Personalization category. Adjust resolution.  Right-Click Desktop 1. You can right-click the desktop and select Screen reso- lution (Figure 1 -...
  • Page 60 Quick Start Guide To access the Intel(R) HD Graphics Control Panel: Click Advanced settings (Figure 1 - 19 on page 1 - 27) in the Screen Resolution control panel in Win- dows. Click the Intel(R)... tab and click Graphics Properties (button) (Figure 1 - 20 on page 1 - 28) .

  • Page 61: Power Options

    Quick Start Guide Power Options Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power Menu item in Set- tings in the Charms Bar in Windows 8.1 may be used to Shut down or Restart (you can also add Hibernate/ Sleep to the menu - see “Adding Hibernate/Sleep to the Power Menu”...

  • Page 62: Running Apps

    Quick Start Guide Running Apps To run apps in Windows 8.1 you will need to check that the Screen Resolution and User Account Control Set- tings are compatible with the system requirements. Screen Resolution Settings Switch to the Windows Desktop (click the app or use the Windows logo key + D key combination).
  • Page 63 Quick Start Guide User Account Control Settings If your computer meets the minimum screen resolution requirements, and still you can't run apps, then that you have to check the status of User Account Control (UAC). Apps may fail to open when the UAC is turned off. To check whether the UAC is on or off, follow the instructions below.
  • Page 64 Quick Start Guide 1 - 32...

  • Page 65: Features & Components Overview

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive/Solid State Drive • Multi-In-1 Card Reader • Touchpad and Buttons/Mouse • Audio Features Overview 2 - 1...

  • Page 66: Hard Disk Drive/Solid State Drive

    Features & Components Hard Disk Drive/Solid State Drive  The hard disk drive (HDD) and/or solid state drive (SSD) is used to store your data Bottom Cover in the computer. The hard disk can be taken out to accommodate other serial (SATA) Removal Warning hard disk drives (see “Storage”...

  • Page 67: Multi-In-1 Card Reader

    Features & Components Multi-In-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s). Make sure you install the card reader driver (see “CardReader”...

  • Page 68: Touchpad And Buttons/Mouse

    Features & Components Touchpad and Buttons/Mouse  The Touchpad is an alternative to the mouse; however, you can also add a mouse to Touchpad Active your computer through one of the USB ports. The Touchpad buttons function in Areas much the same way as a two-button mouse. Note that the pointing Touchpad Sensitivity active area is clearly...
  • Page 69 Features & Components Once you have installed the Touchpad driver (see “TouchPad” on page 4 - 7) you  can configure the functions by double-clicking the Touchpad driver icon in the notification area of the taskbar. You may then configure the Touchpad tapping, but- Touchpad Scrolling tons, scrolling (see sidebar), pointer motion and sensitivity options to your prefer- This computer model se-...

  • Page 70: Gestures And Device Settings

    Features & Components Gestures and Device Settings  The Synaptics Gestures Suite application allows you to use a specific gesture (ac- Show Video tion) on the surface of the Touchpad to perform specific actions to manipulate doc- uments, objects and applications. You can get a clearer view of the gestures in- You can configure the settings from the Device Settings tab in Mouse Properties:...
  • Page 71 Features & Components Disabling the Touchpad If you need to disable the Touchpad for any reason (e.g. you may find that when us- ing the computer’s internal keyboard you accidentally trigger the Touchpad when resting your wrists or palms on it) you can do so by using Fn + F1 key combination. You can also set the system to automatically disable the internal Touchpad when an external USB point device (e.g.
  • Page 72 Features & Components PalmCheck  The PalmCheck feature helps prevent operating the pad by accident, by recognizing when your palm is resting on it or brushing its surface while you are typing. PalmCheck In order to improve pad scrolling responsive- ness when using one- finger scrolling, you can adjust the PalmCheck...
  • Page 73 Features & Components Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the Touchpad surface and slide both fingers in the direction required (in a straight con- Figure 2 - 7 tinuous motion).
  • Page 74 Features & Components Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the Touchpad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.

  • Page 75: Audio Features

    Features & Components Audio Features  You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar Adjustment notification area/control panel (right-click the taskbar notification area icon bring up an audio menu).

  • Page 76: Setup For Audio Recording

    Features & Components Setup for Audio Recording  To record audio sources on your computer at optimum quality follow the instruc- Disabling Front Jack tions below: Detection Go to the Control Panel. It is recommended that Click Realtek HD Audio Manager (Hardware and Sound), or right-click the you do not disable front taskbar icon and select Sound Manager.

  • Page 77: Power Management Overview

    Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.

  • Page 78: The Power Sources

    Power Management The Power Sources  The computer can be powered by either an AC/DC adapter or a battery pack. Forced Off AC/DC Adapter If the system “hangs”, Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ and the Ctrl + Alt + Del key combination doesn’t DC adapter will damage the computer and its components.

  • Page 79: Turning On The Computer

    Power Management Turning On the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- er button on the front panel. When the computer is on, you can use the power button as a Stand by/Hibernate/ Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will shut the computer down).

  • Page 80: Shutting The Computer Down

    Power Management Shutting the Computer Down Note that you should always shut your computer down by choosing the Shut down command as this will help prevent hard disk or system problems. Use the Shut down or sign out item in the Context Menu (right-click the lower left corner of the screen to bring up the menu).

  • Page 81: Power Plans

    Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
  • Page 82 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.

  • Page 83: Power-Saving States

    Power Management Power-Saving States  You can use power-saving states to stop the computer’s operation and restart where Wake On LAN you left off. Win 8.1 uses the Sleep, Hibernate and Shut Down power-saving Support states. (Windows 8) Wake-On-LAN is only Sleep supported from Sleep or In Sleep all of your work, settings and preferences are saved to memory before the...

  • Page 84: Hibernate

    Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.

  • Page 85: Configuring The Power Buttons

    Power Management Configuring the Power Buttons  The power/sleep button (Fn + F12 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
  • Page 86 Power Management Adding Hibernate/Sleep to the Power Menu Add Hibernate/Sleep to the Power Menu as follows. Go to the Power Options (Hardware and Sound) control panel. Click “Change settings that are currently unavailable” Click Choose what the power buttons do. Click to put a check in the Hibernate/Sleep box under Shutdown settings.

  • Page 87: Resuming Operation

    Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F12 key combo). Power Status To Resume Icon Color Table 3 - 1 Power Off Press the Power Button Resuming Press the Power Button...

  • Page 88: Power Conservation Modes

    Power Management Power Conservation Modes  This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Power Conservation of inactivity. Adjust Power Conservation Modes from the Control Center: Modes The Energy Star setting Press the Fn + Esc key combination to toggle the Control Center on/off.
  • Page 89 Power Management Ctrl + Alt + Delete Key Combination You can use the CTRL + ALT + DEL key combination from almost any of the Win- dows 8 interfaces/Apps to bring up a full-screen displaying Lock, Switch User, Log off, Change a password and Task Manager options. If you click the Power icon in the lower right corner of the screen a power management option menu appears to display Sleep, Shut down, and Restart.

  • Page 90: Battery Information

    Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- cally low, immediately grams you are running, and peripheral devices attached.

  • Page 91: Conserving Battery Power

    Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.

  • Page 92: Battery Life

    Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.

  • Page 93: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- ...

  • Page 94: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
  • Page 95 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 12 Change Plan Settings / Change Advanced Power Settings Battery Information 3 - 19...
  • Page 96 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 13 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
  • Page 97 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

  • Page 98: Removing The Battery

    Power Management Removing the Battery  We recommend that you do not remove the battery yourself. If you do need to re- Bottom Cover move the battery for any reason (e.g. long term storage) see below. Removal Warning Turn the computer off, and turn it over. Do not remove any cov- er(s) and /or screw(s) for Slide the latch...

  • Page 99: Inserting The Battery

    Power Management Inserting the Battery Slide the battery straight into the compartment (note that there are grooves on the side of the battery which should align up with the battery compartment). Lock should lock automatically into place upon insertion. Lock the battery in place by sliding latch in the direction of the arrow Figure 3 - 15 Battery Insertion...

  • Page 100: Intel® Dynamic Platform & Thermal Framework

    Power Management Intel® Dynamic Platform & Thermal Framework The Intel® Dynamic Platform and Thermal Framework (Intel® DPTF) is a hard- ware/software solution for power and thermal management on your computer, and provides multiple power/thermal technologies. Simply install the driver as instruct- ed below and the technology will provide a set of policies to effect the power man- agement of the CPU versus the system temperature.

  • Page 101: Configuring Intel® Dynamic Platform & Thermal Framework

    Power Management Configuring Intel® Dynamic Platform & Thermal Framework Go to the Power Options (Hardware and Sound) control panel. Click Change plan settings > Change advanced power settings alongside one of your power plans. Figure 3 - 16 Change Plan Settings / Change Advanced Power Settings...
  • Page 102 Power Management Scroll down to Intel® Dynamic Platform & Thermal Framework and click + to expand the options. Click the sub-menus to adjust the settings as required (see below and overleaf). Figure 3 - 17 Power Options Advanced Settings - Intel®...
  • Page 103 Power Management • Config TDP Level - Sets the maximum power to be used by the processor. A High TDP level enables high performance, but needs more cooling and thus will reduce battery life. Nominal TDP operates the processor at the specified TDP and clock rate.
  • Page 104 Power Management 3 - 28...

  • Page 105: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities  This chapter deals with installing the drivers and utilities essential to the operation or Driver Installation & improvement of some of the computer’s subsystems. The system takes advantage of Power some newer hardware components for which the latest versions of most available op- When installing driv- erating systems haven’t built in drivers and utilities.

  • Page 106: Driver Installation

    Drivers & Utilities Driver Installation Insert the Device Drivers & Utilities + User’s Manual disc into an attached USB DVD drive. Click the message “Tap to choose what happens with this disc.” Click Run autorun.exe. Click Install Drivers (button), or Option Drivers (button) to access the Optional driver menu. Figure 4 - 1 - Drivers Installer Screen 1 4 - 2 Driver Installation...
  • Page 107 Drivers & Utilities Check the driver installation order from Table 4 - 1, on page 4 - 4 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu below. Click to select the driver you wish to install, (you should note down the drivers as you install them). Follow the instructions for each individual driver installation procedure as listed on the following pages.
  • Page 108 Drivers & Utilities Win 8.1 Driver System Required Page # Win 8.1 Driver (Other / Options) Page # Chipset Page 4 - 7 PC Camera Module Page 6 - 2 (No driver required) Video (VGA) Page 4 - 7 Wireless LAN Module Page 6 - 11 Page 4 - 7 Bluetooth &...

  • Page 109: Updating/Reinstalling Individual Drivers

    Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click Browse CD/DVD (button) in the Drivers Install- If you wish to update/reinstall individual drivers it er application and browse to the executable file in the may be necessary to uninstall the original driver.To do appropriate driver folder.

  • Page 110: User Account Control

    Drivers & Utilities User Account Control New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” dur- the driver installation procedure, click Continue or ing the installation procedure (other than when out- Allow, and follow the installation procedure as direct- lined in the driver install procedure), click Cancel to close the window, and follow the installation proce-...

  • Page 111: Driver Installation Procedure

    Drivers & Utilities Driver Installation Procedure Insert the Device Drivers & Utilities + User’s Manual Note: If the computer enters a deep sleep mode during disc into your attached CD/DVD drive and click In- installation, you will be prompted to plug in a network stall Drivers (button).

  • Page 112: Airplane Mode

    Drivers & Utilities Airplane Mode Hot Key Note: Do not use Update Driver in Device Manager to 1. Click 9.Install Hotkey AP > Yes. install the Airplane Mode driver. 2. Click Next > Install. 3. Click Finish to restart the computer. 1.

  • Page 113: Optional Drivers

    Drivers & Utilities Optional Drivers See the pages indicated for the driver installation pro-  cedures for any modules included in your purchase op- Windows Update tion. After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up- dates etc.
  • Page 114 Drivers & Utilities 4 - 10...

  • Page 115: Bios Utilities Overview

    BIOS Utilities Chapter 5: BIOS Utilities  Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- If your computer has never been set up, or you are making important changes to the ed for guidance in set- system (e.g.

  • Page 116: The Setup Utility

    BIOS Utilities The Setup Utility  Each time you turn on the computer the system takes a few seconds to conduct a BIOS Settings POST, including a quick test of the on-board RAM (memory). Warning As the POST proceeds, the computer will tell you if there is anything wrong. If there Incorrect settings can is a problem that prevents the system from booting, it will display a system summary cause your system to...

  • Page 117: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized distributor/supplier as soon as possible.

  • Page 118: Setup Screens

    BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.

  • Page 119: Booting From A Windows 8.1 Dvd

    BIOS Utilities Booting From a Windows 8.1 DVD If you want to boot from a Windows 8.1 DVD (e.g. to reinstall the system software) in an external optical CD/DVD device drive, then follow this procedure. Insert the Windows 8.1 DVD into the external DVD drive. Start the computer up and press the F7 key to enter the Boot Options menu.

  • Page 120: Main Menu

    BIOS Utilities Main Menu Figure 5 - 3 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
  • Page 121 BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.

  • Page 122: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 4 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to enable/disable the Battery Engine (see page 10) and to enable/disable Aggressive LPM Support. Aggressive Link Power Man- agement (ALPM) is a power management protocol for AHCI and SATA devices. This allows the SATA host bus adapter to enter a low-power state during periods of inactivity when enabled.
  • Page 123 BIOS Utilities SATA Mode (Advanced Menu)  The SATA (Serial ATA) control is configured to operate in AHCI (Advanced Host Controller Interface) mode. UEFI Boot When UEFI Boot is en- Boot Logo (Advanced Menu) abled, then the prompts Use this menu item to enable/disable the Boot Logo screen at system startup if you to press F2 or F7 will have not enabled UEFI Boot.
  • Page 124 BIOS Utilities Battery Engine Enable (Advanced Menu > Advanced Chipset Control)  The sub-menu here allows you to enable/disable the Battery Engine. The Battery Engine may be set to automatically start charging your battery when the battery Battery Engine Warning reaches a certain capacity level (e.g.

  • Page 125: Security Menu

    BIOS Utilities Security Menu  Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your...
  • Page 126 BIOS Utilities Note: To clear existing passwords press Enter and type the existing password, then  press Enter for the new password (without typing any password entry) and Enter again to confirm the password clearance. Password Warning If you set a boot pass- Set User Password (Security Menu) word (Password on boot You can set a password for user mode access to the Aptio Setup Utility.
  • Page 127 BIOS Utilities Secure Boot Control (Security Menu) Secure Boot prevents unauthorized operating systems and software from loading during the startup process. Secure Boot is available as a menu option if you have enabled UEFI Boot (see “UEFI Boot (Boot Menu)” on page 5 - 16).
  • Page 128 BIOS Utilities TPM Configuration (Security Menu) (Factory Option) This optional sub-menu will allow you to enable/disable Trusted Platform Module (TPM) support, and to configure the TPM State (see “3G/4G Module” on page 6 - for details). Figure 5 - 7 Security Device Support 5 - 14 Security Menu...

  • Page 129: Boot Menu

    BIOS Utilities Boot Menu Figure 5 - 8 Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.
  • Page 130 BIOS Utilities Boot Option Priorities (Boot Menu) Press Enter to access the menu, use the arrow keys to move up and down the menu, and press Enter to select a device from the Boot Option # list (the selected device will be highlighted in white).

  • Page 131: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 9 Exit Menu Click Save Changes and Reset to save all changes made. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Setup defaults that will re- turn the Setup to its original state, and erase any previous changes you have made in a previous session.
  • Page 132 BIOS Utilities 5 - 18...

  • Page 133: Modules & Options Overview

    Modules & Options Chapter 6: Modules & Options  Overview Wireless Device Operation Aboard This chapter contains information on the following modules, which may come with Aircraft your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your distributor/supplier.

  • Page 134: Pc Camera Module

    Modules & Options PC Camera Module When the PC Camera application is run the LED indicator to the left of the camera will be illuminated (see Figure 1 - 2 on page 1 - 6). Note that you need to use the Camera app in Windows to take pictures and capture video.

  • Page 135: Pc Camera Audio Setup

    Modules & Options PC Camera Audio Setup If you want to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Control Panel. Click Sound (Hardware and Sound) and click Recording (tab). Right-click hold and release Microphone (Realtek High Definition Audio) and make sure the item is not disabled.

  • Page 136: Camera App

    Modules & Options Camera App Run the Camera app from the Start screen by clicking on the Camera app icon The camera interface will display two buttons on the right side of the screen. Figure 6 - 2 Camera App Buttons ...

  • Page 137: Camera Options

    Modules & Options Camera Options The Camera Options settings may be accessed as follows: Run the Camera app from the Start screen by clicking on the Camera app icon While the camera app is running access the Charms Bar (e.g. click Use the Windows logo key + C key combination).

  • Page 138: Taking Pictures/Capturing Video

    Modules & Options Taking Pictures/Capturing Video Run the Camera app from the Start screen by clicking on the Camera app icon Right-click the screen and select the timer if you require a countdown before capture. Click the appropriate icon to take a picture or start video capture (if video capture begins a timer will appear in the bottom corner of the screen).

  • Page 139: Camera Roll

    Modules & Options Camera Roll Run the Camera app from the Start screen by clicking on the Camera app icon Right-click on the screen to bring up menu buttons at the bottom of the screen. Click Camera Roll. Click the arrows (on either side of the screen) to browse through the captured photos/video, and back to the Camera app.
  • Page 140 Modules & Options Click the Edit button to bring up a full suite of tools to edit the photo. 10. Click on the menu headings on the left, and then click on the tool on the right to edit the photo as required. Edit Menu Basic Fixes Light...
  • Page 141 Modules & Options Editing Photos Clicking on a captured video will bring up an app bar with a series of buttons. Figure 6 - 8 Edit Buttons (for Video) Click Delete to remove any video from the camera roll (you will be asked to click Delete again to confirm the deletion).
  • Page 142 Modules & Options Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).

  • Page 143: Wireless Lan Module

    Modules & Options Wireless LAN Module  If you have included an Intel® or 3rd Party WLAN module in your purchase option Wireless Device make sure that the module is on (i.e. the system is not in Airplane Mode) before in- Operation Aboard stalling the driver.

  • Page 144: 3Rd Party Wlan Driver Installation (Version 1)

    Modules & Options 3rd Party WLAN Driver Installation (Version 1) 1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into an attached CD/DVD drive . 2. Click Option Drivers (button). 3.

  • Page 145: Wlan Configuration In Windows

    Modules & Options WLAN Configuration in Windows You can configure a wireless connection using one of the following options, how- ever make sure the Wireless LAN module is turned on (and not in Airplane Mode) before configuration begins. Charms Bar Go to the Charms Bar.
  • Page 146 Modules & Options Double-click an access point to connect to it (or click it and click Connect). Enter a network security key (password) if required, and click Next. You can choose to find other devices or not. When you are connected to the network access point it will display Connected Select any connected network and click Disconnect to disconnect from a connected access point.
  • Page 147 Modules & Options Desktop Mode Switch to the Windows Desktop (click the app or use the Windows logo key D key combination). Click the wireless icon in the notification area of the taskbar. A list of available access points will appear. Double-click an access point to connect to it (or click it and click Connect).

  • Page 148: Bluetooth & Wlan Combo Module

    Modules & Options Bluetooth & WLAN Combo Module  If your purchase option includes the Combination Wireless LAN & Bluetooth Wireless Device module (either Intel® or 3rd Party) then install the driver as instructed overleaf Operation Aboard (two drivers are provided for the 3rd party WLAN module and one for the Intel Aircraft WLAN module).

  • Page 149: 3Rd Party Bluetooth Combo Driver Installation (Version 1)

    Modules & Options 3rd Party Bluetooth Combo Driver Installation (Version 1)  1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into an attached CD/DVD drive . High Speed Bluetooth Data Transfer 2.

  • Page 150: Bluetooth Configuration In Windows

    Modules & Options Bluetooth Configuration in Windows  You can configure a Bluetooth connection as below, however make sure the Blue- tooth module is on (or the system is not in Airplane Mode) before configuration. Bluetooth Headset Stereo Setup Desktop Mode To setup a Bluetooth Switch to the Windows Desktop (click the App or use the Windows logo key headset to support ste-...
  • Page 151 Modules & Options Make sure that Bluetooth is turned on and a list of discovered devices will appear. Double-click the device you want to pair with the computer and click Pair. Figure 6 - 14 PC and Devices - Bluetooth On first connection the computer will provide you with a pairing code to be entered onto the device.
  • Page 152 Modules & Options To Make your Computer Discoverable to Bluetooth Devices Switch to the Windows Desktop (click the app or use the Windows logo key D key combination). Click the notification area of the taskbar, click the Bluetooth icon and click Open Settings.

  • Page 153: 3G/4G Module

    Modules & Options 3G/4G Module  If you have included an optional UMTS/HSPA+ based 3G Module (Universal Mo- Wireless Device bile Telecommunications System or High Speed Packet Access) module or LTE Operation Aboard (Long Term Evolution) 4G module (see “Communication” on page D - 3 for spec- Aircraft ification details) in your purchase option, you do not require a driver/application...
  • Page 154 Modules & Options 3G/4G Module USIM Card Installation  Follow the instructions below to install the USIM card (which will be provided by Power Safety your service provider). Warning Turn the computer off, and turn it over. Before you undertake any Slide the latch in the direction of the arrow.

  • Page 155: 3G Configuration In Windows

    Modules & Options 3G Configuration in Windows You can configure a 3G connection as below, however make sure the system is not in Airplane Mode before configuration begins. Charms Bar Go to the Charms Bar. Select Settings and then click the WiFi icon (it should read Available under the icon and Airplane mode should be Off).
  • Page 156 Modules & Options Any 3G service provider (connection information is usually stored on the USIM card) will appear under Mobile Broadband. Double-click any connection icon under Mobile Broadband (or click and then click Connect). Figure 6 - 19 Mobile Broadband (Connect) The system will connect to your network.
  • Page 157 Modules & Options You can then access the internet, download e-mail etc. as per any internet  connection. To disconnect you can select the connection and click Disconnect Wireless Device Operation Aboard Aircraft The use of any portable electronic transmission devices aboard aircraft is usually prohibited.

  • Page 158: Trusted Platform Module

    Modules & Options Trusted Platform Module (Optional) The TPM security chip allows you to create and manage digital certificates for user and platform authentication. This type of security is usually administered within large enterprises and organizations, and therefore requires implementation by a sys- tem administrator before users can access security features.

  • Page 159: Enabling & Activating Tpm

    Modules & Options Enabling & Activating TPM Restart the computer. Enter the Aptio Setup Utility pressing F2 during the POST/startup. Use the arrow keys to select the Security menu. Select TPM Configuration and press Enter to access the sub-menu. Select Enable in Security Device Support. You will then need to press F4 to save the changes and restart the computer.

  • Page 160: Tpm Management In Windows

    Modules & Options TPM Management in Windows You can manage your TPM settings from within Windows: Go to the Control Panel. Click BitLocker Drive Encryption (System and Security). Click TPM Administration. Figure 6 - 22 BitLocker Drive Encryption (TPM Administration) 6 - 28 Trusted Platform Module...
  • Page 161 Modules & Options The TPM Management window allows you to configure the TPM within Windows. As TPM is usually administered within large enterprises and organizations, your system administrator will need to assist you in managing the information here. Figure 6 - 23 Trusted Platform Module (TPM) Management on...

  • Page 162: Tpm Actions

    Modules & Options TPM Actions Click Prepare the TPM and follow the instructions in the Wizard to prepare the TPM (this will probably require a restart of the computer and confirmation of the setting changes after restart by pressing the appropriate F key). After the restart the TPM will be prepared and you can then use the Actions menu to Turn TPM off, Change Owner Password, Clear TPM or Reset TPM Lockout.
  • Page 163 Modules & Options BitLocker BitLocker Drive Encryption can be used in conjunction with the TPM to encrypt data on the disk. Access the Microsoft BitLocker Drive Encryption control panel applet from the Windows control panel (System and Security). Click Turn on Bit Locker. Follow the on-screen instructions to setup BitLocker, and make sure you have a removable media (e.g.

  • Page 164: Wireless Display

    Modules & Options Wireless Display  Wireless Display uses your Wireless LAN module/WLAN Bluetooth Combo mod- Compatible (you need to make sure that your video adapter/display device is compatible with Adapters your particular WLAN/Combo module) in conjunction with a compatible video adapter/display device (purchased separately) to allow you to display the contents of For a list of compatible the notebook display on another display (e.g.

  • Page 165: Wireless Display Configuration

    Modules & Options Wireless Display Configuration Note that no driver or application is required for wireless display in Windows 8.1. Go the Charms Bar, select Devices. Click Project. Click Add a wireless display. Figure 6 - 26 Add a Wireless Display Wireless Display 6 - 33...
  • Page 166 Modules & Options The system will then search for compatible display devices (this may take up to 60 seconds so allow time for this to complete). Figure 6 - 27 Searching For Devices Double-click any detected display device in the list. You may then need to input a pin number for the device to which you are connecting.
  • Page 167 Modules & Options The display will then connect (for specific settings for your display see the documentation supplied with your compatible adapter/display for full details). 10. To disconnect from the display you can select it in PC and Devices > Devices and click Remove Device >...
  • Page 168 Modules & Options 6 - 36...

  • Page 169: Troubleshooting Overview

    Troubleshooting Chapter 7: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 170: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 171: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 172: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 173: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 174 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 175: Problems And Possible Solutions

    Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
  • Page 176 Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
  • Page 177 Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help.  Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
  • Page 178 Troubleshooting Problem Possible Cause - Solution I am sliding my finger up and down on the There are different Touchpad versions available on this computer, and this right side of the Touchpad to scroll a version requires tapping/holding to scroll. Either tap repeatedly, or hold the Window and the Touchpad does not finger down, at the top or bottom right of the Touchpad (depending on the respond.
  • Page 179 Troubleshooting Problem Possible Cause - Solution The Wireless LAN/Bluetooth modules The modules are off as the computer is in Airplane Mode. Check the LED cannot be detected. indicator to see if it is in Airplane Mode (see “LED Indicators” on page 1 - 7).
  • Page 180 Troubleshooting Problem Possible Cause - Solution I have used Update Driver in Device It is very important that the drivers are installed in the order indicated in Chapter Manager (Unknown device > Other 4 (which is the numbered installation order on the Device Drivers & Utilities + Devices) to try and install the Airplane User’s Manual disc).
  • Page 181 Troubleshooting Problem Possible Cause - Solution When using a Bluetooth headset the This is a common issue with Bluetooth headsets. To resolve this issue do the audio appears to be mono and not following (you will need to repeat this procedure after every boot up, restart, stereo.

  • Page 182: 3G/4G Module Pin Code & Power-Saving

    Troubleshooting 3G/4G Module PIN Code & Power-Saving Note that there may be some issues when a PIN Code is set for a 3G/4G module (if you are unsure of your module version contact your distributor/supplier) in Windows, if Mobile Broadband has been turned off, and the system has resumed from a power-saving state.
  • Page 183 Troubleshooting Click Network. Click the broadband connection under Mobile Broadband. Scroll down to Security and click Remove PIN. Enter the current PIN number and click OK. It is recommended that you do not Enable a PIN for a 3G/4G module. Figure 7 - 2 - Disable PIN 3G/4G Module PIN Code &...

  • Page 184: Resolving The "Insert A Sim" Issue With The 3G/4G Module (Windows 8.1)

    Troubleshooting Resolving the “Insert a SIM” issue with the 3G/4G Module (Windows 8.1) If a PIN was set for the 3G/4G module, you have then switched Mobile broadband off (or put the system in Airplane Mode) in Networks, and the system has just resumed from a power-saving state the following error may occur.

  • Page 185: Interface (Ports & Jacks) Overview

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...

  • Page 186: Notebook Ports And Jacks

    Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device: MMC (MultiMedia Card) / RS MMC SD (Secure Digital) / Mini SD / SDHC / SDXC DC-In Jack...
  • Page 187 Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot.
  • Page 188 Interface (Ports & Jacks) A - 4...

  • Page 189: Control Center Overview

    Control Center Appendix B: Control Center Overview The following chapter will give a quick description of the functions of the Control Center. The Control Center gives quick access to frequently used controls, power management features and enables you to quickly turn mod- ules on/off.
  • Page 190 Control Center Power Modes You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will affect the Power Conservation Mode, Airplane Mode, Power Plan and PC camera power etc. You can click a Control Center icon to set an overall power mode and then click individual icons in the Control Center to power on/off the Touchpad and PC camera.
  • Page 191 Control Center Control Center Menus The Control Center contains 2 menu headings (System Program & Device) under the Power Modes. Click the menu headings and then click any of the buttons outlined on the following pages. Figure B - 2 - Control Center Menus Power Status (System Program) The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged in to a working power outlet.
  • Page 192 Control Center Volume (System Program) The Volume icon will show the current volume level. You can use the slider to adjust the Volume or the Fn + F5/F6 key combinations, or use the Fn+ F3 key combination to mute the volume. Fan Speed (System Program) Note that this item will not appear if your CPU’s power requirement is 4W (4 Watts) or less as no fan is required.
  • Page 193 Control Center Time Zone (System Program) Clicking the Time Zone button will access the Date and Time Windows control panel. Desktop Background (System Program) Clicking the Desktop Background button will allow you to change the desktop background picture. TouchPad/PC Camera (Device) Click either of these buttons to toggle the TouchPad or camera module’s power status.
  • Page 194 Control Center B - 6...

  • Page 195: Video Driver Controls

    Video Driver Controls Appendix C: Video Driver Controls  Video Card Options The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Note that card types, specifications and driv- Intel Video Driver Installation ers are subject to contin- updates changes.

  • Page 196: Intel® Hd Graphics Control Panel

    Video Driver Controls Intel HD Graphics Control Panel ® Advanced video configuration options are provided by the Intel HD Control Pan- ® el. To access the control panel see below and overleaf: Click the Intel® HD Graphics Control Panel icon in the Apps screen. Figure C - 1 Apps Screen Intel ®...
  • Page 197 Video Driver Controls Right-click the Desktop and select Graphics Properties from the menu. Click Advanced settings in the Screen Resolution control panel in Windows. Click the Intel(R) HD Graphics Control Panel tab and click Graphics Properties (button). Double-click the Intel(R) HD Graphics control panel in the Windows Control Panel.
  • Page 198 Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate  menu panel and adjusting the settings from the menus. Quick Guide If you have a working in- ternet connection, you can click on the Quick Guide box to access on- line videos to help you configure...
  • Page 199 Video Driver Controls Sub-Menus Some of the menu panels will also have sub-menus (in the top left corner of the menu alongside the icon ) to display further configuration options. Figure C - 4 Intel ® HD Graphics Control Panel Sub-Menus Intel®...
  • Page 200 Video Driver Controls Display  Click either Display Settings or Color Settings to make display adjustments, in- cluding configuration for any attached external displays. Multiple Display At least one other dis- play must be attached in order to view multiple display selection tions.
  • Page 201 Video Driver Controls Click the Display menu at the top of the screen to display the sub-menus. The Mul-  tiple Displays menu allows you to configure the display mode of any attached dis- plays (see “Attaching Other Displays” on page C - 17).
  • Page 202 Video Driver Controls The Custom Resolutions sub-menu allows you to adjust the display (or any at- tached display) to any width, height, refresh rate, color depth and underscan percent- age of your choice. Note that incorrect settings can cause system instability and even possible component damage, so this is adjusted at your own risk.
  • Page 203 Video Driver Controls This menu allows you to choose how 3D images are displayed. Performance Qual- ity displays the most detail, Balanced Mode provides better computer performance with good quality and Custom allows you to configure the Anisotropic Filtering and Vertical Sync and features to your preferences. Click Apply to save changes. Figure C - 8 Intel ®...
  • Page 204 Video Driver Controls Options and Support Hot Key Manager in Options and Support allows you to create hot keys for open- ing the application, rotating the display, scaling etc. Click Apply to save changes. Figure C - 9 Intel ® HD Graphics Control Panel Options and Support...
  • Page 205 Video Driver Controls Click the Options menu at the top of the screen to display the sub-menus. The In-  formation Center provides details on System Information, the Built-In Display and any attached displays. Preferences Go to the Preferences sub-menu in Options to configure the preferences for the Intel®...
  • Page 206 Video Driver Controls Video The Video Profiles menu allows you to brighten or darken movies, or to switch to vivid colors. The Preview image will display a sample image using the current set- tings. You can Save Profile and name the Profile to recall the settings at any time. Click Apply to save changes (select Color Enhancement, Image Enhancement, Image Scaling or Gamut Mapping from the menu).
  • Page 207 Video Driver Controls Click the Video menu at the top of the screen to display the sub-menus.The Image Enhancement menu allows you to adjust the Sharpness, Skin Tone Enhance- ment, Noise Reduction, Contrast Enhancement and Film Mode Detection etc. Click Apply to save changes. Figure C - 12 Intel ®...
  • Page 208 Video Driver Controls Turn Image Scaling on, and use the sliders to adjust the scaling. Figure C - 13 Intel ® HD Graphics Control Panel Video Image Scaling C - 14 Intel® HD Graphics Control Panel...
  • Page 209 Video Driver Controls Power There are two separate menus to adjust the power settings for whenever the comput- er is Plugged In or On Battery. Maximum Battery Life will reduce graphics per- formance for power saving, Balanced will provide full graphics performance when required and minimize power consumption when inactive, and Maximum Perfor- mance will give top graphics performance but requires more power.

  • Page 210: Display Devices & Options

    Video Driver Controls Display Devices & Options  Note that you can use external displays connected to the HDMI-Out port and/or ex- 4K2K Videos on 4K2K ternal monitor port. See your display device manual to see which formats are sup- External Displays ported.

  • Page 211: Attaching Other Displays

    Video Driver Controls Attaching Other Displays  To Clone Displays: Multiple Display Attach your external display to the HDMI-Out port/external monitor port, and turn it on. Go to the Intel(R) HD Graphics Control Panel control panel and click Display > At least one other dis- Multiple Displays (sub-menu).
  • Page 212 Video Driver Controls To Enable Extended Mode:  Attach your external display to the HDMI-Out port/external monitor port, and turn it on. Go to the Intel(R) HD Graphics Control Panel control panel and click Display > Display Settings Multiple Displays (sub-menu). Extended Desktop Click Extended from the Select Display Mode menu.

  • Page 213: Attaching Other Displays - Devices (Charms Bar

    Video Driver Controls Attaching Other Displays - Devices (Charms Bar)  You can configure attached displays from Devices (in the Charms Bar) Windows Logo Key + P Key Attach your external display to the HDMI-Out port/external monitor port, and turn it on. Combination Go the Charms Bar, select Devices.

  • Page 214: Configuring An External Display In Windows

    Video Driver Controls Configuring an External Display In Windows Attach your external display to the HDMI-Out port/external monitor port, and turn it on. Go to the Screen resolution control panel (see page 27) in the Desktop app. Click the Detect button. The computer will then detect any attached displays.
  • Page 215 Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure C - 19 Screen Resolution Multiple Display Options • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...

  • Page 216: Hdmi Audio Configuration

    Video Driver Controls HDMI Audio Configuration  HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Sound Volume In some cases it will be necessary to go to the Sound control panel and manually Adjustment configure the HDMI audio output as per the instructions below. The sound volume level is Go to the Control Panel.
  • Page 217 Video Driver Controls Adjust the HDMI settings from the control panel tabs. Click OK to close the Sound control panel. Figure C - 21 HDMI Device Properties HDMI Audio Configuration C - 23...
  • Page 218 Video Driver Controls HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party application to play...

  • Page 219: Specifications

    Specifications Appendix D: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your distributor/supplier for details.

  • Page 220: Processors

    Specifications Processors One 204 Pin SO-DIMM socket supporting Keyboard & Pointing Device DDR3L 1600MHz (real operational Intel® Pentium® N3700 (1.6GHz) Isolated Keyboard frequency depends on the FSB of the 2MB Smart Cache, 14nm (14 Nanometer), Built-in TouchPad with Multi-Gesture and processor) DDR3L-1600MHz, TDP 6W Scrolling Functionality...

  • Page 221: Slots

    Specifications Slots 3rd Party WLAN (802.11b/g/n) + BIOS Bluetooth v4.0+LE M.2 2230 Combo Slot 1: for M.2 WLAN Combo Module with One 64Mb SPI Flash ROM Module (Factory Option) PCIe & USB Interface AMI BIOS 3G UTMS/HSPA+ M.2 3042 Card Module Slot 2: for mSATA SSD (Solid State Security (Factory Option)

  • Page 222: Dimensions & Weight

    Specifications Dimensions & Weight 292.4mm(w) * 210.5mm(d) * 22.7mm(h) 1.2kg *Barebone System with 24WH Battery A barebone system does not include the CPU, HDD, RAM, adapter, power cord and factory option modules (weight tolerance within +/- 5%). D - 4 Specifications...

  • Page 223: Windows 10 Overview

    Windows 10 Appendix E: Windows 10 Overview This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows 10 OS. You can refer to the main manual for details of audio & video information, BIOS, modules etc. However drivers information specific to Windows 10 will be included in this Appendix, as well as details on how to navigate the Windows 10 user interface to access the applications, control panels, taskbar etc.

  • Page 224: Windows 10 Start Menu

    Windows 10 Windows 10 Start Menu Most of the apps, control panels, utilities and programs within Windows 10 can be accessed from the Start Menu by clicking the icon in the taskbar in the lower left corner of the screen (or by pressing the Windows Logo Key on the keyboard).

  • Page 225: Right-Clicking The Windows Logo In Start Menu

    Windows 10 Right-Clicking the Windows Logo In Start Menu Right-click the Start Menu icon (or use the Windows Logo Key + X key combination) to bring up an advanced Context Menu of useful features such as Control Panel, Programs and Features, Power Options, Task Manager, Search, File Explorer, Command Prompt, Device Manager and Network Connections etc.

  • Page 226: Start Menu Apps & Tiles

    Windows 10 Start Menu Apps & Tiles The Windows 10 Start Menu will contain a number of apps, and many more will be installed as you add more applications etc. Not all of these apps can fit on the screen so may need click and drag the handles at the edge of the screen to expand the menu in order to view all the apps (you can use the scroll bar to move up and down the screen).

  • Page 227: Pining/Unpinning Apps & Programs To/From The Start Menu

    Windows 10 Pining/Unpinning Apps & Programs to/from the Start Menu To make things easy to find you can add and remove tiles for apps and programs to the Start Menu. Right-Click on a program’s icon and select Pin to Start from the drop-down menu. To remove an app or program from the Start Menu right-click the icon and select Unpin from Start.

  • Page 228: Windows 10 Control Panel

    Windows 10 Windows 10 Control Panel In many instances throughout this manual you will see an instruction to open the Control Panel. The Control Panel can be accessed in a number of ways in Windows 10. • Right-click the Start Menu icon in the taskbar in the lower left corner of the screen and select Control Panel from the menu.

  • Page 229: Settings

    Windows 10 Settings The Settings item in the Start Menu (and also as an App) gives you quick access to a number of system settings control panels allowing you to adjust settings for System, Devices, Network & internet, Personalization, Ac- counts, Time &...

  • Page 230: Windows 10 Taskbar

    Windows 10 Windows 10 Taskbar In many instances throughout this manual you will see an instruction to access the notification area of the task- bar. The notification area of the taskbar in the bottom right of the screen. Some of the Control Panels and appli- cations referred to throughout the course of this manual can be accessed from here.

  • Page 231: Video Features

    Windows 10 Video Features You can switch display devices, and configure display options, from the Display control panel (in Appearance and Personalization). Click Adjust resolution to make changes to the appearance of the display and to detect and configure any attached displays. In Windows 10 it is possible to quickly configure external displays from the Media Connect menu ( press the Windows logo key on your keyboard and the P key).
  • Page 232 Windows 10 To access Display (Control Panel) and Screen Resolution in Windows: Go to the Control Panel. Click Display (icon) - In the Appearance and Personalization category. Make and changes required from the Display, Resolution, Orientation or Multiple display menus. Click Apply to save the settings.
  • Page 233 Windows 10 Display Settings: You can quickly adjust the display by right-clicking the desktop and selecting Display Settings Adjust the settings using the sliders in the menu or click Advanced display settings to change resolution. Click Apply to save any changes made to resolution. Figure E - 10 - Display Settings Video Features E - 11...

  • Page 234: Power Options

    Windows 10 Power Options Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power button item in Start Menu (or the context menu) may be used to Shut down or Restart (you can also add Hibernate/Sleep to the menu - see page 13).
  • Page 235 Windows 10 You can also use the context menu (right-click the Start Menu icon or press the Windows logo + X key combination) to Sign out, Sleep, Hibernate, Shut down, and Restart.  Adding Hibernate/Sleep to the Power Men Go to the Power Options (Hardware and Sound) control panel.

  • Page 236: Minimum Screen Resolution Settings

    Windows 10 Minimum Screen Resolution Settings Windows 10 has minimum screen resolution requirements. Right-click a blank area of the Desktop and select Screen Resolution (or go to the Display control panel). Adjust the Resolution to make sure that it is at least 1024 * 768, although preferably 1366 * 768 or above. Figure E - 13 - Screen Resolution E - 14 Power Options...

  • Page 237: Windows 10 Drivers & Utilities

    Windows 10 Windows 10 Drivers & Utilities Make sure you install all the drivers and utilities for your Windows 10 system as outlined in the following pages. Driver Installation (Windows 10) Insert the Device Drivers & Utilities + User’s Manual disc into the computer’s DVD drive, or an attached DVD drive if applicable.
  • Page 238 Windows 10 Windows 10 (64-bit) Drivers Chipset Page E - 17 Wireless LAN Module Page E - 20 Video (VGA) Page E - 17 Bluetooth & WLAN Combo Module Page E - 22 Page E - 17 PC Camera (No driver required) Page E - 25 Card Reader Page E - 17...

  • Page 239: Driver Installation Procedure

    Windows 10 Driver Installation Procedure Insert the Device Drivers & Utilities + User’s Manual Note: If the computer enters a deep sleep mode during disc and click Install Drivers (button). installation, you will be prompted to plug in a network cable, and click OK, to continue installation.

  • Page 240: Airplane

    Windows 10 Airplane Intel TXE Note: Do not use Update Driver in Device Manager to 1. Click 9.Install TXE Driver > Yes. install the Airplane Mode driver. 2. Click Next. 3. Click the check box to accept the license agree- 1.

  • Page 241: Optional Drivers

    Windows 10 Optional Drivers See the following pages for the driver installation procedures for any modules included in your purchase option. Note that you need to install both the WLAN & Bluetooth drivers for the WLAN & Bluetooth Combo modules. Windows 10 Drivers &...

  • Page 242: E - 20 Wireless Lan Module

    Windows 10 Wireless LAN Module If you have included an Intel® or 3rd Party WLAN module in your purchase option make sure that the module is on (i.e. the system is not in Airplane Mode) before installing the driver. Make sure you install the drivers in the order indicated in Table E - 1, on page E - Note that you need to install both the WLAN &...

  • Page 243: 3Rd Party Wlan Driver Installation

    Windows 10 3rd Party WLAN Driver Installation 1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install WLAN Driver > Yes. 4.

  • Page 244: E - 22 Bluetooth & Wlan Combo Module

    Windows 10 Bluetooth & WLAN Combo Module If your purchase option includes the Combination Wireless LAN & Bluetooth module (either Intel® or 3rd Party) then install the driver as instructed overleaf (two drivers are provided for the 3rd party WLAN module and one for the Intel WLAN module).

  • Page 245: 3Rd Party Bluetooth Combo Driver Installation

    Windows 10 3rd Party Bluetooth Combo Driver Installation 1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive. 2. Click Option Drivers (button). 3. Click 2.Install Combo BT Driver > Yes. 4.
  • Page 246 Windows 10 Bluetooth Configuration Click the Settings item in the Start Menu and then click Devices. Click Bluetooth and make sure Bluetooth is On and a list of discovered devices will appear. Double-click the device you want to pair with the computer and click Pair. On first connection the computer will provide you with a pairing code to be entered onto the device.

  • Page 247: Pc Camera

    Windows 10 PC Camera Use the Fn + F10 key combination or Control Center button to toggle power to the PC Camera module. When the PC Camera is in use the LED indicator to the left of the camera will be illuminated. Note that you need to use the Camera app in Windows to take pictures and capture video.

  • Page 248: E - 26 3G/4G Module

    Windows 10 3G/4G Module If you have included an optional UMTS/HSPA+ based 3G Module (Universal Mobile Telecommunications System or High Speed Packet Access) module or LTE (Long Term Evolution) 4G module (see “Communica- tion” on page D - 3 for specification details) in your purchase option, you do not require a driver/application installation for Windows 10.

  • Page 249: 3G/4G Configuration In Windows 10

    Windows 10 3G/4G Configuration in Windows 10 You can configure a 3G/4G connection as below, however make sure the system is not in Airplane Mode before configuration begins. Click the Settings item in the Start Menu and then click Network and Internet. Click Cellular a list of available access points will appear.

  • Page 250: E - 28 Trusted Platform Module

    Windows 10 Trusted Platform Module (Optional) The TPM security chip allows you to create and manage digital certificates for user and platform authentica- tion. This type of security is usually administered within large enterprises and organizations, and therefore re- quires implementation by a system administrator before users can access security features. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full se- curity protection.

Table of Contents

Save PDF
