- Page 1 SmartHardware User Guide STU2161407M-L STU2161407M-L USB programmable controller Ver. 1.2.2013 Software ver.1.1.2013...
- Page 2 SmartHardware User Guide STU2161407M-L 1. Features HID Device / COM Port select by Jumper HID Mode Backup battery (CR2032) for one week RTC Minimum pulse duration 120ms Four concurrent conditions for output. COM Mode Runtime Counter – 4 bytes User Data RAM – 4 bytes...
- Page 3 SmartHardware User Guide STU2161407M-L...
- Page 4 SmartHardware User Guide STU2161407M-L...
- Page 5 SmartHardware User Guide STU2161407M-L...
- Page 6 SmartHardware User Guide STU2161407M-L 2. Power To operate this controller is not necessary a permanent connection to a computer. This controller can be powered with single or dual power supply for logic. Usually using one of Con1 or Con2 for power and Con0 only is used for programming by computer.
- Page 7 SmartHardware User Guide STU2161407M-L 3. Digital Inputs When the input is not connected, it is assumed level H. Resistance for input must be less than 1200 Ohm. 4. Analog Inputs Input can withstand for a short time higher voltages. The only limitation is heat over the resistance.
- Page 8 SmartHardware User Guide STU2161407M-L 5. Mode, Software for PC and other features This controller can operate in two modes: HID Device Mode (jumper removed) and COM Port Mode (jumper placed). Programming in both modes is independent. Jumper checked only at power on.
- Page 9 SmartHardware User Guide STU2161407M-L -- COM PORT Mode –...
- Page 10 SmartHardware User Guide STU2161407M-L Thank you for using our products. For current versions and new products seek us at www.SmartHardware.eu...
