- Page 1 USER’S Manual NGLT104WPA NGLT150WPA LCD TV / Monitor (IP67 Grade) This Manual is revisable without further notice...
-
Page 2: Table Of Contents
Contents CONTENTS ----------------------------------------------------------- 1 Safety Precautions ------------------------------------------------- 2 Operating Safety ---------------------------------------------------- 3 Packing -------------------------------------------------------------- 4 Wall mounting ------------------------------------------------------ 5 Wiring ---------------------------------------------------------------- 6 Remote Controller -------------------------------------------------- 7 Basic Operations ----------------------------------------------- 1. POWER ON / OFF --------------------------------------------------- 8 2. MENU ACCESS ----------------------------------------------------- 8 3. -
Page 3: Safety Precautions
Safety Precautions TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK COVER. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONAL The symbol is intended alert the user to the presence of un-... -
Page 4: Operating Safety
Operating Safety Operating Safety Use only factory supplied power adapter and connector Assemblies to operate the TV monitor. When a user install the TV Monitor himself, read the “INSTALL GUIDE” before installation. Do not install power outlet in a hot or humid place, or where there is excessive dust or vibration. -
Page 5: Packing
Packing LCD TV Remote controller Power adapter User’s manual Power cord Remote Controller Power Adapter User’s manual Power Cord... -
Page 6: Wall Mounting
Wall mounting Installing VESA compliant mounting devices 1. Align the mounting interface pad (75mm × 75mm hole spacing) with the holes in the holes in the televisions rear cover mounting pad. 2. Secure bracket with the four screws ( 4mm : M4) that came with the VESA mounting device. -
Page 7: Wiring
Wiring 1. AV Connecter Video In CVBS (Yellow) Audio In Left (White) Audio In Right (Red) Speaker Out Left (White) Speaker Out Right (Red) 2. S-Video Connecter 3. D-SUB(PC) Connecter (15” Only) 4. Antenna Jack 5. DC 12V Power Jack Make sure check the audio and video source wiring before WIRING CONNECTION... -
Page 8: Remote Controller
Remote Controller Power Channel ( Main number “ㅡ” Sub number) Menu, Enter, Exit, up, down, right, left Function selection and adjustment Favorite Channel Favorite channel selection Caption Options Sleep Timer (30/60/90 min.) Video Mode Soft/sharp/standard screen TV/Input Source TV, Composite , S-video Mute To silence TV Previous channel... -
Page 9: Basic Operations
Basic Operations Note The buttons on the front bezel are designed with infrared technology; you can control by touching each button only not pressing. 1. POWER ON / OFF To turn power on, put your finger on the “POEWR” button. A power-indicate green lamp turn on and you can see a signal on the screen. -
Page 10: Video Source Selection
Basic Operations 3. VIDEO SOURCE SELECTION To select TV, Video, S-Video and PC, put your finger on the SOURCE “SOURCE” button. OSD, “TV” or other functions appear on the left upper side of the screen in turn whenever touch “SOURCE” button. -
Page 11: Osd Window
Basic Operations 6. OSD Window Channel info : Push the OK button of remote control, basic info on the current channel is displayed. Program info : Push info key of remote control, and more detailed info on input signals and additional info including time are shown. -
Page 12: Menu Operations
Menu Operations 1. Channel Menu Tuning Band Cable Mode DTV Signal Auto Channel Search Manual Channel Set Channel Labels Menu Language Select Main Menu and push up/down buttons of remote control to go to Sub-Menu. Push the Enter button to move to Sub-Menu Window from Main Window. - Page 13 Menu Operations DTV Signal ◀▶ → CHANNEL → ▲▼ → DTV Signal → Select → Exit Move highlight bar to DTV Signal menu and push the OK button. And you will see Signal Window which shows the signal strength (weak/ normal/good).
- Page 14 Menu Operations Manual CH Setting ◀▶ → CHANNEL → ▲▼ → Manual CH Setting → Select → Exit It helps to edit all searched channels (save/delete/prefer). Save → Delete → prefer (by the Enter setting) Move to a channel you want by using “To move”...
-
Page 15: Menu Language
Menu Operations Channel Labels Options ◀▶ → CHANNEL → ▲▼ → Channel Labels Options → Select → Exit Push the Enter button, you’ll see channel Labels Options. You can change registered channels by using “To change” key. The name of registered channels can also be changed by moving to blue-colored names using “To move”... -
Page 16: Video Menu
Menu Operations 2. Video Menu Contrast Brightness Sharpness Color Tint Color Temperature Aspect Ratio Setting To go to Sub-Menu, select a item on the Main Menu and then move to Sub-Menu using up/down keys of remote control. Move menu bar to the sub-menu item you want to adjust, and then push the OK button of the remote control to move to Sub-Menu... - Page 17 Menu Operations Brightness ◀▶ → VIDEO → ▲▼ → Brightness → Select Press the Enter button and you’ll see brightness. Adjust Brightness using right/left key. Sharpness ◀▶ → VIDEO → ▲▼ → Sharpness → Select Press the Enter button and you’ll see sharpness.
- Page 18 Menu Operations Color ◀▶ → VIDEO → ▲▼ → Color → Select Press the Enter button and you’ll see Color. Adjust Color using right/left key. As the number decreases, the screen changes from colored to black & white one. Tint ◀▶...
-
Page 19: Color Temperature
Menu Operations Color Temperature ◀▶ → VIDEO → ▲▼ → Color Temperature → Normal → Warm Color → Cool Color → Exit Press the OK button and adjust Color Temperature. (Color Temperature supports normal/warm/cool colors) <Note> Color Temperature does not mean the same color temperature as 6500k. - Page 20 Menu Operations Setting ◀▶ → VIDEO → ▲▼ → Setting (Reset) → Select Press the Enter button, and the setting will be reset to factory default. <Warning> When you execute the menu, all video-related values which were previously set resets to factory default.
-
Page 21: Audio Menu
Menu Operations 3. Audio Menu Audio Language Bass Treble Balance Digital Audio Output TV speakers Setting To go to Sub-Menu, select a item on the Main Menu and then move to Sub-Menu using up/down keys of remote control. Move menu bar to the sub-menu item you want to adjust, and then push the OK button of the remote control to move to Sub-Menu... - Page 22 Menu Operations Bass ◀▶ → Audio → ▲▼ → Bass → Select Press the Enter button and you’ll see bass. Adjust bass by using right/left keys. Treble ◀▶ → Audio → ▲▼ → Treble → Select Press the Enter button and you’ll see treble.
- Page 23 Menu Operations Balance ◀▶ → Audio → ▲▼ → Balance → Select Press the Enter button and you’ll see balance. Adjust speaker balance by using right/left keys. Digital Audio Output ◀▶ → Audio → ▲▼ → Digital Audio Output → RAW → PCM →...
- Page 24 Menu Operations TV Speakers ◀▶ → Audio → ▲▼ → TV Speakers → Select → Exit Push the Enter button, and it changes to ON or OFF. Setting ◀▶ → Audio → ▲▼ → Setting (Reset) → Select Press the Enter button, and the setting will be reset to factory default.
-
Page 25: Setting Menu
Menu Operations 4. Setting Menu Set Time Sleep Mode Timer OSD Transparency Set Password Parental Control Closed Caption Options To go to Sub-Menu, select a item on the Main Menu and then move to Sub-Menu using up/down keys of remote control. Move menu bar to the sub-menu item you want to adjust, and then push the OK button of the remote... -
Page 26: Osd Transparency
Menu Operations Sleep Mode Timer ◀▶ → Setting → ▲▼ → Sleep Mode Timer → Off → 30min → 60min → 90min → Exit Set Sleep Timer by pushing the Enter button. If you select Off, automatic turn-off is cancelled. (Sleep Timer is 30/60/90 min..) OSD Transparency ◀▶... -
Page 27: Set Password
Menu Operations Set Password ◀▶ → Setting → ▲▼ → Set Password → Select Press the Enter button and you’ll see Password Set menu. Enter the password. By pressing number keys on the remote control, input 4 digits and press Enter. Parental Control ◀▶... - Page 28 Menu Operations Closed Caption Options ◀▶ → Setting → ▲▼ → Closed Caption Options → Automation → Manual → Exit Push the Enter button, and you will see Closed Caption Options. Set auto/manual by pushing the Enter button. (When you select manual, set options using right/left keys.) VGA Setting (15”...
-
Page 29: System Specification
System Specification 1. NGLT104WPA Specification Size 10.4 Inch Panel Resolution SVGA (800*600) TV Frequency Range 55.25 ~ 864.25MHz Signal Input 1 Composite Video (1CH), S-Video (1CH) Signal Input 2 ATSC / NTSC Video System NTSC(M/J) , PAL(B/G) VHF,UHF : 75 Ω... - Page 30 System Specification 2. NGLT150WPA Specification Size 15 Inch Panel Resolution XGA (1024*768) TV Frequency Range 55.25 ~ 864.25MHz Signal Input 1 Composite Video (1CH), S-Video (1CH), VGA (1CH) Signal Input 2 ATSC / NTSC Video System NTSC(M/J) , PAL(B/G) VHF,UHF : 75 Ω Antenna Input Speaker out [L/R] 5W / 5W Max...
-
Page 31: Optional Accessories
Optional Accessories 1. Water Resistant Wall Mount Brackets Flush Adjustable 2. RAM Mount with VESA Plate 3. Monitor Enclosure with Arm Mount...
