- Page 1 Compact Installation Loudspeaker USER'S MANUAL SBWPI05BC/WC...
- Page 3 Catalogue … … … … … … … … … … … … … … … … … … … … … … … Important Precautions … … … … … … … … … … … … … … … … … … … … … … … … … Product maintain …...
- Page 4 Thank you very much for buying SBWPI05 loudspeaker. To make you know more how to use our products, please study this user manual before using and keep it for reference in the future. Important precautions ） To prevent damage of the equipment, please use the accessories we provide and install it according to direction in this user manual.
- Page 5 Use explainer ： Loudspeaker hanging bracket installation steps Install the rear panel of the stand in the wall. Take out two mounting screws at the bottom of the loudspeaker out. Install the front arm and fix with screws. Insert the fixed front arm of the loudspeaker stand into the rear panel fixed in the wall.
- Page 6 Specification Technic specification Items Rated power(RMS) 10-40W Peak power LF:1 5in woofer, 25mm(1in) voice coil dia Speaker components HF:N/C Input method Clip terminal 1 Sensitivity(1W/m) 92dB 108dB MAX.SPL Rated impedance 4 ohms Frequency range 150Hz-17KHz Crossover frequency Dispersion angle H=120 V=120 Polystyrene Cabinet...
- Page 7 Product curve picture Frequency response curve picture Impedance curve picture...
- Page 8 TYG reserves the right to make changes in specifications or products without prior notice.
