Summary of Contents for Baltech TL-0208C
- Page 1 OPERATION MANUAL infrared thermometer www.baltech.biz...
-
Page 2: Table Of Contents
3.3.1 LCD display and control panel 3.3.2 Operation modes of the device 3.3.3 Field of View (FOV) 3.3.4 Emissivity of a controlled object 4. MAINTENANCE 5. STORAGE AND TRANSPORTATION 6. ACCEPTANCE AND PACKING CERTIFICATE 7. CALIBRATION CERTIFICATE 8. WARRANTY CERTIFICATE OPERATION MANUAL infrared thermometer www.baltech.biz... -
Page 3: Introduction
Before you start using the device read this operation manual carefully. DEVICE DESCRIPTION 2.1 Application The infrared thermometer BALTECH TL is designed for non- contact temperature measurements of industrial and household objects. The device can be used for temperature monitoring of electrical equipment, conditioning and ventilation systems, industrial and residential buildings, in scientific experiments. -
Page 4: Technical Data
2.2 Technical data Value Characteristics BALTECH BALTECH BALTECH Temperature 2.2.1 TL-0215C TL-0208C TL-0212C measurement -50+1000°C -50+1500°C -50+800°C range, °C (°F) (-58...+1832°F) (-58...+2732°F) (-58...+1472°F) 2.2.2 Accuracy ±3°C (±5°F) From -50~-20°C (-58°F~-4°F) ±2°C (±3°F) From -20~-100°C (-4°F~212°F) ±2% From 100~-1500°C (212°F~2732°F) Response time, sec 2.2.3... -
Page 5: Delivery Set
2.3 Delivery set 1 Infrared thermometer 2 Strap 3 Battery (9V, type 006P) 4 Operation manual 5 Carrying case 6 Packing 2.4 Design and principle of operation T h e I n f ra r e d t h e r m o m e t e r p e r f o r m s n o n - c o n t a c t temperature measurement of object surfaces through measurement of thermal radiation. -
Page 6: Marking
2.5 Marking The device is marked with a nameplate on the side face of the measurement unit. The nameplate contains the device name, measurement range, field of view and manufacturer name. 2.6 Packing The device is packed in a plastic carrying case with polyurethane foam inserts. -
Page 7: Device Application
DEVICE APPLICATION 3.1 Operating limitations The device can be used at the environmental temperature from 0 to 50°C and relative humidity from 10 to 90%. A controlled object must be bigger than a size of a spot, which is calculated according to the diagram of FOV (paragraph 3.3.3. -
Page 8: External Examination
3.2.2 External examination Before you start using the device, it is necessary to carry out an external examination of the device concerning damages and contamination of the lens and display. If there is contamination, it is necessary to perform maintenance of the device in accordance with paragraph 4 of this operation manual. - Page 9 DEVICE APPLICATION LASER ON/OFF, °C / °F Figure 3.2...
-
Page 10: Work With The Device
3.3 Work with the device 3.3.1 LCD display and control panel The measured values and the operation mode are displayed on the LCD. The device management is carried out with a push-button control panel. The functions of the display and control buttons are shown on the figure 3.3. -
Page 11: Operation Modes Of The Device
3.3.2 Operation modes of the device To select an operation mode and set up parameters of the device, use the button «MODE». The selection of the required mode is performed by multiple pressing of a button and through control of the required mode on the device display. - Page 12 DEVICE APPLICATION REMARKS 1. MEMORY: To save the values, press the button «M». To delete all the records, select «DATAO», using button, and press the button «M». 2. FIXATION: After the operation mode is selected, press the measurement start button to start measuring (figure 2.2).
-
Page 13: Field Of View (Fov)
3.3.3 Field of View (FOV) The field of view is the angle of vision of the device, which is determined by the optics of the device. The field of view is the ratio of the distance from the device lens to the measurement spot* to the measurement spot diameter. -
Page 14: Emissivity Of A Controlled Object
DEVICE APPLICATION 3.3.4 Emissivity of a controlled object Most of organic matters and painted or oxidized surfaces have the emissivity 0,95 (predefined in the device). But when measuring the temperature of shiny or polished metal surfaces, you can have inaccurate measurement results. - Page 15 Emissivity Material Aluminum 0,30 Asbestos 0,95 Asphalt 0,95 Basalt 0,70 Brass 0,50 0,90 Brick 0,85 Coal 0,95 Ceramics 0,95 Concrete 0,95 Copper 0,94 Dirt 0,90 Frozen food Hot food 0,90 0,85 Glass (plate) 0,98 Lead 0,50 0,98 Limestone 0,94 Paint 0,93 Paper 0,95...
-
Page 16: Maintenance
MAINTENANCE Repair and maintenance, not described in this operation manual, must be performed only by qualified trained staff. Clean the device housing with a dry cloth periodically. Do not use abrasives and solvents for the device cleaning. The lens should be cleaned with compressed air jet or soft brush. It is recommended to clean the device housing, using soft jaw or cloth, moistened with soap solution. -
Page 17: Acceptance And Packing Certificate
ACCEPTANCE AND PACKING CERTIFICATE The infrared thermometer BALTECH TL-____№_____ is manufactured according to the specifications and is ready for operation. Issue date «___»__________201_ Signature ______________ Job position and signature of the manufacturer's representative The infrared thermometer BALTECH TL-____№_____ is manufactured according to the specifications and is ready for operation. -
Page 18: Calibration Certificate
CALIBRATION CERTIFICATE... -
Page 19: Warranty Certificate
The warranty is not valid, if the customer registration form is not filled in. The guarantee gives the right for free training of 2 specialists in the company BALTECH GmbH (Spenglerstrasse 39-41, 23556 Lübeck Germany, Tel: +49 (0) 451-370-87-700, e-mail: info@baltech.biz, www.baltech.biz) within coordinated time periods, not later... - Page 20 BALTECH GmbH Kronsforder Allee 45, 23560 Lübeck Germany Tel: +49 (0) 451-370-87-700 E-Mail: info@baltech.biz www.baltech.biz...
