Genesis G80 Quick Reference Manual

WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
☐
DEMONSTRATE HOW TO SET THE CLOCK - page 29
☐
DEMONSTRATE AUTOMATIC CLIMATE CONTROL - page 18 – 19
☐
HOW TO DEFROST
Press the front defrost button.
1
Set to warmest temperature setting.
2
Set to highest fan speed.
3
☐
GENESIS CONNECTED SERVICES – page 21-23
- Assist with creating a Genesis Owners account
- Show Genesis Connected Services Users Manual
- Encourage customers to press the Genesis Connected
Services button
☐
TIRE PRESSURE MONITORING SYSTEM (TPMS)- page 35
Low tire pressure indicator /
TPMS malfunction indicator
NOTE: Tire pressure may vary in colder temperatures causing the
low tire pressure indicator to illuminate. Inflate tires according to
the Tire Pressure Label located on the driver's side door pillar.
☐
WINDSHIELD WIPER / WASHER - page 09
• To activate wipers move the switch down
MIST
to one of the three positions
OFF
(AUTO, LO, HI)
AUTO
• To adjust "AUTO" speed move switch
LO
• To spray washer fluid pull lever toward you
HI
• Push lever up for a single wiper pass
☐ PARKING ASSIST SYSTEM (PAS)
- page 33
If the PAS is OFF, it will automatically turn ON when in Reverse.
PAS will automatically turn OFF when driving forward and
speed is over 6 mph.
MAINTENANCE
Scheduled Maintenance Normal Usage
Engine Oil And Filter* Replace 7,500 or 12 mos.
Fuel Additives Add
Tire Rotation Perform 7,500
Inspect 7,500
Air Cleaner Filter
Replace 30,000
Fuel Tank Air Filter Inspect 30,000
Vacuum Hose Inspect 7,500
Fuel Lines, Fuel Hoses And Connections Inspect 30,000
Vapor Hose & Fuel Filler Cap, Fuel tank Inspect 30,000
Climate Control Air Filter
Replace 15,000
(For Evaporator And Blower Unit)
Air Conditioning Refrigerant Inspect 15,000
Brake Hoses & Lines Inspect 15,000
Drive Shafts & Boots Inspect 15,000
Exhaust Pipe & Muffler Inspect 15,000
Front Brake Disc/Pads, Calipers Inspect 15,000
Rear Brake Disc/Pads Inspect 15,000
Steering Gear Box, Linkage & Boots/
Inspect 15,000
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts Inspect 15,000
Propeller Shaft Inspect 15,000
Brake Fluid Inspect 30,000
Parking Brake Inspect 30,000
Front(AWD)/Rear Differential Oil Inspect 37,500
Fuel Filter Inspect 30,000
Valve Clearance (3.8L) Inspect 60,000
1st Inspect 60,000 or 72 mos.
Drive Belt
Add. Inspect 15,000 or 24 mos.
Spark Plugs (Iridium Coated) Replace 105,000
1st Replace 120,000 or 120 mos.
Coolant
Add. Replace 30,000 or 24 mos.
Automatic Transmission Fluid No, Check, No service required
*Check the engine oil regularly between recommended oil change. We recommend Quaker State oil.
*See Owner's Manual for details.
Looking For more detailed information? This Quick Reference Guide does not replace your vehicle's
Owner's Manual. If you require additional information or are unsure of a specific issue, we
recommend that you always refer to the vehicle's Owner's Manual or contact your authorized
retailer of Genesis Branded Products. The information contained in this Quick Reference Guide is
correct at the time of printing; however, specifications and equipment can change without notice.
No warranty or guarantee is being extended in this Quick Reference Guide, and Genesis Brand
reserves the right to change product specifications and equipment at any time without incurring
obligations. Some vehicles are shown with optional equipment.
Severe Usage*
Replace 3,750 or 6 mos.
Every 7,500 or 12 mos.
Perform 7,500
Inspect More Frequently
Replace Same As Normal
Inspect Same As Normal
Replace More Frequently
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Replace More Frequently
Inspect Same As Normal
Inspect Same As Normal
Inspect 7,500 or 6 mos.
Inspect Same As Normal
Inspect More Frequently
Inspect More Frequently
Inspect More Frequently
Inspect Same As Normal
Inspect 7,500 or 6 mos.
Inspect Same As Normal
Inspect More Frequently
Replace 75,000
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Replace More Frequently
Replace Same As Normal
Replace 60,000
NP150-G2017
(Rev 11/09/16)
Printing 12/29/16
GENESIS G80
Quick Reference Guide
www.GenesisMotorsUSA.com
1-844-340-9742
Roadside Assistance:
XM ® Radio:
Sirius 1-800-967-2346
1-844-340-9741
Genesis Customer Care &
Connected Services:
