Page 1 FCC TEST REPORT Report No.: EMC-FCC-R0111 http://www.emc2000.co.kr User manual compliance Ltd. 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82 31 336 9919 (Main) 82 31 336 4767 (Fax) This test report shall not be reproduced except in full, Without the written approval.
Page 2 'ISAW EXTREME' USER MANUAL Ver.1.3...
Page 3: Names Of Each Part
1. Names of each part 2. Operation & button description - ISAW EXTREME is operated by three buttons (Button #1,# 2,# 3) - Button #1 means 'POWER / REC. / SELECT' . - Button #2 means 'SETUP / QUICK SETUP / UP' .
Page 4: Start The Camera
3. Start the camera 1) Open the battery cover and insert ISAW Li-ion battery. 2) Open the battery cover and insert Micro SD card (The camera does not record when there is no Micro SD inside) 3) Press the POWER (#1) button and hold for two seconds. The camera turns on and LCD monitor shows camera image. 4.
Page 5: Video Recording
options Record consecutive videos files of setup time continuously. (1min/5min/10min/30min) Press shutter button to stop. Recording automatically stops in setup time. Captures each image of setup time and save as video file. (1sec/3sec/5sec/10sec/30sec) Press shutter button to stop. Full HD (1920x1080) 60fps / 30fps video recording UXGA (1600x1200) 60fps / 30fps video recording Real HD (1280x720) 60fps / 30fps video recording Resolutions...
Page 6 4) In setting option, press UP / DOWN (#2, #3) button to choose setting option. 5) Press SELECT (#1) button to confirm setting option. Quick setup screen Operation - Video quick setup screen - Press QUICK SETUP (#2) button to go to quick setup - Select recording options - Use up/down (#2, #3) button to choose option - Press shutter (#1) to confirm setting option...
Page 7: User Setup Menu
- Photo quick setup screen - Press QUICK SETUP (#2) button to go to quick setup - Select image size - Use UP / DOWN (#2, #3) button to choose option - Press SELECT (#1) to confirm setting option 9. User setup menu - User can select basic settings and detailed setting options through user setup menu 1) Press SETUP (#2) button and hold for 2 seconds to enter user setup menu 2) User setup menu is divided into four categories (video, photo, effect, settings)
Page 8: Playback Mode
TV Out NTSC / PAL Time Set current time (YYMMDD:HHMM) Yes / No Format Memory card format Yes / No Default Setting Turn back all settings to default Yes / No Auto LCD Off LCD will automatically turn off in 30sec when there is no operation YEs / No Auto Power Off The camera will automatically turn off in 3min when there is no...
Page 9: Smartphone Control
- Press SELECT (#1) button to select 11. Smartphone control - Utilizing WiFi function of ISAW EXTREME, user can control the camera through smartphone. - Compatible with iOS ver. 5.0 or better, Android OS Jelly Bean or better. - Before connect the camera, download 'ISAW Viwer' application from smartphone app store.
Page 10 - 'ISAW Viewer' is not connected to ISAW EXTREME. - Setup WiFi connection between the camera and the smartphone. - Enter 'Setup' of smartphone. - Select 'iCam_xxxxxx' in WiFi setting. - Default password is 12345678'...
Page 11: Recharging Battery
- Run 'ISAW Viewer' application in smartphone. - Click 'Connect' button in application to connect ISAW EXTREME. - Smartphone screen will display live screen of the camera. - Control the camera through the control panel of smartphone application. - Show LIVE screen display...
Page 12: Features And Specifications
16) Rechargeable Li-ion Battery 17) 3M adhesive tape 18) Pouch 17. WARNING - ISAW EXtreme is designed to shoot video or photo with dynamic angles in all sort of extreme and sports moments. Mount the camera in various surfaces within your action.
Page 13 - To minimize any kinds of damages from electromagnetic wave, we recommend to place the camera at least 8 inches away from human body. - The waterproof housing must be checked for leaks before each use. The seal must be clean and undamaged. Check the sealing before each use by a dive without the camera.
