- Page 1 UP-3GHAT01 Quick Installation Guide - 1 -...
-
Page 2: Revision History
REVISION HISTORY Comments Revision Date R.0.1 2016/11/22 Initial version R.0.2 2016/11/30 Change P1/JP2: RS-485 TX、RX Select Add COM2 RS-422/485 Pin define R.0.3 2016/12/23 Change P1/JP2: RS-485 Select and Change UP-3GHAT01 Layout - 2 -... - Page 3 Table of Content 1. UP-3GHAT01 Layout………………..…………………………………...…..…….…..……...- 2. Connector, References……………………………………….………….…0 Switch 3. Switch Settings……………………………………………….…………………….…..1 4. Connector Pin Assignments…………………………………..………………..2 - 3 -...
- Page 4 1. UP-3GHAT01 Layout - 4 -...
-
Page 5: Connector Index
BT pin4 Header 22N8561-04R10B-01G HAT1 5V IN Header 22N8562-40SA2B-01G USB1 USB 2.0 Header 1204-700-10RM COM1 RS-232/422/485 DB9 Connector 3117-000-09P COM2 RS-232/422/485 Connector 1204-700-10SMR SIM1 SIM Card Connector 80440GIH-081T-12CL MINI1 Mini PCIe Connector AS0B226-S68Q-7H AAEON Technology Inc. Focus • Agility • Competitiveness... -
Page 6: Switch Settings
3. Switch Settings 3.1 JP1/JP2: RS-232/422/485 Select Header Functional Description 3-5, 4-6 RS-422 3-5, 2-4 RS-232 (default) 1-3, 2-4 RS-485 www.aaeon.com AAEON Technology Inc. Focus • Agility • Competitiveness... -
Page 7: Connector Pin Assignments
4.1 CN1: Wifi Header Signal Description Signal Description USB2_WF_TX USB2_WF_TX WF_PWM WF_PWM USB2_WF_DN_L USB2_WF_DN_L USB2_WF_PN_L USB2_WF_PN_L USB2_WF_LED# USB2_WF_LED# 4.2 CN2: BT Header Signal Description BT_PWM USB2_BT_DN_L USB2_BT_PN_L 4.3 HAT1: 5V IN Header www.aaeon.com AAEON Technology Inc. Focus • Agility • Competitiveness... - Page 8 Signal Description Signal Description +3.3V HAT_TXD HAT_RXD G_LED Y_LED +3.3V www.aaeon.com AAEON Technology Inc. Focus • Agility • Competitiveness...
- Page 9 USB_VCC USB2_D- USB2_D+ UART0_RXD UART0_TXD 4.5 COM1: RS-232/422/485 DB9 Connector Signal Description DCDA / RS422TX- / RS485- RXA / RS422TX+ / RS485+ TXA / RS422RX+ DTRA / RS422RX- DSRA RTSA CTSA www.aaeon.com AAEON Technology Inc. Focus • Agility • Competitiveness...
- Page 10 DCDB / RS422TX- / RS485- RXB / RS422TX+ / RS485+ TXB / RS422RX+ DTRB / RS422RX- DSRB RTSB CTSB 4.7 SIM1: SIM Card Connector Signal Description Signal Description P_UIM_PWRF P_UIM_RSTC P_UIM_DATC P_UIM_CLKC P_UIM_VPPC GND_UIM www.aaeon.com AAEON Technology Inc. Focus • Agility • Competitiveness...
- Page 11 4.8 MINI1: Mini PCIe Connector Signal Description Signal Description P3V_3G P_UIM_PWR P_UIM_DAT P_UIM_CLK P_UIM_RST P_UIM_VPP 3G_EN 3G_RST P3V_3G USB2_HUB1_P1_DN USB2_HUB1_P1_DP WLAN_LED WLAN_LED WLAN_LED P3V_3G www.aaeon.com AAEON Technology Inc. Focus • Agility • Competitiveness...
- Page 12 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: AAEON UP-3GHAT-A20-0001...
