USE, CARE AND
INSTALLATION INSTRUCTIONS
FOR YOUR NEW CANNON WOOD HEATER
Model No. CAWDFS12
INSTALLER:
Please ensure these instructions
remain with the owner.
Prior to operating your brand new
wood heater thoroughly read and
understand these instructions.
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Refer to this manual. For assistance or additional
information consult an authorized installer, or the Cannon distributor.
Installation and product maintenance must be performed by an authorized
installer or service agent.
SUPPORTING THE
SUPPORTING
AUSTRALIAN HOME HEATING
LANDCARE
ASSOCIATION
AUSTRALIA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAWDFS12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cannon CAWDFS12

  • Page 1 Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual. For assistance or additional information consult an authorized installer, or the Cannon distributor. Installation and product maintenance must be performed by an authorized installer or service agent.
  • Page 2: Product Specifications

    Model No – CAWDFS12 PRODUCT SPECIFICATIONS Unit Net Weight : 120kg Heat Output : 12kW Heating Efficiency : Particulate Emissions : 1.7g/kg Heating Capacity : Up to 22 squares (205 m2) Overall Dimensions : (H) 760mm X (W) 680mm X (D) 609mm...
  • Page 3: For Your Safety

    CAUTIONS : READ THIS FIRST FOR YOUR SAFETY Your Cannon wood heater has been designed and tested to rigorous Australian Standards, and will provide you with beautiful, environmentally sustainable home heating for many years. However, we must remember that these appliances are very powerful, and need to be both installed correctly and operated with care.
  • Page 4 Model No – CAWDFS12 CAUTIONS If the power supply cord is damaged, it must be replaced by the manufacturer, its service agent or a suitably qualified person in order to avoid electrical hazard. INSTALL STRICTLY ACCORDING TO THESE INSTRUCTIONS This heater and flue system must be installed in accordance with the latest version of AS/NZS 2918, relevant building and local government regulations, using the clearances and requirements tabled in these instructions.
  • Page 5: Installation

    Model No – CAWDFS12 INSTALLATION BEFORE YOU BEGIN This heater and flue system must be installed in accordance with the latest version of AS/NZS 2918, relevant building and local government regulations, using the clearances and requirements outlined in these instructions.
  • Page 6 INSTALLATION FLUE REQUIREMENTS Your Cannon wood heater must be installed with an approved “default” flue kit available from your retailer. You must not modify the kit in any way or mix components from other kits. One of the most important factors that determine the performance of your heater is the height of the flue.
  • Page 7 Model No – CAWDFS12 INSTALLATION CLEARANCES It is mandatory that the heater is installed sufficiently clear of combustible material. See the diagram and table below for minimum clearances for both parallel to the wall and corner installation configurations. WARNING: Failure to observe these clearances from any combustible material (including loose firewood) may result in a fire, the damage from which may not be claimable against insurance.
  • Page 8 Model No – CAWDFS12 INSTALLATION FINAL ASSEMBY Assembly of your Cannon wood heater is very straightforward, as most of the work has been done for you at our factory. SET UP THE FIRE BRICKS Place the bricks upright as shown in the illustration.
  • Page 9: Using Your Heater

    Model No – CAWDFS12 USING YOUR HEATER WOOD SELECTION THE IMPORTANCE OF SEASONED HARDWOOD In our experience, there is very little difference between different types of hardwood (eg box gums, stringy bark etc). What is far more important is how well the wood is seasoned. When wood is first cut down, it has a very high moisture content.
  • Page 10 Model No – CAWDFS12 USING YOUR HEATER CREATING THE PERFECT FIRE THE GOLDEN RULE In the early stages of a fire, smaller wood pieces and more air flow is the key. Bigger pieces of wood absorb more heat before they start to burn, so they tend to lower the temperature of the firebox.
  • Page 11 Model No – CAWDFS12 USING YOUR HEATER OTHER USEFUL TIPS OVERNIGHT BURNS To set up for an overnight burn, ensure there is a hot bed of coals to begin. Load up with large logs, and turn the air control to high until the fire is burning strongly. Then move the air control down to low.
  • Page 12: Care And Maintenance

    WARNING: The door glass becomes extremely hot when the heater is operating. The heater should never be operated without the door glass. DO NOT use this heater if the glass is cracked. Contact your Cannon distributor to obtain a replacement glass.
  • Page 13: Maintenance

    Model No – CAWDFS12 CARE AND MAINTENANCE MAINTENANCE At the beginning of each winter season, you should check the following to ensure proper running of your heater. Any worn or cracked parts should be replaced immediately using replacement parts specified by the manufacturer.
  • Page 14 Model No – CAWDFS12 WOOD HEATER LIMITED WARRANTY This Warranty against defects for your newly purchased Cannon product is proudly prepared by Sampford IXL Pty Ltd of 1/391 Boundary Road, Truganina, Vic 3029, phone 1300 727 421. Sampford IXL products come with guarantees that do not exclude the following consumer entitlements under the Australian Consumer Law: a.
  • Page 15 Cannon product. 10. Sampford IXL and its Authorised Service Dealers reserve the right to seek reimbursement of any costs incurred by them should your Cannon product be found to be in good working order. Privacy The privacy of your personal information has always been important to us.
  • Page 16 Model No – CAWDFS12 1/391 Boundary Road Truganina VIC 3029 T 1300 727 421 F 1300 727 425 E service@ixl.com.au W cannonappliances.com.au...
