Summary of Contents for Timotion TBB7
- Page 1 VERSION: C 20170717 TBB7 User Manual...
-
Page 2: Table Of Contents
TBB7 User Manual Contents Contents ..................................2 1. Warning ................................3 2. Specifications ..............................4 3. Operation ................................6 4. Indications ................................6 Status ......................................6 Table ......................................6 Table (TP7C) ..................................... 6 Remarks ....................................6 5. Installation ................................7 6. -
Page 3: Warning
TBB7 User Manual 1. Warning Must follow the rated input voltage Don’t discard or expose the products into water or heat source Recycle with certified depots Repair by authorized maintenance centers With certified charger from original manufactures... -
Page 4: Specifications
TBB7 User Manual 2. Specifications Model name TBB7 5.0Ah 2.9Ah Battery capacity (0.1C discharge, 500mA) (0.1C discharge, 290mA) Input 29~45V DC Output 24V DC, 5.0A 24VDC, 2.9A Duty cycle 10% (2 min on / 18 min off) Operation temperature 5~45... - Page 5 TBB7 User Manual 2.9Ah: Version C July 2017...
-
Page 6: Operation
Long dimming (0.5 sec / 4 sec) Protection <20% Failure Orange Continuous on 4.3 Table (TP7C) When charge by TP7C, TBB7 LED become off, and the status only shown on TP7C- Status Capacity Hi charging >80% Green continuous on Charging <80%... -
Page 7: Installation
TBB7 User Manual 5. Installation Version C July 2017... -
Page 8: Protections
TBB7 User Manual 6. Protections Under below protection status- LED continuous off Protection type When Lasting for Discharge- Over current protect Current > 10.0A 10 sec. Discharge- Low voltage protect Voltage <16.0VDC 15 sec. Standby - Low voltage protect Voltage <22.5VDC 10 min. -
Page 9: Appendix
Discharge current (A) Y axis Discharge time (min) Remark In real situation the discharge varies- this test is only for reference TBB6 and TBB7 (5.0Ah) discharge time curve Time (min) TBB6 and TBB7 (2.9Ah) discharge time curve Time (min) Version C July 2017... -
Page 10: Cycle Test Curve
Charge until max capacity 500mA 290mA reference *Repeat since 51 times TBB6 and TBB7 (5.0Ah) cycle test curve Max capacity (Ah) TBB6 and TBB7 (2.9Ah) cycle tst curve Max capacity (Ah) Version C July 2017...
