AIR HUNTER AWT2400G User Manual

802.11g/b 54/mbps
Hide thumbs

Advertisement

Quick Links

Download this manual
AIN AWT2400G WIRELESS LAN
AIR HUNTER 802.11G/B 54/MBPS
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the AWT2400G and is the answer not in the manual?

Questions and answers

Summary of Contents for AIR HUNTER AWT2400G

  • Page 1 AIN AWT2400G WIRELESS LAN AIR HUNTER 802.11G/B 54/MBPS User Manual...
  • Page 2 Federal Communications Commission Statement Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment.
  • Page 3 2.4465-2.4835GHz frequency range and must be restricted to indoor use. CE Declaration of Conformity For the followi ng equi pment: AIN AWT2400g Cardbus Wireless LAN Card 0984 Is herewith confirmed to comply with the requirements set out in the...

  • Page 4: Table Of Contents

    Content Product Introduction………………………………………………………………………………..2 Air Hunter Installation……………………………………………………………………………..4 Ad-Hoc (Peer-to-Peer) Mode Setup………………………………………………………………13 Application 1: Access the Internet without an AP Application 2: Data sharing between computers Technical Support………………………………………………………………………………..22 AWT2400g Wireless LAN CARD...

  • Page 5: Product Introduction

    1. Product Introduction Thank you for using Air Hunter WLAN product. This installation guide will help you install Air Hunter WLAN Card and connect to the Internet quick & easy. ■ Package Contents 1. AIR HUNTER WLAN CARD 2. Quick Installation Guide 3.
  • Page 6 Ad-Hoc mode is a Peer-to-Peer mode. Without an AP, computers can also Ad-Hoc Mode connect to each other by Air Hunter WLAN card. With this mode, computers are able to share data or connect to the Internet if one of them is already connected to.
  • Page 7 2. Air Hunter Wireless LAN card Installation Note: The screens showed below are from Windows 2000. For other Windows system, the steps are the same, but the screens shown will be a little different. Please Plugging your WLAN card first.
  • Page 8 4. Press the “Install Card Driver” button, the program will Autoruning installation our Air Hunter Wireless LAN card driver. 5. Press Next> button to continue. 6. Choose I accept the terms in the license agreement, then Press Next> button to continue.
  • Page 9 Press Install button, to next. 8. Press button to next. AWT2400g Wireless LAN CARD...
  • Page 10 After successful installation, you’ll see the new icon appear in the Icon Tray. The software will automatically search for available APs for connecting to the Internet. If the connecting fail, the Icon appeared is in yellow to white color. AWT2400g Wireless LAN CARD...
  • Page 11 Radio….et It also shows the connecting signal and quality for you to adjust related infrastructures and configurations. Remark: The field of Reg Domain shown above exemplifies the application in the European market. It cannot be changed and it will be determined by the driver shipped with the product. AWT2400g Wireless LAN CARD...
  • Page 12 3. Statistics window: It shows the real time transmitting and receiving status. 4. Site Survey window: Click “Rescan” to search all available WLAN devices and their status in current environment. Double click the device you want to connect. AWT2400g Wireless LAN CARD...
  • Page 13 5. Encryption window: Air Hunter WLAN is able to provide 64/128/152Bit encryption. 6. Advanced window: It provides you to adjust Power Saving, Preamble Type, Fragment Threshold, RTS Threshold, Receive Antenna. AWT2400g Wireless LAN CARD...
  • Page 14 7. Profiles window: It provides customers to change settings and save them in the configuration file. 8. Info window: It shows the latest software version and MAC address. AWT2400g Wireless LAN CARD...
  • Page 15 AWT2400g Wireless LAN CARD...

  • Page 16: Air Hunter Installation

    3. Ad-Hoc (Peer to Peer) Mode Setup Application_1 ：Access the Internet without an AP With existing Internet connection, another computer can access the Internet by using Peer to Peer mode of Air Hunter Wireless LAN Card. Current Internet set. Internet...
  • Page 17 1. Check the current environment and install WLAN cards A. Check whether “Laptop_Main” connects to the Internet. Install Air Hunter Wireless LAN Card in “Laptop_Main”, and “Laptop_2”….et. 2. “Laptop_Main” Setup A. Click “Start” (1) -> Settings (2) -> Click Network and Dial-up Connections (3) B.
  • Page 18 C. Check the status of the Connection icon. Click the Connection icon, and you can see the device name and status under Network Connections. The name of Air Hunter is “Air Hunter Wireless LAN”, and another one is the original connected device, “Ethernet card 1”.
  • Page 19 E. After finishing, the following window shows up. Please choose “Yes”, and the computer will set your IP address in 192.168.0.1. F. Double click the Air Hunter icon in Icon Tray, and enter into the “Configuration windows”. Configuration window: Remarks: The channel number shown in the above Configuration window exemplifies the application in the European market.
  • Page 20 “Laptop_2” Setup A. Double click the Air Hunter icon in the Icon tray. Under Site survey window, you will see all available connecting instruments. Double click the item (1) with SSID named “Dlink_TEST”. Rest Laptop_2. AWT2400g Wireless LAN CARD...
  • Page 21 2. Check whether the IP address is 192.168.0.1, and the Subnet Mask is 255.255.255.0 (as shown above) Laptop_2: 1. IP address does not need to setup. The DEFAULT GATEWAY is 192.168.0.1. 2. Please follow the steps of “Laptop_Main” to check whether the IP address is 192.168.0.1 AWT2400g Wireless LAN CARD...

  • Page 22: Application 2: Data Sharing Between Computers

    1. Check Laptop_Main & Laptop_1 already install Air Hunter WLAN Card。 2. In Laptop_Main: Double click the Air Hunter icon in Icon Tray, and enter into the “Configuration” Button. Under “Configuration window”, click “Network Type” to modify the Operation Mode to “Ad-hoc Station”...
  • Page 23 Radio “ON”. 7. Encryption: Air Hunter provides 64/128/152bits encryption. Choose “disable”, if you do not need this function. When using Encryption, there are two configurations to setting: Choose from encryption key 1~4 to encrypt.
  • Page 24 This will take more time for devices to check with each other, but it also prevents the loss of frames. 11. Power Saving: Determine whether to use power saving mode. The default setting is ‘Disable’. AWT2400g Wireless LAN CARD...

  • Page 25: Technical Support

    4. Technical support The software version of Air Hunter is under the info window of “software and utility”. Users can get the latest software version from the reseller or Card Maker website at http://www.aincomm.com If you have any further problem, please contact with us.
