Operating Instructions & Parts Manual
Model Number
ATD7341
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
WARNING
!
To avoid crushing and related injuries:
NEVER work on, under or around a
load supported only by a hydraulic
jack. ALWAYS use a pair of adequately
rated jack stands.
ATD Tools Inc.
160 Enterprise Drive, Wentzville, MO 63385
Swift Lift
Hydraulic Service Jack
U.S. Patent No's. 5,946,912 • 6,199,379
Capacity
3-1/2 Ton
Printed in China
ATD7341-M0-0613
Advertisement
Table of Contents
Summary of Contents for ATD Tools ATD7341
- Page 1 ALWAYS use a pair of adequately rated jack stands. ATD Tools Inc. 160 Enterprise Drive, Wentzville, MO 63385 Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
-
Page 2: Safety And General Information
SAFETY AND GENERAL INFORMATION Save these instructions. For your safety, read, understand, and follow the information provided with and on this device before using. The owner and/or operator shall have an understanding of the device, its operating characteristics and safety operating instructions before operating the equipment. The owner and/or operator shall be aware that use and repair of this product may require special skills and knowledge. -
Page 3: Specifications
SPECIFICATIONS Model Capacity Jack Size (L x W x H) Min. Height Max. Height Saddle Dia. ATD7341 3-1/2 Ton 28-1/2" x 13-3/4" x 6-1/2" 5-1/2" 22" 4" OPERATION Lifting Only attachments and/or adapters supplied by the manufacturer shall be used. Lift only on area of the vehicle as specified by the vehicle manufacturer. -
Page 4: Maintenance
WARNING WARNING • Study, understand, and follow all instructions before operating this device. • Do not exceed rated capacity. To avoid crushing and related injuries: • Use only on hard, level surface. • This is a lifting device only. Immediately after •... -
Page 5: Troubleshooting
Not all components of the jack are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence. When ordering parts, give Model number, serial number and parts description below. Call or write for current pricing: ATD Tools Inc. 160 Enterprise Drive, Wentzville, MO 63385. Tel:(816)891-6390 Fax:(816)891-6599... - Page 6 ** Replacement requires special skills, G73700-0002 Tool Tray knowledge, and equipment. Only G73500-0005 Pump Piston authorized service center may perform G73500-0021 Handle Fork the repair and/or replacement of these items. G73504-0000 Repair Kit Figure 2 - Replacement Parts Illustration for Model ATD7341...
-
Page 7: One-Year Limited Warranty
ONE YEAR LIMITED WARRANTY For a period of one (1) year from date of purchase, ATD Tools Inc. will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage. This limited warranty is a consumer's exclusive remedy. - Page 8 Note Page ATD Tools Inc. 160 Enterprise Drive, Wentzville, MO 63385...
