Summary of Contents for EVN VSAVM-021
- Page 1 M E D I A T E C H N O L O G Y website to download the latest version of manual for reference. Maybachstrasse 39 Tel: +49 7161 60686 0 www.evn-components.de PP5-RHAA12Z-000 RoHS 73037 Göppingen Fax: +49 7161 60686 29 info@evn-components.de...
-
Page 2: Package Contents
Feature ● Select a VGA plus analog audio or a digital HDMI signal converting to a HDMI signal ● Support video with the resolution up to Full HD (1920 x 1080) / WUXGA (1920 x 1200) ● UXGA, WSXGA ….Full HD, WUXGA system ●... - Page 3 Video Mode Setting This switch allows user to select the input source from HDMI or VGA + audio. By switching the slide switch according to the printing from left to right HDMI Priority, VGA Priority, Auto and Switch, users can choose the source which is the main output.
-
Page 4: Led Indicator
LED Indicator VGA Input LED (L1) Monitor Mode Source Emit Green and Flash Blue 3 Times HDMI Emit Green and Flash Blue 2 Times Emit Blue and Flash Green 3 Times HDMI Emit Blue and Flash Green 2 Times Emit Green and Flash Red Once Emit Blue and Flash Red Once HDMI Input LED (L2) Monitor Mode... -
Page 5: Product Description
Product Description DC in Ai +Vi1 Audio & Video Input Connect to the VGA + analog audio source Video Input Connect to the HDMI Source Slide Switch Select video input mode Video Output Connect to HDMI monitor LED indicator Please See LED indicator 1. -
Page 6: Connection Pattern
Connection Pattern HDMI cable DC in HDMI cable VGA cable Operation Push Button 1. Press left BTN once to switch input source as VGA or HDMI 2. Press left and right BTNs simultaneously over 2 sec. to enter in t f i Mode 3. -
Page 7: Installation
Installation ● Prior to installation, ensure to power off all devices that will be connected to this system. ● Ensure that all devices you will connect are properly grounded. machines that are likely to generate electrical noise. 1. Adjust slide switch to the proper postion. 2. -
Page 8: Power Consumption
VSAVM-021 HDMI x 1 Input VGA x 1, Analog Stereo x 1 Output HDMI x 1 Full HD (1920 x 1080) Video Resolution (Max.) WUXGA (1920 x 1200) LED Indicator Input x 2 (Multi-color) HDMI TMDS Clock Rate 225 MHz (Max.)
