Summary of Contents for LINK Creative LKW300-21A3
- Page 1 LKW300-21A3 Quick Installation Guide...
-
Page 2: Packing List
1. Packing List Wireless router x1 Power adapter (DC) x1 ADSL splitter x 1 Quick installation guide x1 RJ45 Cable x1 RJ11 Cable x1 CD (user manual) x1 Warranty card X1 2. Installing Your Wireless Router Step 1 Connect the ADSL interface of the device and the Modem interface of the splitter through a telephone cable. -
Page 3: Front Panel
Caution: The power specification is 12V DC, 800 mA. If the power adapter does not match the specification, it may damage the device. 3. Front Panel There are 9 LED indicators on the front panel of the wireless router. By observing their status, you can judge whether the device runs normally. -
Page 4: Rear Panel
Color Status Description indicator quickly layer of the office end. The Internet connection is normal in the routing mode (for example, PPP dial-up is successful), and no Internet data is being transmitted. Green Internet data is being transmitted in the routing Blinks Internet mode. -
Page 5: Logging In To The Web Page
Description Interface RJ-45 interface, for connecting to the Ethernet interface of a LAN1/2/3/4 computer or the Ethernet devices through an Ethernet cable. Power interface, for connecting to the power adapter Power This button is used to restore the factory default settings of router. Keep the device powered on, and insert a needle into the hole for Reset more than 3 seconds, then release it. - Page 6 Note: The username and password of the super user are admin and admin. The username and password of the common user are user and user. Step 3 Click Login to log in to the Web page. Step 4 Click Wizard and then you can follow the on-screen step-by-step instructions to configure the wireless router.
