SERVICEPAD 300
ServicePad 300
User guide
1. This manual is designed for the usage of
SERVICEPAD 300. No part of this manual can be
reproduced,
stored
in
a
retrieval
system
or
transmitted, in any form or by any means (electronic,
mechanical, photocopying, recording, or otherwise),
without the prior written permission of Red (EU) Ltd.
2. SERVICEPAD 300 is designed for the professional
vehicle repair or maintenance technicians only.
3. Use the device only as described in this manual.
The user will be responsible solely for the after-
effects of violating the laws and regulations caused by
using the product or its data information, in this case
Red will not bear any legal responsibility.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ServicePad 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Blue Gecko ServicePad 300

  • Page 1 SERVICEPAD 300 ServicePad 300 User guide 1. This manual is designed for the usage of SERVICEPAD 300. No part of this manual can be reproduced, stored retrieval system transmitted, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the prior written permission of Red (EU) Ltd.
  • Page 2 SERVICEPAD 300 4. Red shall not be liable for any incidental or consequential damages economic consequential damages arising from the accidents of individual users and the third parties, misuse or abuse of the device, unauthorized change or repair of the device, or the failure made by the user not to use the product according to the manual.
  • Page 3 You may not use the trademarks, service marks, domain names, logos and company name of Red or other companies mentioned without written permission from the trademark holder. 8. Please visit www.thebluegecko.co.uk for more information on the SERVICEPAD 300.

  • Page 4: Table Of Contents

    SERVICEPAD 300 Contents Chapter Ⅰ About SERVICEPAD 300 ......6 1. Getting to know the tool ......... 6 2. Technical Parameters........9 Chapter Ⅱ Diagnose ............ 10 1. Vehicle Connection Diagnosis ....... 10 2. SERVICEPAD 300 Main Menu ......11 3.
  • Page 5 SERVICEPAD 300 3. Metric/English Units ........16 4. Recording ............17 5. Information ............18 Chapter Ⅳ Update ............19 1. Upgrade Tool Installation ......19 2. Software Updating ......... 20...

  • Page 6: Chapter Ⅰ About Servicepad 300

    SERVICEPAD 300 Chapter Ⅰ About SERVICEPAD 300 1. Getting to know the tool (1) Appearance ① ② ③ ④...
  • Page 7 SERVICEPAD 300 Name Descriptions Display 3.5’’ TFT-LCD ， showing ① screen testing options and results After power on, it will turn Power to red color and remains ② indicator After communicating Communicati the vehicle, it will turn to ③ on Indicator green color remains on.
  • Page 8 SERVICEPAD 300 Retrieve the keyboard Special function key, can be used as OK. (2) Top view： DB15 Port：Connect to the main test cable (3) Underneath view： Micro USB Port: For connecting USB cable...

  • Page 9: Technical Parameters

    SERVICEPAD 300 2. Technical Parameters CPU: ARM 32bit CPU 72MHz RAM: 64K Ram Program Memory: 512K Flash Internal Memory: built-in 2GB TF card Input Voltage: DC 11~36V External Interface: DB15/ Mini USB Display: 3.5’’ TFT-LCD Display Components: main frame, test cable, USB cable Operating Temperature: -20—50℃...

  • Page 10: Chapter Ⅱ Diagnose

    (1) Connect the DB15 connector of test cable to the SERVICEPAD 300 and the OBDII-16 connector to the vehicles DLC port. (As shown) (2) Switch on the ignition and turn on SERVICEPAD 300 to test vehicles. ① SERVICEPAD 300 ② test cable...

  • Page 11: Servicepad 300 Main Menu

    【Function】 to test vehicles; Select 【Options】 to enter the settings menu; Select 【About】 to check the software version, serial number, etc.; Select 【Selftest】 for the SERVICEPAD 300 to self-test. 3. OBDII Diagnosis (1). Select 【Function】 in the main interface to do...
  • Page 12 SERVICEPAD 300 (2). When choose 【AUTO SCAN】, SERVICEPAD 300 will scan the protocol of the vehicle automatically. If it is compatible with OBDII protocols, then the SERVICEPAD 300 can diagnose that vehicle. Users can also manually choose the protocol if known.
  • Page 13 SERVICEPAD 300...

  • Page 14: Chapter Ⅲ Setting

    SERVICEPAD 300 Chapter Ⅲ Setting Select 【Options】in the main menu to enter the settings menu. 1. Language Setting Select 【Language】 and press Up and Down to choose language; press OK to save settings.

  • Page 15: Contrast Adjustment

    SERVICEPAD 300 2. Contrast Adjustment Select 【Contrast】 and press Left and Right to adjust the contrast; press OK to save settings.

  • Page 16: Metric/English Units

    SERVICEPAD 300 3. Metric/English Units Select 【Unit】 and press Up and Down to choose unit; press OK to save settings.

  • Page 17: Recording

    SERVICEPAD 300 4. Recording When testing vehicles, record diagnostic results and give feedback to the after-sales department. Select 【Recording】 and choose Disable or Enable.

  • Page 18: Information

    SERVICEPAD 300 5. Information Select 【About】 in the main interface to check the information, including the product serial number, hardware version, software version, password, etc.

  • Page 19: Chapter Ⅳ Update

    SERVICEPAD 300 Chapter Ⅳ Update 1. Upgrade Tool Installation (1). Visit www.thebluegecko.co.uk and select Updates (2). Click the icon of “Upgrade Tool” (shown as below), then download the Upgrade Tool and save the file to your computer.

  • Page 20: Software Updating

    (3). Follow the instructions step by step to install the Upgrade Tool. 2. Software Updating (1). Connect the SERVICEPAD 300 to the computer via USB cable。 (2). Open the Upgrade Tool, input the Product SN and Password, then click Login. (shown as below)
  • Page 21 SERVICEPAD 300 (3). After login, you will see as below; click “(Un)Sel” to select the software and click “Upgrade” then it will update automatically.
