Fractus Antennas specializes in enabling effective mobile communications. Using Fractus
technology, we design and manufacture optimized antennas to make your wireless devices
more competitive. Our mission is to help our clients develop innovative products and accelerate
their time to market through our expertise in antenna design, testing and manufacturing.
TM
Geofind
FR05-S1-E-0-103
GPS (1575 MHz)
Some Fractus Antennas products are
protected by
All
information
document is property of Fractus Antennas
and is subject to change without prior
notice. Information is provided "as is" and
without warranties. It is prohibited to copy
or reproduce this information without prior
approval.
Fractus Antennas is an ISO 9001:2008
certified company. All our antennas are
lead-free and RoHS compliant.
Last updated on June 2017
USER MANUAL
Geofind
(FR05-S1-E-0-103)
TM
Fractus
patents.
contained
within
© 2016 FRACTUS ANTENNAS, S.L. -
this
1
Advertisement
Table of Contents
Related Manuals for Fractus Geofind
Summary of Contents for Fractus Geofind
- Page 1 (FR05-S1-E-0-103) – GPS (1575 MHz) Fractus Antennas specializes in enabling effective mobile communications. Using Fractus technology, we design and manufacture optimized antennas to make your wireless devices more competitive. Our mission is to help our clients develop innovative products and accelerate their time to market through our expertise in antenna design, testing and manufacturing.
-
Page 2: Table Of Contents
INDEX OF CHAPTERS ANTENNA DESCRIPTION ....................4 QUICK REFERENCE GUIDE ..................... 4 ELECTRICAL PERFORMANCE ..................5 MECHANICAL CHARACTERISTICS .................. 8 MATCHING NETWORK ..................... 9 ASSEMBLY PROCESS ....................10 PACKAGING ........................12 Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -... - Page 3 4.2. SPECIFICATIONS FOR THE INK ................8 4.3. ANTENNA FOOTPRINT (as used in the evaluation board) ......... 9 MATCHING NETWORK ..................... 9 ASSEMBLY PROCESS ....................10 PACKAGING ........................12 Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -...
-
Page 4: Antenna Description
GPS (1575 MHz) Chip Antenna is specifically engineered for low cost, consumer electronics mobile GPS devices. The Geofind™ Chip Antenna uses space-filling properties of Fractus technology to minimise its size and cost while maintaining a high radiation efficiency value. This monopole antenna... -
Page 5: Electrical Performance
USER MANUAL Geofind (FR05-S1-E-0-103) ELECTRICAL PERFORMANCE 3.1. FRACTUS EVALUATION BOARD The Fractus Antennas configuration used in testing the Geofind Embedded Antenna is displayed in Figure 1. Measure 60.0 30.0 71.0 17.0 35.0 Tolerance: ±0.2mm Material: The evaluation board is built on FR4 substrate. Thickness is 1.0mm. -
Page 6: Radiation Patterns, Gain And Efficiency
Table 2 – Antenna Gain and Efficiency at 1575 MHz. Measures made in the evaluation board and in the Satimo STARGATE 32 anechoic chamber. Data across the band is not significant in this case because the bandwidth is very narrow. Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -... -
Page 7: Capabilities And Measurement Systems
3.4. CAPABILITIES AND MEASUREMENT SYSTEMS Fractus Antennas specializes in the design and manufacture of optimized antennas for wireless applications, and with the provision of RF expertise to a wide range of clients. We offer turn-key antenna products and antenna integration support to minimize your time requirements and maximize return on investment throughout the product development process. -
Page 8: Mechanical Characteristics
(RoHS). The RoHS certificate can be downloaded from www.fractusantennas.com. 4.2. SPECIFICATIONS FOR THE INK Next figure shows the correct colors of the antenna: Acceptable color range Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -... -
Page 9: Matching Network
MATCHING NETWORK The specs of a Fractus Antennas standard antenna are measured in their evaluation board, which is an ideal case. In a real design, components nearby the antenna, LCD’s, batteries, covers, connectors, etc. affect the antenna performance. This is the reason why it is highly recommended placing pads compatible with 0402 and 0603 SMD components for a PI matching network as close as possible to the antenna feeding point. -
Page 10: Assembly Process
Geofind (FR05-S1-E-0-103) ASSEMBLY PROCESS Figure 5 shows the back and front view of the Geofind chip antenna, and indicates the location of the feeding point and the mounting pads: Mounting Pads (2, 3, 4): solder the antenna mounting pads to the soldering pads on the PCB. - Page 11 8 minutes max Table 3 – Recommended soldering temperatures. Next graphic shows temperature profile (grey zone) for the antenna assembly process in reflow ovens. Figure 7 – Temperature profile. Last updated on June 2017 © 2016 FRACTUS ANTENNAS, S.L. -...
-
Page 12: Packaging
USER MANUAL Geofind (FR05-S1-E-0-103) PACKAGING The Fractus Geofind™ chip antenna is available in tape and reel packaging. Measure 16.0 ± 0.3 10.5 ± 0.1 10.5 ± 0.1 1.5 ± 0.1 11.1 ± 0.1 2.0 ± 0.1 2.0 ± 0.1 Wmax 16.3...
