14.0 Technical Specifications
RD-1 Tube DAB/DAB+/ RDS FM Radio with
Wireless Audio Connection
-Maximum Power Output: 2 x 25 Watts
-Frequency Response: 20-20 KHz
-DAB/DAB+/RDS Receiver Sensitivity: 98 dB
-DAB/DAB+ Receiver Frequency Range: Band III, 174-240 MHz
-RDS/FM Tuning Range: 87.45 -108 MHz
-OLED (Organic Light Emitting Diode) Display
-S/N Ratio: 86 dB
-Distortion: 0.1%
-Input Impedance: 47 K-Ohms
-Output: Internal Speaker, (2 x 4 Ohms, custom design)
-Maximum Power Consumption: 110 Watts
-Input Source: DAB/DAB+/DAB III, FM/RDS, Line In (2 x RCA),
Aux In (2 x RCA)
-Output: Line Out (Pre-amp); Headphone
-Voltage Input: AC 100-120 V, 50/60 Hz
AC 220-240 V, 50/60 Hz
-Tubes: 6N1;6N2; 6E2 Cats-Eye
-Dimensions: 327 x 196 x 199 mm ( L x W x H)
12 11/16" x 7 3/4" 7 13/16" (L x W x H)
-Weight: 7 kg, 15.5Ibs
Thank-you for selecting DARED
as your choice for your
audio entertainment system
and listening pleasure.
Experience The Art of Tube
Tube
The Purity of Sound
12
Model RD-1
Retro-Dreams-Retro-Style Tabletop Tube
DAB/RDS/FM Radio with Wireless Audio
Connection, Wireless Remote,
and advanced OLED Display
WARNING!
Read the instruction manual
completely before use.
IT CONTAINS VITAL SAFETY, WARRANTY
AND LIABILITY INFORMATION.
By using the product the user acknowledges their responsi-
bility and agrees to the warranty and liability statements
and safety notices.
DARED AUDIO INTERNATIONAL
www.dared.com.hk
© 2010-2014 DARED Due to constant improvements, specifications and functions
subject to change without notice. Failure to read and follow the guidelines estab-
lished in the manual may void warranty. Customer is solely responsible for use.
Tampering or modifying the unit voids warranty. Consult Warranty Statement for all
details.
Manual Rev 3.2 June 2015
Advertisement
Table of Contents
Summary of Contents for Dared RD-1
- Page 1 Manual Rev 3.2 June 2015 DARED AUDIO INTERNATIONAL www.dared.com.hk © 2010-2014 DARED Due to constant improvements, specifications and functions subject to change without notice. Failure to read and follow the guidelines estab- Tube The Purity of Sound lished in the manual may void warranty.
- Page 2 If you hear unusu- The performance of your RD-1 will continue to improve during the first al sounds, squeals, or have low audio output, or distorted output, it is time to 480 hours of listening.
- Page 3 Use an RCA Cable to connect from the Out- Radio in the space provided on the card as well as below for future refer- put terminals on the back of RD-1 to the input of your system. The Output level from ence.
- Page 4 7.10 Clock: Once either the DAB/DAB+ or the RDS FM Radio has scanned and 10. Only use attachments and accessories specified by DARED or your Au- registered its stations and updated the RD-1’s CPU, or the time has been set manually, thorized DARED Dealer.
- Page 5 With all connections made and secured, you are now steps away from enjoying the than those specified. sound quality of the RD-1. Also it is a good idea to remove the back cover with pow- er disconnected to ensure that the tubes are seated properly before connecting to 7.
- Page 6 AC wall outlet you use has a functioning ground. Then, it is preferable that you plug your RD-1 into a surge suppressor power bar used as well for your other audio components, then best is to connect this directly into a dedicated AC outlet.
