Aeronavics BOT-Series Build Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the BOT-Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Aeronavics BOT-Series

  • Page 4 Aeronavics or any multi-rotor craft. to the front of you, make sure you are well clear of obstructions and other people. You may need the assistance of another Please read the instructions for the relevant Flight Control person for this test.
  • Page 5 Make sure that you have fully charged your transmitter and Always keep your eyes on the craft when in flight – if people onboard battery packs. Make sure that the antenna of your approach you inside your safety perimeter to talk to you or to Radio (TX) is up and correctly positioned;...
  • Page 6 Aeronavics disclaims all warranties, whether express or implied, including but not limited to the implied warranties of merchantability and fitness for a particular purpose. Aeronavics does not assume any lyability, whether direct or indirect, from the use of the BOT craft. Aeronavics shall not be liable for any direct, indirect, special, incidental, punitive, contingent or consequential damages to...
  • Page 7 • Never fly in strong wind – the operational safe wind speed for these craft is about 10-15 KPH. • In the event of a crash or a hard landing, always check the craft for damage before taking off again. In this instance, you must also check that you do not have dirt or grit in the engines;...
  • Page 9 se of mediUm strength thread lock is highly recommended hilliPs river m3 h river m3 2.5 crew river...
  • Page 10 Battery Mounting Plate Alloy Twin Battery Mounting Pad Rubber 1406-0090 1403-0133 M3 QR Mounting Bracket - Male CX Landing Gear Mounting Bracket 1403-0032 1406-0170 Camera Mounting Bracket DJI H3-2D CX BOT Landing Gear Plate - Tube 1403-0140 1406-0120 Landing Gear Twin Skid Foot Clip Landing Gear Skid 300mm 1406-0200 1406-0185...
  • Page 11 Locking Washer M3 2504-0030 12 (1) Rubber Grommet 9.5mm 2506-0250 Transparent Adhesive Domes 2506-0650...
  • Page 12 Attach the two landing gear plates together screwing the 63mm Alloy Spacers in between using the M3 x 8mm screws. Do not tighten to full extent since you will need some play when mounting further parts.
  • Page 13 Attach the Quick release male clip to the Attach the Skid Feet using the 63mm Landing Gear Mounting Bracket using Alloy Spacer and the M3 x 12mm M3x8mm SHCS screws and M3 SS Nuts. Screws.. Slide the Twin Skid End Cap over the Skids.
  • Page 15 Now slide the Gear Rail Tubes through the Push the Gear Rail Tubes through the grommets grommets of the Camera Mounting Bracket. of the Landing Gear Plate. Now attach the Dog Bone using M3x8 shcs. Slide the first Battery Plate on to the Gear Rail Tubes with the bottom angle facing backwards as shown below.
  • Page 16 Now push the Gear Rail Tubes through the Attach the Dog Bone using M3x8 shcs second Landing Gear Plate add the second and slide the Battery Straps on the Battery Battery Plate as shown below. Mounting Plate. Your set up should now look like this...
  • Page 17 Gear Rail Bracket BOT LP 130mm Landing Gear Foot BOT 1411-0120 1402-0070 Camera Mounting Bracket DJI H3-2D Gear Rail Center Plate Spacer M3 1504-0010 1406-0121 Battery Mounting Twin-Plate Socket HeadCap Screw M3x8mm 2503-0030 1403-0133 8 (1) Gear Rail Dog Bone Bracket Socket HeadCap Screw M3x12mm 2506-0020 1404-0040...
  • Page 18 Push the grommet into the bottom of the Landing Gear plate.
  • Page 19 Fit the silver spacer into the grommet and fix Position the Spacer and fix with a this with a M3x12 Socket HeadCap Screw M3x30 SHCS and a Stainless Steel and a 1mm M3 Nyclon Washer. Repeat this M3 nut. for the secon plate. Attach the landing gear to the landing gear mounting bracket...
  • Page 20 Remove the nuts from the inner boom cluster, place the bracket and replace the nuts with the 4 M3 Nyloc Nut Black provided. Push the grommets into the holes of the Gear Rail Bracket Assemble the Gear Rail Assembly by firstly pushing the grommets into the Camera Mounting Bracket.
  • Page 21 Now slide the Gear Rail Tubes through the Push the Gear Rail Tubes through the grommets grommets of the Camera Mounting Bracket. of the BOT LP Gear Rail Bracket. Now attach the Dog Bone using M3x8 shcs. Slide the first Battery Plate on to the Gear Rail Tubes with the bottom angle facing backwards as shown below.
  • Page 22 Now push the Gear Rail Tubes through the Attach the Dog Bone using M3x8 shcs. rare grommets on the Gear Rail Bracket, then add the second Battery Plate as shown below.
  • Page 23 Your setup should now look like this.
  • Page 25 This Core Pack includes fittings for new Low Profile and Extended Landing Gear. Standoff Threaded M3x11 Nylon 1202-0011 Center Plate 2503-0070 Standoff Threaded M3x12.7mm Nylon 1202-0040 Decal set BOT 2506-0220 Socket Head Cap Screw M3x30mm 1206-0010 Universal Adaptor Plate 2506-0050 Socket Head Cap Screw M3x35mm 1206-0044 Boom bracket inner...
  • Page 26 2510-0230 Socket Head Cap Screw M3x30mm Ti 2506-0460 Nyloc Nut M3 Aluminum Black...
  • Page 27 Take a moment to familiarise yourself with the centre plate setup to get an understanding which holes relates to which parts. Take one of the plates and lay it out with the notch at the top and the sticker facing up. Lines indicate the boom mount triangle...
  • Page 28 Slide the inner boom brackets onto the Slot the M3x30mm bolts into the relevant holes for boom corresponding bolts. mounting shown by the yellow triangles. Then flip the plate over (bottom picture). Mount your booms onto the brackets as shown here. The holes closest to the end of the Booms should face inwards.
  • Page 29 Place the remaining boom bracket inners onto Fit M3 SS nuts to the screws - do not tighten them, just the booms. make them secure whilst you work your way around. Position the second centre plate over the boom cluster aligning the hole pattern as shown below.
  • Page 30 electronics standoffs You can now tighten all of the nuts slotting the supplied nylon M3 x apart from the SS ones (front and 6mm countersunk screws through rear). the desired holes from the underside. Then screw the standoffs onto them.
  • Page 31 Attach the bracket to the landing gear plate using the Socket Head Cap Screw M3x12mm and M3 Spring Washer. Your setup should now look like this..Place the M3 QR Female Clip (from the landing gear pack) across the landing gear plate as shown.
  • Page 32 Repeat the process for all four of the positions shown and then turn the core over. With the four remaining Center Plate Spacers you will need to file a grove into the top as shown. Feed the M3x40mm screw through the hole and center plate spacer next to the Nylon Standoff making sure that the grove is facing the screw on the underside of the...
  • Page 33 Slide the landing gear plate on top of the Under Body Spacers and end of the M3 Screws. Add the Under Body Spacers to the protruding screw ends. Secure the Landing Gear Plate onto the Front of craft core with the M3 Stainless Nuts.
  • Page 34 Now turn your craft over and place your universal flight controller adapter plate onto the standoff and secure with the M3x6mm nylon screws as shown below. Note: the small notch on the adaptor plate should face to the front.
  • Page 35 Your setup should now look like this..
  • Page 36 Take the Quick Release Folding Cams and the completed BOT Core and slide the Cams onto Slide the Cam to the the ends of the booms, edge of the core making as shown below. sure that the bolts are a lined with the slots on the core.
  • Page 37 Flip the cam levers to a vertical position and make sure that it is secure. If the bolts aren’t down against the center plate then adjust the cam bolts. Unclip and pull out the QR mechanism a few times to make sure that the action and height of the bolts is correct.
  • Page 39 Dome 1106-0010 Top Mounting Post 1506-0060 Machine Screw M3x6mm Pan Phillips 2506-0140 Dome Grommet 2506-0260...
  • Page 40 Attach the four dome mounting posts Fit 4 of the rubber grommets to the to the center plate of your craft as dome as shown. shown in the picture below.
  • Page 41 Firmly press the dome onto the top of To attach / remove your Crash cage the craft aligning the grommets with the to / from your BOT Craft place fingers corresponing dome mounting posts. on each side of the mounting post and press firmly.
  • Page 42 Your setup should now look like this.
  • Page 43 Engine Mount Boot M3 Socket Head Cap Screw M3x30mm 1205-0130 2510-0060 Engine Mount Bracket M3 (13mm) Machine Screw M3x6mm SS 1206-0080 2506-0120 Engine Mount Bracket M3 (20mm) Nyloc Nut M3 SS 1206-0090 2506-0170 Engine Mount Disk M3 O-ring 2.5mm 1204-0061 2506-0270 Boom Nacelle Nylon Black O-ring 1mm...
  • Page 44 Place the second half of the Nacelle Slide the 1.5mm O-rings over the on top and snap together. boom... adjust the distance of the two O-rings to fit the Boom Nacelle. Please Note: we are showing the hi visibility boom nacelles in these pictures.
  • Page 45 Fit the two M3 x 30mm Titanium screws and Washers through Apply the heat shrink and slide the 1mm O-rings the engine mount bracket. onto each boom. Affix the engine to the engine mount disk by slotting the desired machine screws through the chamfered side of the Fit two of the 2.5mm O-rings over the M3x30mm disk and into the firewall mount holes of the engine.
  • Page 46 Feed the wires of your engine through the Engine Mount Add the second Engine Mount Bracket... Boot and boom as shown in the picture below..fold the engine and wires over to fit onto the Engine Mount Disk. Tighten with two M3 S/S nyloc nuts. Place the Boom as shown below, making sure the hole of the boom sits neatly on the dimpel of the Engine Mount Bracket.
  • Page 47 Finally push the 1mm O-ring into the arch Your final setup should now look like of the boot between the boom and the this. boot.
