HANTEL POCSAG PAGER
Function button
Caution : Any changes or modifications in construction of this device which are
not expressly approved by responsible for compliance could void the
user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the condition that this device dose not harmful interference
Read button

Advertisement

loading
Need help?

Need help?

Do you have a question about the POCSAG and is the answer not in the manual?

Questions and answers

Summary of Contents for HANTEL POCSAG

  • Page 1 HANTEL POCSAG PAGER Function button Read button Caution : Any changes or modifications in construction of this device which are not expressly approved by responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules.

  • Page 2: Lcd Display

    LCD display LCD is consist of 8 icons, small clock display area and main 12 digits display. Icons are; : In range indication : Licked message indication : Sound alert / Vibration mode : Unread message indication : Alarm clock enable indication : Duplicate message detection indication : Low battery indication : Additional message indication for more than 13digits.

  • Page 3: How To Operate

    How to Operate 1. Power ON / OFF 1) Power ON When pressing any button for 2 seconds or longer while the receiver is in the OFF state. A ring tone is activated and at the same time the following is displayed. And then, power is turned on.
  • Page 4 Press the read button. < Power OFF State > 2. Initial Receive Waiting State The following 1) and 2) show the initial receive waiting state in each mode. 1) Ring Tone Mode < Initial State > 2) Vibration Mode < Initial State > ¡...
  • Page 5 3. Switch of Alert Status 1) When switching from the ring tone mode to the vibration mode, Press the function button. Press the read button. < Switching into the vibration mode > 2) When switching from the vibration mode to the ring tone mode, When pressing the read button once after pressing the function button, the status Changes into Tone1, Tone2, Tone3, and Tone4 sequentially.
  • Page 6 Press the function button. Press the read button. Press the read button. Press the read button. Press the read button.
  • Page 7 Press the read button. < Switching into the ring tone mode > 4. Message Receive 1) In case a call is made , the received message is displayed on the screen and the call alert is activated at the same time. <Message receive while in the vibration mode >...
  • Page 8 3) Displaying the message with 13 characters or more In case the message with 13 characters or more received, the “ ” indication is displayed on the end part of the first screen to notify that the message continues on the next screen.

  • Page 9: Reading The Message

    5.Reading the Message 1) Reading the received Message When receiving the message the alert ( ring tone or vibration ) can be deactivated within the automatic recovery time by pressing function or read button. At this time, if a message with 13 digits or longer or longer is received, continuity indication is displayed. 2) Reading the Stored Message <...
  • Page 10 .3) Reading the Message Not Read In case there are messages not read, the following is displayed on the screen. Displays the total number of messages not read. Press the “ read ” button. 1: this means the first message. 4: This means the total number of messages received.

  • Page 11: Memory Capacity

    6. Memory Capacity This receiver stores a total of 16 telephone numbers. When all the telephone numbers are stored, new messages are received. Since the messages are deleted sequentially, starting with the first memorized message, important telephone numbers can be prevented from being deleted by protecting them beforehand.
  • Page 12 1) Message Protection Select the message to be protected on the screen. Then, press the function button while pressing the read button, to display the “ ” indication. This is used to indicate that the message on the screen is protected. <...
  • Page 13 Press the read button. The state is changed into the initial receive state as the message is deleted. 11. Alarm Adjustment Method The alarm function is used to activate the alarm at the user desired time. 1) Alarm Set - Up Press the function button two times in the initial receive state.
  • Page 14 “ ” and “ 10 ” start to blink. “ Read button ” : Time Adjustment “ Function button ” : Hour ¡ æ Minute ¡ æ AM / PM Press the function button after adjusting the changed time. ¡ Ø In case time adjustment has not been made in this state, the display starts to blink for 8 seconds and then, the alarm is set up to the pre - set time.
  • Page 15 The state is changed into the initial screen as the alarm is released. < Alarm Release State > 12. Time Adjustment Method Press the function button five times in the initial receive state. Press the read button. Current Time : The display starts to blink at the “ hour “ “...
