Imaging (VeriQ C™)
REGULATORY COMPLIANCE
Sales Classification
Device Category
Quality System
Provisions Imaging and volume flow meter probes
Provisions VeriQ™ and VeriQ C™ Systems
SYSTEM COMPONENTS
System Monitor
CPU
Memory
System Storage
Smart card reader
Ports
Sound
Printer
MATERIALS
Component
Base frame
Columns
Power inlet module
Front cover
Top cover
Back cover
Other structural brackets
Handles
STANDARDS
Safety
Usability
Ultrasound
EMC
Biocompatibility
RoHS
APPROVALS
No. of physical channels:
Transducer frequency:
Ultrasound bandwidth:
Maximum frame-rate:
Supported modalities:
Supported probe geometries:
Type:
Touch screen:
Native resolution:
Power:
Intel Core2 dual core
4GB
System hard disk >= 500GB
(one additional HDD for data storage is optional)
ISO/IEC 7816 compatible
2 x USB 2.0
Stereo speakers for directional Doppler sound
InkJet printer, colour, USB 2.0 compatible
Material
Molded aluminium
Extruded aluminium
Sheet metal
Sheet metal
Moded PUR
Thermoformed ABS
Sheet metal
Thermoplastic
IEC 60601-1 (ed.3)
IEC 60601-1-6 (ed.3) / IEC 62366 (ed.1)
IEC 60601-2-37 (ed.2)
EN 60601-1-2 (ed.3)
ISO10993-1:2009
EN50581 (ed.1)
The Medistim system and probes are approved according to UL 60601-1 & CSA C22.2 No. 601.1 with
MET listing number E113031.
The Medistim VeriQ™ Systems and probes are CE approved.
© MEDISTIM 2015
128
11 – 18 MHz
20 MHz
50 fps
2D (B-Mode)
Linear, phased array
Rx-Only. Caution: Federal Law (USA) restricts this device to sale by or
on the order of a physician
Medical ultrasonic imaging and volume flow-meter system with probes
Medistim ASA is ISO13485:2003 certified
Risk Class III in Annex II of the EC-Directive 93/42/EEC (MDD)
flow-meter probes: as amended by Directive 2007/47/EEC (CE-mark)
Risk Class IIb in Annex II of the EC-Directive 93/42/EEC (MDD) as
amended by Directive 2007/47/EEC with the exemption of section 4
(CE-mark).
19" TFT LCD, IEC60601-1 compliant
Surface-wave type, requires fingertip operation only, sharp pointing
devices will not work.
1280 x 1024 Pixels
12V DC, 50W
Coating/Surface
Powder paint
Powder paint
Powder paint
Powder paint
Paint
Structured (VeriQ™)
Paint (VeriQ C™)
Aluzinc
CFM-Velocity Doppler
CFM-Power Doppler
PW-Doppler
