GFS-2 Front Panel Description

The front panel of the GFS-2 contains two In-Band ports: a Fibre Channel port
and a GbE port. In addition, the switch has a RJ-45 serial port and a 10BaseT
Out-of-Band port, which are usually used for switch management.
To the right of each of the In-Band ports are four LEDs, which indicate the
current status and activities of the corresponding port.
Two other options that are specific to the GFS-2 are:
• A Reset button--located behind the center fan grill, centered on the front panel
• A LED status indicator for the Out-of-Band port
WARNING! D
O NOT USE ANY METALLIC OBJECT TO DEPRESS THE
U
SING METALLIC OBJECTS TO DEPRESS THE
IN ELECTROCUTION OR DAMAGE TO THE SWITCH
Figure 2-2 illustrates the GFS-2 front panel.
Figure 2-1
- L i g h t S a n d G F S - 2 H a r d w a r e G u i d e
2 14
GFS-2 S F P
WITCH RONT
R
ESET BUTTON COULD RESULT
.
ANEL
R !
ESET BUTTON
Out-of-Band port
Serial port
GbE port
GbE port status LEDs
Fibre Channel port
status LEDs
Fibre Channel port
Reset Button
L/A status LED
