U.S. Security Solutions CA601 User Manual

Ir remote
Hide thumbs

Advertisement

Quick Links

Download this manual
IR REMOTE CONTROL SYSTEM
User's Manual
Please read this instruction thoroughly before operation
and retain it for future reference.
IR REMOTE CONTROL SYSTEM
User's Manual
Please read this instruction thoroughly before operation
and retain it for future reference.
USER'S MANUAL
USER'S MANUAL
601 V1.2
601 V1.2

Advertisement

loading

Summary of Contents for U.S. Security Solutions CA601

  • Page 1 IR REMOTE CONTROL SYSTEM USER’S MANUAL User’s Manual Please read this instruction thoroughly before operation and retain it for future reference. 601 V1.2 IR REMOTE CONTROL SYSTEM USER’S MANUAL User’s Manual Please read this instruction thoroughly before operation and retain it for future reference. 601 V1.2...
  • Page 2 Thank-You Note Before You Get Start First of all, we would like to express our gratitude to you for purchasing CPcam products. Once again, this product is designed uniquely to meet all your personal needs with our great industry-designing ability and our everlasting perseverance to the quality of all our products.
  • Page 3 WARNING WARNING All the safety and operating instructions should be read before operation. The improper operation may cause permanent damage. • Please lift and place this equipment gently. • Do not expose this equipment to open sunlight. • Do not use this equipment near water or in contact with water. •...

  • Page 4: Specifications

    SPECIFICATIONS IR RECEIVER IR RECEIVER SPECIFICATIONS ª SPECIFICATIONS 1.Support PTZ camera & DVR control 2.Connected to RS-485 by transmission line 3.IR Receiver 4.Control up to 255 PTZ & LIGHT 5.Control up to 255 DVR 6.Enabling different ID 7.Current Consumption: DC 12V, 25mA IR TRANSMITTER IR TRANSMITTER SPECIFICATIONS...
  • Page 5 SITUATION SIMULATE PTZ CAMERA REMOTE IR RECEIVER SWITCH : connect IR TRANSMITTER : transmit SITUATION SIMULATE PTZ CAMERA REMOTE IR RECEIVER SWITCH : connect IR TRANSMITTER : transmit...
  • Page 6 RS 485 RS485-B RS485-A (green color line) (red color line) Note: Connect “RS485-A(red color line)” to 11 aperture on DVR’s Sub-D Plug, PTZ or Remote Switch. Connect “RS485-B(green color line)” to 10 aperture on DVR’s Sub-D Plug, PTZ or Remote Switch. RS 485 RS485-B RS485-A...

  • Page 7: Panel Description

    PANEL DESCRIPTION Preset Light 1.BLUE LINE AREA – Control CAMERA 2.RED LINE AREA – Control DVR CAMERA 3.OTHERS – Support CAMERA & DVR Zoom max 4.Digital Zoom is not supported now. Zoom min Number selection buttons Zoom + Zoom - Auto Menu Right...
  • Page 8 FUNCTION DEFINITION - CAMERA •Zoom max Press the Zoom max button, the picture will become the biggest size directly. •Zoom min Press the Zoom min button , the picture will become the smallest size directly. •Zoom + / – Press the Zoom + or Zoom- button to change the ratio. •Auto Please refer to PTZ User’s Manual.
  • Page 9 FUNCTION DEFINITION - DVR •CH1、CH2、CH3、CH4 Press Ch1- 4 to select channel. • Under DVR play mode, it can display the 4 channels in QUAD mode.Under setup mode, it can decrease value. • Under DVR play mode, it can display Picture in Picture screen. Under setup mode, it can increase value. •Zoom Press Zoom button to enlarge the digital picture.

  • Page 10: Adjustment And Settings

    ADJUSTMENT AND SETTINGS Turning On the Power of IR TRANSMITTER • Press DVR, CAMERA and Digital Zoom button one by one to turn on IR Transmitter. • IR Transmitter will turn off automatically after 8 minutes if there is no operation. Please restart again.
  • Page 11 ADJUSTMENT AND SETTINGS vID Setting – CAMERA For example: Changing Camera ID from 001 to 003 Step 2 Step 4 Step 2 Step 4 Step 1 Step 1 Step 3 Step 2 Step 3 Step 4 Step 1 Step 3 2.
  • Page 12 ADJUSTMENT AND SETTINGS vID Setting – DVR Use DVR panel to set DVR ID. Step 1 Step 1 Step 2 Step 2 Step 3 Step 3 Step 1 Step 2 Step 3 1.Enter the main menu of DVR 2. Enter “REMOTE” setup. 3.
  • Page 13 ADJUSTMENT AND SETTINGS vFunction : How to enter the main menu Step 2 Step 2 Step 1 Step 2 Step 3 Step 1 Step 3 Step 1 Step 3 1.Press “CAMERA” button 2.Press the ID number 3. Press “Menu” button and Menu list will be on the screen. or “DVR”...
  • Page 14 ADJUSTMENT AND SETTINGS vAuto vPreset In PTZ mode, press “Auto” button and PTZ For example: In PTZ mode, if you want to see the 6 preset position. will enter the Auto Mode. Press any key can stop the Auto Mode. Step 2 Step 2 Step 1...

  • Page 15: Remote Switch

    REMOTE SWITCH DC POWER INPUT DC POWER INPUT vID Setting: The ID setting is the same as the CAMERA ID. DC LAMP SOURCE DC BUZZER SET UP (ON/OFF Switch) To DC Power Source RJ-11 REMOTE SWITCH AC POWER INPUT AC POWER INPUT AC PLUG DC OUTPUT DC INPUT...
