Summary of Contents for Myo Technologies Myotone
-
Page 3: Table Of Contents
Myotone® Conductive Gel ........3... -
Page 4: Introduction
In order for this device to work properly, it is important to first apply the Myotone® Conductive Gel to the skin areas that are being treated. Gently apply the Myotone® to strategic areas of your face as outlined in this manual. The Myotone® has 3 toning settings to adjust to your comfort level. -
Page 5: Your Myotone® Facial Toning System Device
Toning Level and Charging Indicator Lights Myotone® General Specifications: Measures approx. 7.5” L x 2.2” W x 2” H Device Net Weight is approx. 5.6 oz. System Kit Gross Weight is approx. 1lb.8.6oz Made by Myo Technologies, Inc. in the USA Page | 2... -
Page 6: 2. Myotone Conductive Gel
This product is water soluble. Ingredients: Purified Water, EDTA Disodium, Propylene Glycol, Diazolidinyl Urea, Iodopropynyl, Carbomer, Glycerin and Triethanolamine. Myotone Elite System Additional Myotone® Conductive Gel can be ordered from our online ordering store at www.myotone.com or by calling us toll free at 1-877-969-2811. -
Page 7: Additional Myotone® System Items
Myotone Internal Battery Pack Input : 100-240v Output 5v 2 (3.7) V Rechargeable Lithium Ion batteries Note: For use only with the Myotone Unit Note: Battery Pack is not replaceable by user. and is not approved for any other device. -
Page 8: Before Using Your Myotone
Myotone® will advance through Toning Levels 1, 2, 3 and then turn off. With the Myotone off press the On/Off button once for level 1, twice for level 2, three times for level 3, and four times to turn your Myotone®... -
Page 9: Usage Instructions-- Personal Preparation
Apply the Myotone® Conductive Gel to only one side of your face at a time. Apply a small amount of conductive gel to the dual probes of the Myotone®... -
Page 10: Basic Techniques Face
Basic Techniques igure 1 Directions- Face 1. Apply the Myotone® Conductive Gel. 2. Position both probes just above your jaw line on the points marked, Hold for 4 seconds. (Fig. 1) 3. Reposition the probes on the points marked Hold for 4 seconds. -
Page 11: Basic Techniques Forehead
Basic Techniques Directions- Forehead 1. Apply the Myotone® Conductive Gel. 2. Position the probes above your temple on the points marked Figure 1 Hold for 4 seconds. (Fig 1) 3. Reposition the probes above the center of your eyebrow, on the points marked . -
Page 12: Advanced Techniques Eye And Temple
1. Position the Myotone® probes at the points marked . Hold for 4 seconds. (Fig 1) 2. Then move the Myotone® in a swooping “J” motion slowly in the direction of the arrows for a count of 4 seconds. Hold at the end of the move near your temple for 2 seconds. -
Page 13: Advanced Techniques Forehead
Directions- Forehead 1. Position the probes at the points marked . Hold for 4 seconds then move the Myotone® slowly in the direction of the arrows towards your scalp for a count of 4. (Fig 1) Figure 1 2. Reposition the probes at the points marked . -
Page 14: Advanced Techniques Cheek Movement 1
Directions- Cheek Movement 1 1. Position the probes at the points marked . Hold for 4 seconds then move the Myotone® slowly in the direction of the arrows towards your ear for a count of 4. (Fig 1) Figure 1 2. -
Page 15: Advanced Techniques Cheek Movement 2
Directions- Cheek Movement 2 1. Position the probes at the points marked , along the jaw line. Hold for 4 seconds, then move the Myotone® slowly in the direction of the arrows towards your eye bone for a Figure 1 count of 4. -
Page 16: Advanced Techniques Jaw And Chin Movements
Figure 2 tissue there, do not place the probes over trachea or midline of the neck. Hold for 4 seconds then move the Myotone® slowly up in the direction of the arrows. (Fig 2) 3. Reposition the probes at the points marked . -
Page 17: Advanced Techniques Neck Movement 1
Directions- Neck Movement 1 1. Position the probes at the points marked , just above the collarbone. Move the Myotone® in the direction of the arrows for a slow count of 4, stopping just under the jaw line. Figure 1 (Fig1) 2. -
Page 18: Advanced Techniques Neck Movement 2
(just not rest them near or on the above the collarbone) then trachea. Be sure to position move the Myotone® in the them in the muscle just outside direction of the arrows for a of the area. slow count of 4, stopping just before the back of the neck. -
Page 19: Cleaning & Maintenance & Troubleshooting
Areas To Avoid WARNING: Do not use your Myotone® on: Mid-line of neck (avoid area near or on the trachea for risk of potential problems with thyroid gland) Mouth Area (on top of the lips or touching the lips-if they happen to brush or briefly touch that is fine. -
Page 20: Indications For Use & Warnings
Consult with your physician before using this device, because the device may cause lethal rhythm disturbances to the heart in susceptible individuals; and Apply stimulation only to normal, intact, clean, healthy skin. Myotone® should not be used by: Children Pregnant Women... -
Page 21: Precautions
Painful areas Precautions Your Myotone® device is designed for cosmetic use only and for individuals in good health. If this is not the case for you, please consult your physician before use. Be sure to view your User Manual and Instructional DVD before using your Myotone®. A slight tingling sensation may occur while using the Myotone®... -
Page 22: Adverse Reactions
Adverse Reactions There have not been any reported adverse reactions with the Myotone® device specifically. However, skin irritation and burns beneath the electrodes have been reported with the use of other electronic stimulators. You may experience headache and other painful sensations during or following the application of electrical stimulation near or around your eyes and face. -
Page 23: Technical Specifications
Technical Specifications Type of protection Class II (while charging) or Internally Powered (while stimulating) against electrical shock Degree of protection against electrical shock Degree of IPx0 protection against ingress of water (IEC 529) Suitability for use Not suitable in presence with flammable anesthetic mixture Mode of operation... - Page 24 Myo Technologies, Inc. 1213 Culbreth Drive, Ste. 124 Wilmington, NC 28405 www.myotone.com ©Myo Technologies Inc. 2014...
