Summary of Contents for A4Tech rhp-7
- Page 1 Enjoy Hi-Fi music beyond boundary! User’s Guide Model : RHP-7 www.a4tech.com...
- Page 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 3 Noise Filter Function ● ●Charge Output Jack for Headphone Charging INTRODUCTION ●Audio-In Jack for Audio Cord connecting Audio Source,ideal choice for all types of music and TV The 3D Stereo Wireless Headphone is of the latest applications wireless technology. Its 3 Channel FM Stereo ●Power On Indicator: Green LED Light Technology enables emitting signals travel easily through walls and floors, delivering high-quality...
-
Page 4: Installation Of Transmitter
INSTALLATION OF TRANSMITTER back of TV, CD, VCD, DVD. Then insert the red 1) Connect the supplied AC/DC power adapter to an and white RCA plug ends into the equipment electrical power source or wall outlet. jacks marked "Audio Out " to make the audio 2) Plug the AC/DC power Adapter into the DC jack source connection. -
Page 5: How To Charge
with Both battery’s positive(+) side on top. 3) Replace the cover and your headphone is ready to use. Battery Door OPERATION HOW TO CHARGE ● Turn on your audio source (computer or other audio ● Connect the supplied power cord to the charge out source) to which the transmitter is connected. -
Page 6: Specifications
Carrier Frequency: 912-914 MHz Operating Voltage 1: 2.4V 2 × AAA Ni-MH Operating Voltage 2: 3.0V 2 × AAA alkaline Frequency Response: 20Hz – 20KHz Signal Noise Ratio: ≧55 dB Distortion: 1.5% Channel Separation: ≧30 dB Operation Maximum: 52M (in open space w/o boundary) NOTE: Changes or modifications not expressly approved by the party responsible for compliance to... - Page 7 the volume of the audio source equipment.
