PowerFlex 700L Installation Instructions Manual

Where This Kit Is Used

Table A Maximum DC Bus Capacitance with Existing Precharge
Input Voltage
Frame Size
Drive's Internal DC Bus Capacitance (µF)
Maximum External DC Bus Capacitance (µF) 19,150
Maximum Total DC Bus Capacitance (µF)
Table B Maximum DC Bus Capacitance with Precharge Kit Plus Existing Precharge
Input Voltage
Frame Size
Drive's Internal DC Bus Capacitance (µF)
Maximum External DC Bus Capacitance (µF) 89,851
Maximum Total DC Bus Capacitance (µF)
®
PowerFlex 700L Frame 3A and 3B Input Filter
Precharge Resistor Kit (20L-RESPRE-A1)
ATTENTION: To avoid an electric shock hazard, ensure that all
!
power to the complete drive cabinet has been removed before
performing any steps of these instructions.
ATTENTION: To avoid an electric shock hazard, verify that the
!
voltage on the bus capacitors has completely discharged before
performing any work on the complete drive cabinet. After
removing power, wait 5 minutes for the power module bus
capacitors to discharge. Remove the lower front cover of the
power module. Measure the DC bus voltage at the DC+
TESTPOINT and DC- TESTPOINT sockets on the front of the
power module. The voltage must be zero.
ATTENTION: HOT surfaces can cause severe burns. Do not
!
touch the heatsink surface during operation of the power module.
After disconnecting power allow time for cooling.
ATTENTION: The complete drive cabinet contains ESD
!
(Electrostatic Discharge) sensitive parts and assemblies. Static
control precautions are required when installing, testing,
servicing or repairing the complete drive. Component damage
may result if ESD control procedures are not followed. If you are
not familiar with static control procedures, refer to Allen-Bradley
publication 8000-4.5.2, "Guarding Against Electrostatic
Damage" or any other applicable ESD protection handbook.
This kit can only be used with PowerFlex 700L Frame 3A and 3B complete
drives. It is used to increase the precharge power capacity of the drive. This
kit may be required when powering another drive from the DC bus of a
Frame 3A or 3B complete drive. Only one kit per drive is permitted. See the
tables below for comparisons of maximum DC bus capacitance.
400V AC
3A 3B
16,200 32,400
38,301
35,350 70,701
400V AC
3A 3B
16,200 32,400
109,002 57,447
106,051 141,402 73,647

Installation Instructions

480V AC 600V AC
3A 3B 3A 3B
16,200 32,400 10,800 21,600
8,349 16,698 4,911 9,823
24,549 49,098 15,711 31,423
480V AC 600V AC
3A 3B 3A 3B
16,200 32,400 10,800 21,600
65,796 36,334 41,245
98,196 47,134 62,845
690V AC
3A 3B
10,800 21,600
1,080 2,160
11,880 23,760
690V AC
3A 3B
10,800 21,600
24,840 25,920
35,640 47,520
