Summary of Contents for Amoenus audio ASM 6-3
- Page 1 AUTHENTIC STEREO MONITOR ASM 6-3 SP amoenus audio AUTHENTIC STEREO MONITOR ASM 6 -3 SP optical AES-EBU SPDIF line input volume amoenus power balance phones...
- Page 2 Manual ASM 6-3 SP Foreword The ASM 6-3 SP is a special device for playing stereophonic music. The two algorithms for an improved playback quality on speakers amoenus verus amoenus externus ) and headphones ( ) are unique and provide a natural and comfortable listening experience.
-
Page 3: Installation
An internal voltage monitoring mutes the audio outputs at under- voltage (<10V) and over-voltage (>14V). Due to the small dimensions of the ASM 6-3 SP, the device is very handy. This is very useful, especially for headphone playback. Before you switch on the ASM 6-3 SP, all necessary inputs and outputs should be connected and the volume control must be turned to position “0”. - Page 4 Inputs Connect the ASM 6-3 SP to a free USB port on your computer. Do not turn on the ASM 6-3 SP until the computer is completely started up. Mac OS X 10.6 and later: No special audio driver is required.
- Page 5 Line The line output can be connected to an input of a HiFi system. The volume of the ASM 6-3 SP is bypassed. The volume has to be adjusted by the HiFi system. This balanced output is for active speakers. The volume is adjusted with the volume control of the ASM 6-3 SP.
- Page 6 On the other hand the radiating surface of a speaker is very small. Especially in the higher frequency range, where the localisation of the ear is highly accurate, the sound is emitted virtually punctual. ASM 6-3 SP...
- Page 7 • The instruments sound naturally (particularly such with a wide overtone spectrum). • The stereo image appear tidy (better localisation of the sound sources). • The virtual centre-channel gets the necessary presence. • The “live“ feeling is increased. amoenus verus without amoenus verus with ASM 6-3 SP...
- Page 8 In order to achieve the original listening experience on headphones the sound of loudspeakers in a 60° triangle array has to be simulated on the phones. ideal 60° stereo listening with listening with triangle headphones headphones and amoenus externus listening position ASM 6-3 SP...
-
Page 9: Recycling Information
Use the ASM 6-3 SP only in a dry environment. Clean the surface with a dry or slightly wet cloth and do not use any aggressive detergents. amoenus audio assumes no liability for misuse of the ASM 6-3 SP. Warranty amoenus audio grants a product guarantee of 2 years. -
Page 10: Digital Input
Technical Data ASM 6-3 SP Digital Input USB: USB Type B (female) SPDIF: Cinch (female) 0.5 - 2.1 Vpp @ 75 Ω optical: TOSLINK (female) AES-EBU: XLR (female) 0.25 - 8.5 Vpp @ 110 Ω Sample Rate: 44.1 - 192 kS/s Internal Data Format: 88.2 kS/s, 24 Bits... -
Page 11: Mechanical Specifications
165 x 92 x 190 mm (W x H x D) Weight (unit): 1.68 kg Weight (shipping): 2.75 kg Environment Working Temperature: 0 - +45 °C Storage Temperature: -40 - +85 °C (10 - 95 % RH) ASM 6-3 SP ! 1 0... - Page 12 ASM 6-3 SP ! 1 1...
