- Page 1 E S 1 2 0 I n s t r u c t i o n M a n u a l V 1.0.3...
-
Page 2: Table Of Contents
Contents I. Safety Statement II. Product Introduction III.Performance Parameters IV. Surface and Sockets V. Use Steps VI. Parameter Setting VII. Firmware Upgrade VIII. FAQ IX. Certification Marks... -
Page 3: Safety Statement P1
Do not operate under high humidity; Do not operate in inflammable/explosive environment. keep product surface clean & dry. Please don’t operate ES120 when it’s wet or operate it with wet hands,which will cause an electric shock. When using ES120,the handle is constructed with precision, dropping shall be avoided. -
Page 4: Product Introduction
II. Product Introduction ES120 is a STM32 processor-based mini smart electric screwdriver. It is featured with OLED display, Micro USB interface which serves as PC connecting and charging. Compact size, simple operation and easy to use. It can meet the essential requirements of school experiment, home appliance repair and electronic engineering. -
Page 5: Surface And Sockets
IV. Surface and Sockets ① ② ④ ③ 1. Button 2. OLED screen 3. Hex socket (size: 4mm) 4. Micro USB socket... -
Page 6: Use Steps
V. Use Steps When the screwdriver is power off, short press the key to enter stand-by interface. Way of use: In Standby mode, hold ES120's button, and: 1) When your wrist turns left (see Pic.1 and Pic.3), the bit of ES120 will turn clockwise;... -
Page 7: Parameter Setting
0.5 second, the screwdriver will rotate in the same direction as that of previous use. Stand-by interface: Working interface: 4、ES120 will automatically turn off if kept still for 15 seconds. VI. Parameter Setting 1. Manual setting... -
Page 8: Firmware Upgrade
Torque shifts, “0-4“ corresponds with “A-4” MotoTimeCont Motor service time, read only Version, read only Note: Settings will be applied to ES120 by saving. VII. Firmware Upgrade 1、Visit www.miniware.com.cn and download the latest ES120 firmware to your PC 2、When the screwdriver is power off, connect it to PC with USB data cable, and hold the key until “DFU3.44”... -
Page 9: Faq
3.Copy the hex firmware to root directory of the disk, and when the suffix of firmware changes to .rdy, disconnect USB data cable or press the key continuously thrice to quit DFU mode and thus complete the firmware upgrade. VIII. FAQ .Torque shift: when the torque reaches the highest torque shift, the screwdriver will stop for 3 seconds before working again, as to protect the screw and motor. -
Page 10: Certification Marks
IX . Certification Marks 9.1 Disposal Do not dispose this product with domestic waste. Handling and recycle: Disposal of the product shall be manipulated according to laws and regulations in your area. 9.2 Statement of Fulfilling FCC Standard This device fulfills part 15 of the FCC regulations Device must fulfill below 2 conditions: (1) Device must not generate interference.
