INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
IHP1500
Model Number / No. de Modelo:
INDUCTION HOTPLATE
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS. AND SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
La sección en español empieza en la página 17.
Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and
specifications without notice.
Avanti Products, A Division of The Mackle Co., Inc.
P.O. Box 520604 - Miami, Florida 33152
www.avantiproducts.com
Advertisement
Table of Contents
Related Manuals for Avanti IHP1500
Summary of Contents for Avanti IHP1500
- Page 1 INSTRUCTIONS. AND SAVE FOR LOCAL ELECTRICAL INSPECTOR’S USE. La sección en español empieza en la página 17. Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and specifications without notice. Avanti Products, A Division of The Mackle Co., Inc.
-
Page 2: Table Of Contents
Temperature / Power Specifications Timer Setup Timer Off (Cancel) Automatic Functions Cookware Tips Troubleshooting Guide Service for your Induction Appliance Wiring Diagram Your Avanti Products Warranty Instrucciones en Español Registration Information and Registration Card TABLE OF CONTENTS 17 ~ 21... -
Page 3: Hotplate Safety
INDUCTION HOTPLATE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. This symbol alerts you to potential hazards that can kill or injure you and others. -
Page 4: Important Safeguides
National Electrical Code ANSI/NFPA No. 70 (Latest Edition) and local electrical code requirements. • Replacement Parts – Only authorized replacement parts may be used in performing service on the range. Replacement parts are available from factory authorized parts distributors. Contact the nearest Avanti service center in your area. -
Page 5: Help Us Help You
Keep it handy to answer your questions. If you don't understand something or you need more assistance, please call: Avanti Customer Service 800-220-5570 Keep proof of original purchase date (such as your sales slip) with this guide to establish the warranty period. -
Page 6: Parts And Features
PARTS & FEATURES Induction Cooktop Control Panel Timer Set Button Timer Cancel / Off Button Temperature Display Selector Power Display Selector Settings (UP and DOWN) Buttons Keep Warm Selector Power ON / OFF Electronic Display... -
Page 7: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING • Read all instructions before using the Induction Hotplate. • CAUTION: Do not store items of interest to children in cabinets above a Induction Hotplate or on the surface of a Induction Hotplate. • Proper Installation - Be sure the Induction Hotplate is properly installed and grounded by a qualified technician. -
Page 8: Installation Instructions
• Do Not Touch Surface Units, Heating Elements, Interior Surfaces of Hotplate or Areas Near Units - Surface units and heating elements may be hot even though they are dark in color. Area near surface and interior surfaces of an Hotplate become hot enough to cause burns. -
Page 9: Electrical Connection
ELECTRICAL CONNECTION Improper grounding can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorized Avanti Products service center. • For personal safety, the hotplate must be properly grounded. -
Page 10: Operating Your Induction Hotplate
OPERATING YOUR INDUCTION HOTPLATE CONTROL PANEL 1. Oven Function Selector Knob 2. Oven Thermostat Knob 3. Front Left Burner Control Knob Rear Left Burner Control Knob 1. SET TIMER SELECTOR 2. TIMER OFF / CANCEL TIME SELECTOR 3. ELECTRONIC DISPLAY 4. -
Page 11: Operating Procedure
OPERATING YOUR INDUCTION HOTPLATE OPERATING PROCEDURE INSERT THE POWER CORD INTO A SOCKET USING THE INDUCTION HOTPLATE The surface control is easily operated. Simply turn the unit ON and select the desired temperature or setting. When the element is energized, The control has a variable of power output from Warm-hold function (158ºF/70ºC to 392ºF/200ºC) with a number of positions. -
Page 12: Cookware Tips
• Hotplate overheating protection: The hotplate is designed with a built-in fan that adjusts the temperature inside the hotplate. If the air inlet or outlet should be blocked and or clogged, the hotplate will automatically shut off after 10 audio alarms advising the consumer of the error. To correct this situation, clear the air inlet and outlet and restart the hotplate once it has cooled down for 5 minutes. - Page 13 CLEANING YOUR HOTPLATE • Disconnect the A/C from the main power box or designated circuit breaker, turn off the hotplate, make sure the surface unit is off and cool before proceeding. • Wring excess water out of the sponge or cloth when cleaning area of the controls, or any electrical parts.
-
Page 14: Troubleshooting Guide
We are proud of our customer service organization and the network of professional service technicians that provide service on your Avanti appliances. With the purchase of your Avanti appliance, you can have the confidence that if you ever need additional information or assistance, the Avanti Products Customer Service team will be here for you. -
Page 15: Wiring Diagram
WIRING DIAGRAM... -
Page 16: Your Avanti Products Warranty
F. Repairs when your Hotplate use. AVANTI PRODUCTS SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do not allow the exclusion or limitation of incidental or consequential damages, so this exclusion or limitation may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. -
Page 17: Instrucciones De Seguridad
INSTRUCCIONES DE SEGURIDAD ADVERTENCIA: Para reducir el riesgo de incendio, choque eléctrico, o daños cuando use electrodomésticos, siga estas precauciones: Lea todas las instrucciones antes de usar su Plancha de Inducción. PRECAUCION: No almacene artículos sobre la Plancha de Inducción o en gabinetes encima de esta ya que estos podrían llamar la atención de los niños. -
Page 18: Partes Y Caracteristicas
quemaduras por vapor. Algunos limpiadores pueden producir gases o vapores nocivos si es que entran en contacto con una superficie caliente. • No caliente recipientes de comida cerrados – la presión creada puede causar que el recipiente explote y podría ocasionar daño. PARTES Y CARACTERISTICAS 1. - Page 19 SELECCION DE TEMPERATURA/POTENCIA TABLA DE SELECCIÓN DE TEMPERATURA SELECCIÓN SELECCIÓN DE POTENCIA TIBIO (WARM) 300 VATIOS TEMPERATURA 300 VATIOS AJUSTABLE 1500 VATIOS ESPECIFICACIONES DE LA UNIDAD / POTENCIA RATIO DE VOLTAJE RATIO DE SALIDA DE POTENCIA DIMENSIONES PESO NETO USANDO EL MEDIDOR DE TIEMPO (SETUP) Ud.
- Page 20 Si la olla o sartén es removida durante el proceso de cocción, la pantalla mostrará un mensaje de error “E1” y sonará una alarma de sonido. Si en 60 segundos (1 minuto) no coloca una olla o sartén en la hornilla, esta se apagará automáticamente y empezará...
- Page 21 CUIDADO Y MANTENIMIENTO INFORMACION GENERAL PRECAUCION: Desconecte la unidad del suministro eléctrico antes de limpiar o dar mantenimiento. • Es aconsejable limpiar la unidad cuando esta esté fría, especialmente cuando vaya a limpiar las partes esmaltadas. • Evite usar productos de limpieza que contengan una base de cloro o ácido. LIMPIEZA DE SU PLANCHA DE INDUCCION •...
-
Page 23: Registration Information And Registration Card
REGISTRATION INFORMATION Thank you for purchasing this fine Avanti products. Please fill out this form and return it within 100 days of purchase and receive these important benefits to the following address: Avanti Products, A Division of The Mackle Co., Inc. - Page 24 PRINTED IN CHINA...
