The Land of Nod Geodome Assembly Instructions

Geodome Playground
This page lists the contents included in the box.
Please take time to identify the hardware as well as
the individual components of the product. As you
unpack and prepare for assembly, place the
contents on a carpeted or padded area to protect
them from damage. Please follow the assembly
instructions closely. Improper assembly can result
in personal or property damage.
Note: 2 adults are required to safely assemble
this product.
!
26 - Hex bolts
54 - Flat washers
26 - Hex nuts
1 - Hex wrench
Assembly Instructions
ded in the box.
are as well as
the product. As you
ce the
dded area to protect
assembly
Improper assembly can result
ely assemble
NOTE: For instructional purposes, the poles are labeled by letters on the diagram.
The actual poles are not labeled. Red tape is marked on the longest pole to reference
Pole B.
A
30 - Pole A
B
35 - Pole B
C
1 - Pole C
1 - Pole cover 1 - Fabric cover
